LCD Screen
AC Input Power Port
100-120V AC
(US Version)
220-240V AC
(EU Version)
Universal Balancing
Port Pitch=2.54mm
Battery Sockets
Universal Balancing
Port Pitch=2.54mm
Menu Control Buttons
Battery
Sockets
DC Input
Socket
T emp Sensor PC Link
Available for
CHARGER LAYOUT
Menu Control Buttons
Battery
Sockets
T emp Sensor PC Link
Available for
output
Ventilation Fan
with T emperature
Sensor Control
output
2 & 4 only
1 & 3 only
