Function Code
F0.00
F0.02
F0.08
F0.09
F0.10
F0.14
F2.06
F2.07
F2.08
F3.30
F5.00
F5.01
F5.02
F5.10
F5.15
F5.16
F5.17
F5.18
F5.19
F5.20
F5.21
F5.22
F7.03
7.1.2 Wire receiving machine parameters of fine-drawing machine
and micro-pulling machine（EDS1000 Series）
Function Code
F0.02
F0.03
F0.08
F0.09
F0.10
F1.05
F1.06
F1.07
F1.08
F2.00
F2.18
160
Function Name
Frequency input channel selection
Run command channel selection
Acceleration time 1
Deceleration time 1
Upper limit Frequency
Torque boost
Jog run frequency
Jog acceleration time
Jog deceleration time
Failure relayTA,TB, TCfunction selection
Input terminal X1 function selection
Input terminal X2 function selection
Input terminal X3 function selection
Open circuit collector output terminal OCI
FDT1(frequency level)electric level
FDT1 lag
Analog output (AO1)selection
Analog output (AO1)gain
Analog output (AO1)offset
Analog output (AO2) selection
Analog output (AO2) gain
Analog output (AO2) offset
VCI max. provision corresponding freq.
Function Name
Run command channel selection
Run direction setting
Acceleration time 1
Deceleration time 1
Upper limit Frequency
Stop mode
DC brake initiative freq. when stop running
DC brake time when stop running
DC brake voltage when stop running
Analog filter time constant
Acce. time 2(when start up smoothly )
Appendix 1 EDS1100 Drawing machine Inverter Manual
Factory Value
1
0
20.0
20.0
50.00Hz
0.5
5.00Hz
20.0s
20.0s
15
0
0
0
0
10.00Hz
1.00Hz
0
1.00
0.00
0
1.00
0.00
50.00
Factory Value
0
000
20.0
20.0
50.00Hz
0
0.00
0.0
0
0.20s
20.0
Setting
4
1
40.0-60.0
40.0-60.0
80.00
2.5
6.00
6.0
6.0
15
11
5
12
2
5.50
0.01
0
1.00
0.00
0
1.00
0.00
80.00
Setting
1
010
2.0
2.0
75.00
2
3.00
1.5
8
0.03
150.0
