A u d i o M e n u :
Expanded Stereo
Your TV includes an Expanded Stereo feature which adds
greater depth and dimension to stereo broadcasts. Your TV
electronically increases the audio separation perception of
the speakers so you perceive an "expanded" more spacious
stereo sound effect.
Although you can easily turn the expanded stereo feature
on and off as desired, you may prefer to leave it turned on.
That way your TV will automatically process and expand
the stereo signals whenever a stereo broadcast is received
(or whenever a stereo tape is played through a stereo VCR
connected to the TV's audio/video jacks labeled
Because this feature expands stereo sound, it processes
only stereo signals. If a TV program is broadcast in mono
instead of stereo, your TV will automatically reproduce
monaural audio. You will not be able to hear Expanded
Stereo because expansion has no effect on monaural audio.
Stereo expansion enhances the ambience of music and
program material. Dramatic effects of spatial enhancement
can be experienced with music. Talk shows with
background crowd noise also benefit from expansion by
engulfing the listener in a wider sound field than would be
experienced without expanded stereo. The effect will vary
with program material.
The perception of greater stereo separation is created by
cancelling the cross-coupled sound from the right speaker
that arrives at the left ear (and the left speaker that arrives
at the right ear). Like stereo headphones, stereo expansion
isolates the left and right signals that arrive at the ears. As
a result, the speakers seem to be farther away from the TV.
Notes: The Expanded Stereo feature will have no effect unless the
program is broadcast in stereo.
When the Expanded Stereo feature is turned on, some sound will be
heard from each speaker regardless of the
14
B a s i c F u n c t i o n s
).
INPUT
control setting.
BALANCE
c o n t i n u e d
Resetting the Audio Function to Hear Expanded
Stereo
with or without remote
1 Press the button repeatedly to select the
MENU
Mute
Video Menu
Audio Menu
Setup Menu
and then press + to display the audio menu.
2 Press the button repeatedly to select the
MENU
–........|........+
Treble
Bass –........|........+
Balance –........|........+
Stereo/SAP: Stereo
Expand Stereo: Off
display.
3 Press either + or – to turn on Expanded Stereo. Each time
you press the + or – button, the on-screen display will change
from to , etc.
ON OFF
To Hear Expanded Stereo
1 The function
STEREO/SAP
must be set to . You
STEREO
will not hear expanded stereo
if this function is set to
or . Details are on
MONO SAP
page 13.
2 The
EXPAND STEREO
function must be set to
ON
You will not hear expanded
stereo if this function is set
to .
OFF
3 A stereo signal must be
present. You will not hear expanded stereo on TV programs if
the TV station is broadcasting monaural audio. You can,
however, hear expanded stereo if you play a stereo tape on a
stereo VCR that is connected to the TV's audio/video jacks
labeled .
INPUT
Normally, you can leave the
and the
STEREO EXPAND STEREO
will then automatically produce either expanded stereo or
monaural sound, whichever is broadcast.
R e m o t e
AUDIO MENU
EXPAND STEREO
Treble –........|........+
Bass –........|........+
Balance –........|........+
Stereo/SAP: Stereo
Expand Stereo: On
–........|........+
Treble
Bass –........|........+
Balance –........|........+
Stereo/SAP: Stereo
Expand Stereo: On
.
Treble –........|........+
Bass –........|........+
Balance –........|........+
Stereo/SAP: Stereo
Expand Stereo: On
function set to
STEREO/SAP
. Your TV
function set to
ON
