Summary of Contents for Giant neos pro
- Page 1 - English -...
-
Page 2: Table Of Contents
Content Heart Rate Introduction Reset Trip Data Set Smart EL Calories Unit Enter Setting Mode Power Calibration Current Altitude Parts Set Clock Mode / Sub Mode Functions Set Home Altitude Installation Set Odometer Clock Ascent% General Operation Set Wheel Size Date Average Display... -
Page 3: Introduction
Introduction Introduction Thanks for purchasing a Giant Neos PRO computer, it is an ANT+ digital multi-function computer. It is compatible with all ANT+ sport transmission devices, including Giant RideSense which is integrated in selected Giant bikes. For your own safety, please do not stare at the computer screen while riding, it may cause a dangerous situation during the ride. -
Page 4: Unit Parts
Unit / Parts Unit / Parts Neos PRO computer package contains 1 unit and 8 parts, Neos PRO+ computer package have additional PC-link docking and Heart Rate Belt. 1. Computer Unit 2. Base Mount 3. Rubber Pad 4. Battery Cap 5. -
Page 5: Installation
Installation Installation To install the battery, use a coin to open and close the battery cap. Computer can be mounted in 3 different positions: (A) Extened Mount (B) Stem (C) Handle Bar. CLICK... -
Page 6: General Operation Display
General Operation / Display GENERAL OPERATION / DISPLAY There are 4 main keys on the computer unit. EL key: Manual key for backlight M key: Operates the Mode functions, it also can be pressed on the bottom of unit when it is mounted. - Page 7 General Operation / Display 6. Pacer The pace arrow shows the comparison between current speed and average speed. If the current speed is above or equal to average speed, the up arrow displays; if the current speed below the average speed, the down arrow appears. 7.
- Page 8 General Operation / Display General Operation / Display 12. PC Link Mode If the computer unit is placed into the USB cradle, it will enter the PC-link mode automatically for data upload & download. 13. Sleep Mode The computer unit will turn to SLEEP mode after all sensors sleep more than 5 minutes.
-
Page 9: Compatible Sensor Pairing
Compatible Sensor 2 in 1 Sensor Neos PRO computer is compatible with all ANT+ 2.4G digital transmission device sensors, including Giant Ride Sense sensor in selected Giant bikes or 2 in 1 sensor in accessories. The sensor is not included in the package. Pair the sensor with computer unit before starting to ride. -
Page 10: Searching
Searching / Record Reminder / Reset Computer / Reset Trip Data Searching In Sleep mode, When bike is moving or press U+EL keys for 2 seconds, computer will start searching for paired devices. The longest time for searching is 30 seconds, effective distance for transmission is 1 meter. -
Page 11: Enter Setting Mode
Enter Setting Mode Enter Setting Mode 1. Press U key for 3 seconds to enter the setting modes. Select the parameter setting by pressing S or M key in sequence loop of Clock, Odometer, Wheel Size, Stopwatch, Countdown Distance, Heart Rate Limit, Altitude, User Data, Unit, Smart EL, Power Calibrate (if paired), and Exit. -
Page 12: Set Clock Set Odometer
Set Clock / Set Odometer Set Clock Select “C ” in setting mode, and press U key to enter Clock setting. Follow LOCK the key flow diagram. Select 24 hours set or 12 hours set by pressing S or M key and confirm it by U key. -
Page 13: Set Wheel Size
Set Wheel Size *Same as Bike2 setting WHEEL CIRCUMFERENCE Set Wheel Size EASY CALIBARATION & CIRCUMFERENCE Select “W ” in setting mode, and press U HEEL REFERENCE TABLE a. (mm) key to enter Wheel Size setting. Follow the key flow Tire Size 700x20C 2086... -
Page 14: Set Stopwatch
Set Stopwatch Set Stopwatch Select “S ” in setting mode, and press U key to enter Stopwatch TOPWATCH setting. Follow the key flow diagram. Press S or M key to select lapping by Manual or Auto and press U key to enter the setting. In Manual Lap setting, select sample rate in 5, 10, 20 seconds to record the data or Clear Memory by pressing S or M key. -
Page 15: Set Countdown Distance Set Heart Rate Limit
Set Countdown Distance / Set Heart Rate Limit Set Countdown Distance Select “ D ” in setting mode, and press U key to enter Countdown Distance ISTANCE setting. Follow the key flow diagram. Press S or M to adjust the number in different digit, and press U to confirm it. -
Page 16: Set Altitude
Set Altitude Set Altitude Select “A ” in setting mode, and press U key to enter Altitude setting. LTITUDE Follow the key flow diagram. Press S or M to adjust the altitude above (+) or below (-) horizontal line and the altitude height, and press U key to confirm it. Then you can save it as current altitude or set as home altitude. -
Page 17: Set User Data Set Unit
Set User Data / Set Unit Set User Data Select “U ” in setting mode, and press U key to enter User Data setting. Follow the key flow diagram. Press S or M key to select Male or Female and press U key to set personal weight, the range is 20 ~ 220 kg or 44 ~ 485 lb. -
Page 18: Set Smart El Power Calibration
Set Smart EL / Power Calibration Set Smart EL (Backlight) Select “S EL” in setting mode, and press U key to enter Smart EL setting. MART Follow the key flow diagram. Press S or M key to turn Smart EL function on or off, and press the U key to confirm it. -
Page 19: Mode / Sub Mode Functions
Mode / Sub Mode Functions Mode / Sub Mode Functions In Mode display press M key to display Clock/ Ride Time/ Stopwatch/ Distance Travelled/ Current Altitude/ Gradient%/ Ave. Speed/ Current Power/ Max. Temperature, and press S key to display the Sub functions under the main Mode functions. -
Page 20: Clock Date Ride Time
Clock / Date / Ride Time Clock / Date Clock display in 12hrs / 24hrs set, press S key to display date (MM-DD-YY). It will return to Clock automatically after 3 seconds if S key is not pressed. Ride Time Ride Time / Total Bike1 Ride Time / Bike1+Bike2 Ride Time Ride Time display the trip riding time, and press S key to display Total Bike1 trip ride time and Bike1+Bike2 ride time. -
Page 21: Stopwatch
Stopwatch Full Memory & Low Battery If computer memory is full, the LCD will display "MEMORYFULL" 1 second every minute. If battery is low, the LCD will display "LOW BTT" blinking, press any key to stop the blinking. Pre-setting Before using the stopwatch, pre-set the stopwatch to Manual / Auto Time / Auto Distance Mode (see p.23-24 Set Stopwatch ) Manual Stopwatch In Manual mode, hold M key 2 seconds to reset and start the stopwatch. - Page 22 Stopwatch Auto Time Stopwatch In Auto Time mode, hold M key 2 seconds to reset and start the stopwatch. It will lap automatically when the preset time is reached. Stop the stopwatch by holding M key 2 seconds and press S key to view the individual lap data. Auto Distance Stopwatch In Auto Distance mode, hold M key 2 seconds to reset and start the stopwatch.
-
Page 23: View Lap Data
View Lap Data View Lap Data After stop Stopwatch, press S key to choose the lap and view the individual lap data. It shows every 2 seconds in sequence of loop: Lap Time, Distance Travelled, Average RPM, Average Heart Rate, HR Lower Zone Time, HR In Zone Time, HR Upper Zone Time, Calories Consumed, Altitude Gain, Altitude Loss, Average Ascent%, Average Descent%, Average Speed, and Average Power. -
Page 24: Odo
ODO / Distance Countdown In Distance mode, press S key to display Bike1 ODO and Bike1+2 ODO. See distance countdown by pressing S key. Distance Countdown In Distance Countdown mode, hold M key to reset and start the timer. When the timer is running, hold EL key to see the estimated arrival time and release EL key to see the previous display. -
Page 25: Cadence
Cadence / Heart Rate / Calories Cadence In Current Cadence display, press S key to display Average Cadence and Maximum Cadence. It will return to Current Cadence automatically after 3 seconds if S key is not pressed. Heart Rate / Calories In Current Heart Rate press S key to display Average Heart Rate, Maximum Heart Rate, Heart Rate Lower Zone Time, In Zone Time, Upper Zone Time, and Calories Consumed during trip. -
Page 26: Current Altitude Set Home Altitude
Current Altitude / Set Home Altitude Current Altitude / Set Home Altitude In Current Altitude mode, hold M key 3 seconds to set current altitude as Home Altitude, and press U key to confirm it or press S key to return previous mode. To set current altitude as home, it will display same as Home Altitude. -
Page 27: Ascent% Average Maximum Speed Bike1 / Bike2
Ascent% / Average / Maximum Speed /Bike1 / Bike2 Ascent% In Ascent% Mode, press S key to display in sequence of Average Ascent%, Average Descent%, Maximum Ascent%, and Maximum Descent%. It will return to Ascent% automatically after 3 seconds if S key is not pressed. Average / Maximum Speed In Average Speed Mode, press S key to display Max Speed. -
Page 28: Power Temperature
Power / Temperature Power In Current Power display, press S key to display Average Power and Maximum Power. It will return to Current Power automatically after 3 seconds if S key is not pressed. Temperature In Maximum Temperature Mode, press S key to display Minimum Temperature. It will return to Max. -
Page 29: Trouble Shooting
Trouble Shooting Problem Possible Cause Solution Problem Possible Cause Solution Magnet is misaligned or Readjust the magnet and Battery is dead Replace battery too far away sensor position Erratic Data Battery is installed in Install battery in correct Sensor battery is low battery Replace the sensor battery wrong position position... -
Page 30: Technical Specification
Technical Specification Current Speed 2nd Wheel size Maximum Altitude Minimum Temperature 6000 m -20 ~ +60 199.9Km/h or m/h 0-3999mm Total Altitude gain/ Easy Calibration Average Speed Time (12/24hr) 14 + custom 199.9Km/h or m/h 12/24 99999 m loss for bike 1 or 2 Total Altitude gain Cadence Maximum Speed...
