Plena Power Amplifier | Installation and User Instructions | Technical data
6

Technical data

6. 1

Electrical

6.1.1

Mains power supply

Voltage
115 - 230 VAC, ±10%, 50/60 Hz
Inrush Current PLE-1P120-EU
8/16 A (230/115 VAC)
Inrush Current PLE-1P240-EU
9/19 A (230/115 VAC)
6.1.2

Battery power supply

Voltage
24 VDC, ±15%
Current PLE-1P120-EU
6 A
Current PLE-1P240-EU
12 A
Charge current
0.5 ADC
Charge float voltage
27.4 VDC
6.1.3

Power consumption

PLE-1P120-EU (mains)
400 VA
PLE-1P240-EU (mains)
800 VA
6.1.4

Performance

Frequency response
50 Hz to 20 kHz (+1/-3 dB @ -10 dB ref. rated
output)
Distortion
<1% @ rated output power, 1 kHz
Bosch Security Systems | 2008-02 | PLE-1P120-EU, PLE-1P240-EU en
6.1.5

Line input - loop through output

Line input
3-pin XLR, balanced, phantom
Loop through output
3-pin XLR, balanced, phantom
Sensitivity
1 V
Impedance
>1 kohm (mic); >5 kohm (line)
S/N
63 dB
Dynamic range
100 dB
CMRR
>40 dB (50 Hz to 20 kHz)
6.1.6

100 V input

Connector
4-pin, Euro style pluggable screw terminal
Sensitivity 100 V
100 V adjustable
Impedance
>10 kohm
S/N (flat at max volume)
>65 dB
6.1.7

Loudspeaker outputs 70 / 100 V*

Connector
Euro style pluggable screw terminal, floating
Max / rated PLE-1P120-EU
180 W / 120 W
Max / rated PLE-1P240-EU
360 W / 240 W
6.1.8

Loudspeaker output 8 ohm*

Connector
Euro style pluggable screw terminal, floating
PLE-1P120-EU
31 V (120 W)
PLE-1P240-EU
44 V (240 W)
* Subtract 1 dB for 24 V battery operation.
en | 19
