Adjust the input levels of Stereo1 and Stereo2 by selecting the box under L or R and turning
the volume control knob.
Inputs can be sent to:
The Left and Right outputs
The Left Surround and Right Surround outputs
Left and Left Surround, plus Right and Right Surround
Matrix Decoder
Note when Enable Mic is selected both Microphone and stereo will be on at the same time.
Microphone audio is not mixed with the stereo audio but must be routed to different speakers.
The microphone audio is added to the hearing impaired audio when using the stereo input with
the microphone playing on the surround channels.
4.3.6.3.1.
System > Inputs > Input Options > Stereo Level and Routing > Mic
If Enable Mic is selected in the Stereo level and routing screen, you can adjust mic level and
routing by going to Mic Level and Routing screen.
Note this is used with the Stereo input and Microphone option, if using just the
Microphone input see section 4.3.6.4
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Figure 50. Stereo Level & Routing
Stereo Mic Level and Routing
Figure 51. Mic Level with Stereo
