4.0 System Options

The system communicates with the user by illuminating icons in the
LCD display as shown in Figure 2.

4.1 Partition Display

Sections [001] to [008]
You can program the DGP2-640 to
display up to four partitions. Sections
[001] to [004] correspond to partitions
1 to 4 (see Figure 2.
The LCD numbers 1 to 4 are assigned values 001 to 004. To assign
an LCD display number to a partition, choose a section number from
[001] to [008] and assign it a value between 001 and 004 which
represents LCD numbers 1 to 4 respectively.
Do not assign the same display number to more than one
section. For example, you cannot assign value 002 to sections
[003] and [004]. The rejection beep will remind you that a
selected display number is already assigned to another
section. Refer to List of Sections on page 14 for default values.
Example:
LCD number 3 is assigned to partition 3. To reassign LCD number 3
to partition 8 perform the following steps:
1. Enter 003 to select partition 3.
2. Enter 000 to clear the value.
3. Press the
4. Enter 008 to select partition 8.
5. Enter value 003 to reassign LCD number 3 to partition 8.
6. Press the
)
key.
key to exit.
Figure 2: Partition Display
001
002
DGP2-640 Icon LCD Keypad 7
003
004
