Instructions for the installation
and advice for the maintenance
ED/30 1G AI AL TR - ED/30 2G AI AL
Instructions Manual
ED/30 1G AI AL TR - ED/30 2G AI AL
Town Gas
COD. 01001HKTK - 29.01.2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ED 30 1G AI AL TR and is the answer not in the manual?

Questions and answers

Summary of Contents for Teka ED 30 1G AI AL TR

  • Page 1 Instructions for the installation and advice for the maintenance ED/30 1G AI AL TR - ED/30 2G AI AL Instructions Manual ED/30 1G AI AL TR - ED/30 2G AI AL Town Gas COD. 01001HKTK - 29.01.2007...
  • Page 2 DESCRIPTION OF THE HOT PLATES MODELS: ED/30 1G AI AL TR - ED/30 2G AI AL 1 Ultra rapid burner of 3350 W 2 Rapid gas burner of 3500 W 3 Auxiliary gas burner of 1100 W 6 Enamelled steel pan support 1F 7 Enamelled steel pan support 2F 8 Burner n°...
  • Page 3 1) BURNERS - Use adequate pans for each burner (consult the following table and fig. 2). A diagram is screen-printed above each knob on the - When the pan comes to the boil, set the knob to the front panel. This diagram indicates to which burner reduced rate position (small flame fig.
  • Page 4 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
  • Page 5 CLEANING IMPORTANT: - Do not force the taps if they are difficult open or close. Contact the technical assistance service Always disconnect the appliance from the gas for repairs. and electricity mains before carrying out any - Don’t use steam jets for the equipment cleaning. cleaning operation.
  • Page 6: Technical Information For The Installer

    INSTALLATION TECHNICAL INFORMATION FOR The measurements of the opening made in the top THE INSTALLER of the modular cabinet and into which the hot plate will be installed are indicated in either fig. 7. Always Installation, adjustments of controls and comply with the measurements given for the hole maintenance must only be carried out by a into which the appliance will be recessed (see fig.
  • Page 7: Room Ventilation

    INSTALLATION 5) FIXING THE HOT PLATE The adhesive used to stick the plastic laminate to the cabinet must be able to withstand a The hot plate has a special seal which prevents temperature of not less than 150° C otherwise liquid from infiltrating into the cabinet.
  • Page 8: Gas Connection

    INSTALLATION 8) GAS CONNECTION WARNINGS: Remember that the gas inlet union on the Before connecting the appliance, check that the values on the data label affixed to the underside appliance is a 1/2" gas parallel male type in of the hot plate correspond to those of the gas compliance with ISO 228-1 standards.
  • Page 9: Electrical Connection

    INSTALLATION 9) ELECTRICAL CONNECTION When the appliance is connected straight to the electricity main: The electrical connections of the appliance must - Install an omnipolar circuit-breaker between the be carried out in compliance with the provisions appliance and the electricity main. This circuit- and standards in force.
  • Page 10 ADJUSTMENTS Always disconnect the appliance from the and turn the throttle screw to the right or left until the electricity main before making any adjustments. burner flame has been adequately regulated to the All seals must be replaced by the technician at “Reduced rate”...
  • Page 11: Replacing The Injectors

    CONVERSIONS 11) REPLACING THE INJECTORS After the injectors have been replaced, the burners must be regulated as explained in paragraphs 11. The burners can be adapted to different types of gas by The technician must reset any seals on the mounting injectors suited to the type of gas in question.
  • Page 12 SERVICING Always disconnect the appliance from the Greasing the taps (see fig. 18 - 19) electricity and gas mains before proceeding with If a tap becomes stiff to operate, it must be any servicing operation. immediately greased in compliance with the following 12) REPLACING HOT PLATE PARTS instructions: When parts housed within the hot plate need...
  • Page 13 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY Gas hot plate H05 RR - F Section 3 X 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
  • Page 14 TECHNICAL DATA ON THE DATA LABEL HONG KONG MARKET 1 BURNER “ DOMINO ” 2 BURNERS “ DOMINO ” LPG = 30 mbar LPG = 30 mbar TOWN = 10 mbar TOWN = 10 mbar Tot.Nom.L.P.G. Gas Rate = 4.6 kW Tot.Nom.L.P.G.
  • Page 15: Technical Assistance And Spare Parts

    TECHNICAL ASSISTANCE AND SPARE PARTS Before leaving the factory, this appliance will have been tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
  • Page 16 Malaysia Kuala Lumpur TEKA KÜCHENTECHNIK 3 – 762.01.600 3 – 762.01.626 (MALAYSIA) Mexico Mexico D.F. TEKA MEXICANA S.A. DE C.V. 5 - 762.04.90 5 – 762.05.17 Poland Warszawa TEKA POLSKA SP Z O.O. 22 - 652.18.94 22 - 850.12.48 Portugal Ilhavo TEKA PORTUGUESA LTDA.
