F2.10 Principal subordinate
machine communication
frequency provision
proportion
F2.11 LED display control 1
166
Appendix 2 The manual of middle frequency inverter
7: exterior pulse provision－
CCI
8: reserved
9: reserved
10: reserved
11: reserved
12: reserved
13: VCI，CCI any nonzero
value effective, VCI
preferred
14: reserved
15: RS485+CCI
16: RS485-CCI
17: RS485+VCI
18: RS485-VCI
19: RS485+keypad
potentiometer
20: RS485- keypad
potentiometer
21: VCI+ keypad
potentiometer
22: VCI- keypad potentiometer
23: CCI+ keypad
potentiometer
24: CCI- keypad potentiometer
25: reserved
26: reserved
27: reserved
28: reserved
0(%)－500(%)
0000-1111
first bit: running time
0: not display
1: display
second bit: accumulative time
0: not display
1: display
third bit: input terminal status
0: not display
1(%) 100(%)
1 0000
○
○
167
