Sun ZFS Storage 7700 SAS Cabling
The following illustration shows how SAS cabling is provided from the factory in the main
cabinet.
fig.1 Sun ZFS Storage 7700 SAS and cluster cabling as shipped
Figure Legend
1 System controller 0 3 RCC 0
2 System controller 1 4 RCC 1
90
Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010
