1
provide for direct connection of video
INPUT JACKS
3A 3B
devices (like VCRs, camcorders, and laser disc players)
or compatible home computers and TV games with
video/audio outputs. To see the signals from a device
connected to the
INPUT 1
4
EXTERNAL SPEAKER TERMINALS
of auxiliary speakers. Connection details are on
pages 48-49.
5 SPEAKER SWITCH
This switch lets you turn off TV's internal speakers so
that sound will instead come through speakers connected
to
EXTERNAL SPEAKERS
Details about connecting speakers to the TV are on
pages 48-49.
Important: Always place switch in
external speakers are used (or if external speakers are ever
disconnected).
jacks, select TV channel 91.
permit direct connection
terminals.
position if no
INTERNAL
Caution: When using TV games, computers, and similar products with
your TV, keep the brightness and contrast functions at low settings. If a
fixed (non-moving) pattern is left on the screen for long periods of time
at a high brightness or contrast setting, the image can be permanently
imprinted onto the screen. These types of imprints are not covered by
your warranty because they are the result of misuse.
2
6A 6B provide for direct connection of video
INPUT JACKS
devices (like VCRs, camcorders, and laser disc players)
or compatible home computers and TV games with
video/audio outputs. To see the signals from a device
connected to the
INPUT 2
CABLE/ANTENNA CONNECTORS
7
either a home antenna and/or a cable-TV system to your
TV. Connection details are on pages 38-40.
provides for direct S-VHS video
S-VIDEO CONNECTOR
8
connection from S-VHS VCR or camcorder. Remember
to also connect the S-VHS VCRs or camcorder's audio
jack(s) to the TV's
INPUT 1 LEFT
jacks. This is necessary because S-Video cables only
carry the super video (picture), not the audio signal.
Connection details are on pages 43-45.
To see the signals from a device connected to the
jacks, select TV channel 90.
jacks, select TV channel 92.
are used when attaching
and/or audio
R/MONO
S-VIDEO
37
