Summary of Contents for Bel Canto e.One S125
- Page 2 Trademarks used in this publication: Bel Canto and the Bel Canto logo are registered trademarks of Bel Canto Design Limited. S125 is a trademark of Bel Canto Design Limited. Bel Canto Design Limited disclaims any proprietary interest in trademarks and trade names other than its own.
- Page 3 Explanation of symbols used in this manual or on the CAUTION rear/underside of the apparatus: • To reduce the risks of electric shock, do not remove the cover. • No user serviceable parts inside. This symbol is intended to alert the user to •...
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 Bel Canto before attempting to transport your unit. This product, like any electrical component, can be The power supply on the S125 is preset for the dangerous and cause injury unless correct handling proper power voltage. The power cable should have procedures are observed and used.
- Page 6 Make all connections before powering your unit! The e.One S125 amplifier is a dual-mono audio power amplifier that delivers 130 watts into 4 ohm loads per channel. Each amplifier contains its own dedicated regulated power supply for all amplifier stages, including the output section.
-
Page 7: Rear Panel Connections
Rear Panel Connections Never Connect Either the Positive or Negative Speaker Output to Any Ground Contact! Connecting any Speaker Output on the S125 to Ground will cause the amplifier to go into protection and could damage the amplifier and void the warranty. - Page 8 ON again, check that the blue LED is lit and that music will play. There is an internal fuse protection on the S125. If the power switch is in the ON position, the power cable is •...
- Page 9 Maximum Power Output: 130W 4 ohms, 70W 8 ohms per channel Power Output 1% THD: 120W 4 ohms, 60W 8 ohms per channel Minimum Load: 3 ohms per channel Peak Output Current: 30 amperes Frequency Response: +/-3 dB 1.5Hz-90KHz, 4 ohm load THD+N: 0.003% 1W, 1KHz, 4 ohms IMD (CCIF):...
