PIONEER 205
PIONEER 205
OPERATING & MAINTENANCE
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pioneer 205 and is the answer not in the manual?

Questions and answers

Related Manuals for Clarke Pioneer 205

Summary of Contents for Clarke Pioneer 205

  • Page 1 PIONEER 205 PIONEER 205 OPERATING & MAINTENANCE INSTRUCTIONS...

  • Page 2: Table Of Contents

    Thank you for purchasing this Pioneer 205 Air Compressor which is fitted with a PARTS LIST 9.5 litre air receiver. Before attempting to operate the machine, please read this leaflet thoroughly and carefully follow the instructions given. In doing so you will ensure the safety No.

  • Page 3: Safety Precautions

    2. DO NOT operate your compressor with any guards removed. 3. Electrical or mechanical repairs should only be carried out by a qualified engineer. If problems occur, contact your Clarke dealer. 4. Before carrying out any maintenance, ensure the pressure is expelled from the air receiver, and the machine is disconnected from the mains supply.

  • Page 4: Electrical Connections

    We recommend that this machine is connected to the mains supply via a Residual Current Device (RCD) If in any doubt, DO NOT attempt any connections or repairs yourself. Consult a qualified electrician, your Clarke dealer, or CLARKE International Service Dep’t on 020 8988 7400 or e-mail: Service@clarkeinternational.com...

  • Page 5: Preparation For Use

    1. Check that the mains voltage corresponds with that shown on the data sticker on the crankcase cover of the machine. Your Clarke Pioneer 205 Air Compressor can be used in conjunction with a range 2. Ensure that the ON/OFF knob is in the ‘OFF’ (0) position, i.e. pushed DOWN, of optional accessories for inflating tyres, air brushing, stapling, blowing and many then plug in and switch on at the mains supply.
  • Page 6 However, should problems (see also item 1) when pressure reduces to develop with the cut-in, cut out settings, please consult your Clarke dealer, or approx 95 psi. the Clarke Service Dep’t.

  • Page 7: Shutting Down

    Load compressor to maximum pressure. 2. Check the oil level before you start and  Unplug the compressor. top up if necessary - (use Clarke SAE 40 compressor oil).  With a brush and soapy water wet all ‘screwed’ connections.
