Product Layout

In the case of an error, the screen will communicate the cause of the error and
emit an audible sound.

The Set Contains:

1 x X2AC Plus Charger
1 x Power Cord
1 x Universal Balancing Board
1 x Balance Adaptor
2 x 18AWG Wire Charge Cables
Cooling Fan
Balance Lead Socket
Temp Sensor Port .
Cooling Fan
DC Input
11-18V
8
LCD Display
Output Socket
4mm Banana Plug
Balance Lead Socket
Temp Sensor Port
.
Micro USB Port for
PC Link / WiFi Module
Connection
USB Port
AC Input
100-240V
Tilt Stand

Specifications

X2 AC Plus Specifications
AC Input
DC Input
Total Charge Circuit Power
Charge Current Range
Discharge Current Range
Discharge Current Power
Current Drain for LiPo Balancing
NiCd/NiMH Battery Cell Count
- Capacity Range
LiPo/LiHV/LiFe/Lilon Cell Count
- Capacity Range
Pb Battery Voltage
- Capacity Range
Net Weight
Dimensions
100 - 240 Volts AC
11 - 18 x Volts DC
100 Watts AC input
200 Watts DC input
0.1 - 10.0 Amps x 2
10 Watts x 2
0.1 - 5.0 Amps x 2
200mA per cell
1 - 15 Cells
100 - 50000mAh
1 - 6 Cells
100 - 50000mAh
2 - 20 Volts
100 - 50000mAh
2.15 lbs
975g
6.42 x 6.02 x 2.83in
163 x 153 x 72mm
