- Page 1 8 Zones Multiroom System ORDERCODE D2680...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. The DAP Audio 8 Zones Multiroom System brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
-
Page 3: Table Of Contents
DAP Audio DAP Audio 8 Zones Multiroom System Product Guide Warning ..................................Return Procedure..............................Safety-instructions..............................Operating Determinations............................. Return Procedure..............................Claims..................................Description..................................Features..................................Overview Front panel............................Overview Back panel............................Operation..................................DIP Switch Settings..............................Connecting Multiple Units............................. Connecting Inputs..............................Connecting Outputs.............................. Keypad Panel Features and Functions........................ Keypad Installation.............................. -
Page 4: Warning
WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 5: Safety-Instructions
Never remove warning or informative labels from the unit. Never use anything to cover the ground contact. Do not insert objects into air vents. Do not connect this system to a dimmerpack. Do not switch the system on and off in short intervals, as this would reduce the system’s life. Do not open the device and do not modify the device. -
Page 6: Return Procedure
OPERATING DETERMINATIONS If this system is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void. Any other operation may lead to dangers like short-circuit, burns, electric shock, etc. You endanger your own safety and the safety of others! Improper installation can cause serious damage to people and property ! Connection with the mains... -
Page 7: Description
Description of the device Features The 8 Zones Multiroom System is a professional high power Public Adress Amplifier: • Multi-room/ source distribution system • Audio and video signal distribution • Easy connection and mounting system • Master-slave link setup (10 units) •... -
Page 8: Overview Back Panel
Backpanel Fig. 2 8. Preamp Line Out (1-8) If an application requires more power than the built in zone poweramp (2x20W) can deliver, you can use the zone line outputs to connect an additional amplifier. 9. Zone Speaker Output (zone 1-8) Four pole terminal for connecting 2 speakers to a zone. -
Page 9: Operation
AC Inlet With Integrated Fuse Holder This connector is meant for the connection of the supplied main cord. Connect one end of the power cord to the connector, the other end to the mains, then turn on the Power Switch (11) to operate the unit. -
Page 10: Connecting Multiple Units
2. DIP switch 6 can be used to switch the autobroadcast function On or Off. Dip switch 6 = 1 Pressing the Call switch on the frontpanel of the AVP-800P will generate a call even if a keypad is powered off. If a keypad is powered off the AVP-800 will automatically start up the keypad in call mode. -
Page 11: Connecting Inputs
Connecting Inputs Fig. 5 Connecting Outputs Speakers are connected using terminal connectors. See the examples below and following page. Fig. 6 Absolute minimum nominal load Impedance is 4 Ohm per channel to avoid damage to the amplifier. The total speaker power should be at least the power of the amplifier to avoid damage to the speakers. -
Page 12: Keypad Panel Features And Functions
Keypad Panel Features and Functions. Fig. 7 24. Function LED This LED lights if function mode is selected. In function mode you can select source 1-6 using the Up (29) and Down (28) buttons. 25. Volume LED This LED lights if volume mode is selected. In volume mode you can adjust the volume using the Up (29) and Down (28) buttons. -
Page 13: Keypad Installation
38. Video Gain Control Use to adjust the video output level of the keypad. Range 0 - +6dB. Keypad Installation Fig. 8 Remote Control 39. Mute Button Press to mute all zones. 40. Source +/- Use these buttons to select the input source C1-C6. 41. -
Page 14: Connection Cables
Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 15: Product Specifications
Keypad controls: Source, bass, treble, volume 4 camera inputs (RJ-45) 4 video inputs (RCA) Dimension Controller/ Amplifier: 485 x 425 x 88 mm (LxWxH) Dimension Keypad: 125 x 82mm (LxWxH) Design and product specifications are subject to change without prior notice. Website: www.dap-audio.info Email: service@highlite.nl... - Page 16 2009 Dap Audio.
