Protection function
Fitting parts
ambient
configuration
Mounting mode
To exert excellent performance of this inverter, please choose correct type and check
relevant content according to this chapter before wiring for use.
note
!
Must choose correct type, otherwise may cause abnormal running of the motor or
damage of the inverter.
warning
12
12
Use ambient
altitude
Ambient temperature
Ambient humidity
vibration
Storage temperature
Defending grade
Cooling mode
2 Type and specification of the inverter
Over-current protection, over-voltage protection,
lack-voltage protection, over-heat protection,
over-load protection, etc.
brake subassembly, remote-control keypad,
connecting cable for remote-control keypad etc.
indoor，not bare to sunlight，no dust, no corrosive
gas, no flammable gas, no oil fog, no vapor, no
water drop or salt etc.
Lower than 1000m ,if higher than 1000m ,need to
reduce amount to use.
-10ºC~+40ºC(under ambient temperature 40ºC
~50ºC, please reduce the volume or strengthen heat
sink)
Smaller than 95%RH, no condensation water
Smaller than 5.9m/s²(0.6g)
-40ºC~+70ºC
IP20
By fan with automatic temperature control
Wall hanging
