substitute for keypad to realize long-distance control. Effective during common
run if F0.00=2.Increasing descending speed is set by F5.09.
18: Accel&Decel speed forbidden command. Let the motor not effected
by any foreign signal(except stop command)，keep running at current frequency.
Ineffective during normal decelerating stop.
note
19: three-wire run control. Please refer to function description of F5.08
run mode (three-wire run mode).
20: closed-loop ineffective. Realize flexible switch to lower level runmode
under closed-loop run status.
(1) can switch between closed-loop and lower level run mode only during closed-loop
run(F3.00=1).
note
(2) start stop control, direction and Accel&Decel time are subject to setting of
corresponding run mode when it's switched to lower level run mode.
21: PLC ineffective. Realize flexible switch to lower level run mode
underPLC run status.
(1) can switch between PLC and lower level run mode only during PLC run(F4.00≠0).
(2) start stop control, direction and Accel&Decel time are subject to setting of
note
corresponding run mode when it's switched to lower level run mode.
22: simple PLC pause command. Implement pause control to PLC
processduring running，run at zero frequency when this terminal is effective，not
time for PLC run；after ineffective implement automatic speed tracking start and
continue PLC run. For application method please refer to function description of
F4.00~F4.14.
23: PLC stop status restoration. Under stop status of PLC run mode,
willclear PLC run step, runtime, run frequency etc. recorded when PLC run stops
if this terminal is effective，please see F4 group function description.
24~26: terminal frequency provision channel selection. Through
ON/OFF combination of frequency provision channel selection terminal 24, 25,
26，can realize frequency provision channel switch shown in Table 6-5. For
relation of terminal switch and function code F0.00 setting, that is, latter effective.
