INTRODUCTION: Congratulations, you have just purchased one of the most innovative and reliable lighting fixtures on the market today! The Design Spot 1400E,™ has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit.
Page 4
Please do not discard the shipping carton in the trash, keep for warranty repair. Please recycle whenever possible. WARRANTY REGISTRATION: The Design Spot 1400E™ carries a two year (730 days) limited warranty. Please fill out the enclosed warranty card to validate your purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number.
Page 5
Design Spot 1400E™ high-pressure environment to emit a brilliant output. Due to the high pressure involved with the construction of the lamp, the lamp may explode during prolonged extensive use. This risk is increased with age; added care is encouraged when dealing with older lamps. Thus, lamp should always be replaced at the end of their recommended duty cycle.
2. Never touch the fixture during normal operation. This can cause severe personal injuries and/or damage to the fixture. 3. Be sure to unplug the Design Spot 1400E™ from the power outlet before performing any service related issues. 4. Lamp Replacement; Please wait at least 15 minutes after disconnecting the main power before you open the Design Spot 1400E™.
Design Spot 1400E™ 4. GENERAL GUIDELINES This fixture is a professional lighting effect designed for use on stage, in nightclubs, in theatres, etc. Do not attempt operation or installation without a proper knowledge on how to do so. This fixture was designed for indoor use only. Use of this fixture outdoors may void the manufactures warranty.
• Allow the unit to cool for at least 15 minutes before attempting any type of service. • Before you put the Design Spot 1400E™ into operation after a lamp change or service, be sure all covers have been replaced and/or closed and secured.
The Design Spot 1400E™ lamp holder is aligned at the factory. However, due to slight imperfections in all lamps, fine adjustments will improve light performance. Please follow the procedure below for proper lamp optimization: 1.
Mounting The Design Spot 1400E™ is fully operational in two different mounting positions, hanging upside-down from a ceiling, or set on a flat level surface (see illustration on next page). Be sure this fixture is kept at least 0.5m (1.5ft) away from any flammable materials (decoration etc.).
Clamp Mounting The Design Spot 1400E™ provides a unique mounting bracket assembly that integrates the hanging yoke as well as the safety cable rigging point in one unit (see the illustration on the next page).
Securing the Design Spot 1400E™ Regardless of the rigging option you choose for your Design Spot 1400E™ always be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the hanging bracket as illustrated above. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable to a carrying handle.
1 to that fixture no matter where it is located in the DMX chain. The Design Spot 1400E™ can be controlled via DMX-512 protocol. The Design Spot 1400E™ is a 25-channel DMX fixture (16-bit mode). The DMX address is set electronically using the controls on the LCD menu.
Page 18
Design Spot 1400E™ Be sure to follow the above figure when making your own cables. Do not use the ground lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing. Grounding the shield could cause a short circuit and erratic behavior.
Page 19
Design Spot 1400E™ DMX-512 connection with DMX terminator A DMX terminator should be used in all DMX lines especially in longer runs. The use of a terminator may avoid erratic behavior in your DMX line. A terminator is a 120 ohm 1/4 watt resistor that is connected between pins 2 and 3 of a male XLR connector (DATA + and DATA -).
Page 20
In the case of the Design Spot 1400E™, which is a 25 channel fixture, you should set the starting DMX address of the first unit to 1, the second unit to 26 (25 + 1), the third unit to 51 (25 + 26), and so on.
9. FIXTURE MENU On-Board System Menu: The Design Spot 1400E™ comes with an easy to navigate system menu. This next section will detail the functions of each command in the system menu. LCD Control Panel: The control panel located on the side of the fixture allows you to access the main menu and make necessary adjustments to the Design Spot 1400E™.
Page 22
Fans Speed Mode Select Temperature between C˚/F˚ 05 M, 02-59M Display off interval 70%, 40~99% LCD brightness 185 150 199 Display Contrast PAN =XXX Initial effect position Activate WDMX De-activate WDMX Reset Wireless DMX memory Restore factory sett. Design Spot 1400E™ switch...
Page 23
Step 01=SCxxx Step 64=SCxxx Pan,Tilt,…… Pan=xxx… --Secne Time-- TIME=XX.XS Input external source Design Spot 1400E™ Reset all motors Reset Pan/Tilt Reset color wheel Reset all gobo wheels Reset shutter and dimmer Reset all other motors Test all channels Fine adjustment...
Page 29
Design Spot 1400E™ No DMX Status – This function dictates how the fixture will function if it looses DMX signal during normal operation. The default function is set to hold, in which the fixture will lock into the last DMX signal it received and remain in that position until it is turned off or begins receiving a new DMX signal.
Page 33
10.8.4 Auto Scenes rec - The Design Spot 1400E features an integrated DMX recorder by pre-programmed scenes can be transmitted to the fixture via any standard DMX controller.
12. OPERATION Operating Modes: The Design Spot 1400E™ can operate in several different modes. This next section will detail the differences in the operating modes. • Auto Program Mode (Master) - The fixture will chase through the built-in programs, sending a DMX control signal to all other fixtures connect via DMX cables instruction for a synchronized light show.
Page 37
16 fixtures to be linked together to provide a synchronized light show without the use of a controller. Only use this when linking several Design Spot 1400E together for use without a controller. Any fixture can act as a “Master or a “Slave.”...
Page 39
13. Using the Built-In Wireless DMX System The Design Spot 1400E comes equipped with an Elation Wireless DMX Receiver built-in. This receiver is fully compatible with your existing Elation Wireless DMX System. 13.1 Working with the Wireless DMX (WDMX) System: •...
Page 45
Design Spot 1400E™ • Press the Enter button to confirm. • Turn the encoder to select “Master” or “Alone”. The selection "Alone" means Stand Alone-mode and "Master" that the device is defined as master. • Press the Enter button to confirm.
Page 46
Design Spot 1400E™ number of 250 • Turn the encoder to select the desired scene numbers. You can program a maximum number of 250 scenes. • Press the Enter button to confirm. • Press the Mode/Esc button in order to return to the main menu.
Design Spot 1400E™ 15. DMX CHANNEL TRAITS: The chart below details the channel layout for 25 DMX channels (default). In 8bit mode the “Pan Fine” and “Tilt Fine” channels are not used, thus converting the fixture into a 23-channel DMX fixture.
Design Spot 1400E™ FUSE REPLACEMENT The Design Spot 1400E has two external protective fuses. One fuse protects the internal electronics and the other protects the lamp circuitry. Refer to page 10 for fuse holder location. Fuse 1, Lamp Fuse: GMA 220v/10A...
Design Spot 1400E™ 17. ERROR CODES: When power is applied, the unit will automatically enter a “reset/test” mode. This mode brings all the internal motors to a home position. If there is an internal problem with one or more of the motors an error code will flash in the display in the form of “XXer” were as XX will represent a function number.
Page 55
Design Spot 1400E™ located in the default position after the reset. Rotation Gobo 1 Er (Rotation gobo 1 error) This message will appear after the reset of the fixture and if the magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the main PCB).
Page 56
Design Spot 1400E™ Prism rotation Er (Prism rotation error) This message will appear after the reset of the fixture if the head’s magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driving IC on the main PCB). The Prism rotation is not located in the default position after the reset.
Page 57
Design Spot 1400E™ magnetic-indexing circuit malfunction (sensor failed or magnet missing) or the stepping-motor is defective (or its driving IC on the main PCB). The Color wheel is not located in the default position after the reset. Iris Er (Iris error) This message will appear after the reset of the fixture if the yoke’s magnetic-indexing circuit malfunction (sensor failed or magnet missing) or the stepping-motor is defective (or its driving IC on the main PCB).
United States of America, including possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable evidence, at the time service is sought. B. For warranty service, send the product only to the Elation Professional factory. All ®...
Page 61
® liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product. G. This warranty is the only written warranty applicable to Elation Professional Products ® and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
