INTRODUCTION
The Hitec X4 AC Plus allows you to charge up to four different batteries simultaneously.
The charger will automatically charge all 4 batteries at a time to their maximum capacity.
Additionally the batteries being charged do not need to have the same configuration or the
same chemistry. Therefore you can connect any one of a NiMH/NiCD/LiPo/LiFe battery
into any of the charging ports. This eliminates the time consuming efforts of charging all
your batteries separately.

Specifications

Power Source
Operating Voltage Range
Charge Power
Discharger Power
Cell Count
Current Drain for Balancing Lithium
Charge Termination
Lead-Acid and Lithium
Dimensions
Net Weight
02
100-120V AC, 12V DC Car Battery or
11-15V DC Power Supply
DC 11 - 15 Vol t
50 Watts, current is regulated accordingly
e.g. 11.1 V battery, charge current approx. 4.5 A
e.g. 22.2 V battery, charge current approx. 2.2 A
5 Watts, current is regulated accordingly
1-15 NiCd/NiMH cells
1-6 LiPo/LiIon/LiFe cells
1-10 Lead-Acid cells (2V - 20V)
300mA
Automatic, negative delta-peak method
NiCd/NiMH
Automatic, voltage-dependent, CC-CV process
8.9" x 6.7" x 2.6"
3.4 lbs.
