Installation/Operator's Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not
use any phone in your building.
* Clear the room, building or area of all
occupants.
* Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
* If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
120299EL/abe
AD-25V
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
* Ne pas tenter d'allumer d'appareil.
* Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez..
* Évacuez la pièce, le bâtiment ou la zone.
* Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
* Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
For replacement parts, contact the distributor from which the dryer
was purchased or
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
ADC Part No. 113042

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. AD-25V

Summary of Contents for American Dryer Corp. AD-25V

  • Page 1 AD-25V Installation/Operator's Manual WARNING: For your safety the AVERTISSEMENT: Assurez-vous de bien information in this manual must be suivre les instructions données dans cette followed to minimize the risk of fire or notice pour réduire au minimum le risque explosion or to prevent property damage, d’incendie ou d’explosion ou pour éviter tout...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models. Important For your convenience, log the following information: AD-25V DATE OF PURCHASE MODEL NO. DISTRIBUTORS NAME Serial Number(s) Replacement parts can be obtained from your distributor or the ADC factory.
  • Page 3 IMPORTANT YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, AD- JUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Oc- cupational Safety and Health Administration) STANDARDS.
  • Page 4 WARNING The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. WARNING DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE...EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. IMPORTANT PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/ or specified in the installation/operator's manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I IMPORTANT INFORMATION ................3 A. Receiving and Handling ....................... 3 B. Safety Precautions ........................4 SECTION II SPECIFICATIONS ....................6 A. Specifications ..........................6 SECTION III INSTALLATION PROCEDURES ..............8 A. Unpacking/Setting Up ......................... 8 B.
  • Page 6 SECTION VI ROUTINE MAINTENANCE ................42 A. Cleaning ........................... 42 B. Adjustments ..........................43 C. Lubrication ..........................43 D. Lint Drawer Removal........................ 44 SECTION VII TROUBLESHOOTING ..................45 Microprocessor (Computer) Models ....................45 Dual Timer Models ......................... 51 SECTION VIII DATA LABEL INFORMATION................

  • Page 7: Important Information

    SECTION I IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden skid should be visually inspected for shipping damage.

  • Page 8: Safety Precautions

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 9 WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvent will create a fire hazard. WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage plastics or rubber and also may be a fire hazard.

  • Page 10: Specifications

    1/2" Shaded areas are stated in metric equivalents AD-25V reversing dryer available with 3-phase (3ø) 1/2 HP [.373 kw] motors standard. Size of piping to dryer varies with installation conditions. Contact factory for assistance. *** Contact factory for information not listed, 3-phase (3ø) figures shown are for 3-wire service.
  • Page 11 Specifications ADG-25V ADE-25V ADS-25V NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.

  • Page 12: Installation Procedures

    SECTION III INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable AMERICAN NATIONAL STANDARDS: ANSI.Z223.1-LATEST EDITION (National Fuel Gas Code) ANSI/NFPA NO. 70-LATEST EDITION (National Electric Code) In CANADA, the installation must conform to CANADIAN STANDARDS: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.

  • Page 13: Location Requirements

    1. Leveling Dryer The dryer is equipped with four (4) leveling legs, one at each corner of the base. Two (2) are located at the rear of the dryer base, and two (2) are located in the lint chamber (coop). To increase bearing life and improve efficiency, the dryer should be tilted slightly to the rear.

  • Page 14: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of 12-inches (30.48 cm) above the dryer's outer top; 18-inches (45.72 cm) for steam dryers, except along the front of the dryer which may be closed if desired. NOTE: Allowances must be made for opening the control door.

  • Page 15: Fresh Air Supply

    D. FRESH AIR SUPPLY The AD-25V air supply (makeup air) must be given careful consideration to assure proper performance of each dryer. An unrestricted source of air is necessary for each dryer. As a general rule, an unrestricted air entrance from the outdoors (atmosphere) of a minimum of one (1) square foot (0.093 square meters) is required for each...

  • Page 16: Exhaust Requirements

    E. EXHAUST REQUIREMENTS Exhaust duct work should be designed and installed by a qualified professional. Improperly sized duct work will create excessive back pressure which results in slow drying, increased use of energy, and shutdown of the burner by the airflow (sail) switch, burner hi-limit, or lint chamber hi-heat protector thermostat. Where possible, it is suggested to provide a separate (single) exhaust duct for each dryer.

  • Page 17: Single Dryer Venting

    SINGLE DRYER VENTING IMPORTANT: For exhaust duct runs over 25 feet (7.62 meters) a minimum size of 10-inches (25.4 cm) must be used. ORIZONTAL ENTING 25 feet When a single 8-inches (20.32 cm) horizontal vent is used, the duct work to the outlet cannot exceed (7.62 meters) 25 feet (7.62 meters) - refer to Illus.
  • Page 18 ERTICAL ENTING When vertical single 10-inch (25.4 cm) venting is used (refer to Illus. B below), the duct work from the dryer to the outside outlet cannot exceed 40 feet (12.19 meters) (refer to Illus. B below). This calculation compensates for the use of a maximum of three (3) elbows including the two (2) elbows creating the 180°...
  • Page 19 MULTIPLE DRYER (Common) VENTING If it is not feasible to provide separate exhaust ducts for each dryer, ducts for individual dryers may be channeled into a common main duct. Each dryer is provided with a back draft damper. The individual ducts should enter the bottom or side of the main duct at an angle not more than 45°...
  • Page 20 ORIZONTAL ENTING Illus. C ERTICAL ENTING Illus. D...
  • Page 21 IMPORTANT VENTING REMINDERS 1. Duct work size and installation should be done by a qualified professional. 2. The dryer must be exhausted to the outdoors. 3. Duct work should be routed as short as possible to the outdoors with as few elbows as possible. 4.

  • Page 22: Electrical Information

    F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electrical connections, material, and workmanship must National Electrical Codes ANSI/NFPA NO.
  • Page 23 2) Electric Models ONLY ALL electrically heated dryers must be connected to the electric service shown on the dryer's data label which is affixed to the back side of the control (service) door. The connecting wires must be properly sized to handle the rated current. NOTE: Electrically heated service (amperage) specifications/requirements not available at the time of printing.
  • Page 24 INGLE HASE Ø LECTRICAL ONNECTIONS EADS Black White Green White Neutral Ground If local codes permit, power to the dryer can be made by the use of a flexible U.L. listed power cord or pigtail (wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker panel.
  • Page 25 5. 3-Phase (3ø) Wiring Connections/Hookup The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, L3, and some- times Neutral) and ground. Single-phase (1ø) power for the control circuit is done internally to the dryer. No single-phase (1ø) input connection is required on a 3-phase (3ø) dryer.
  • Page 26 CAUTION: The dryer must be grounded. A ground lug has been provided for this purpose. IMPORTANT: A CIRCUIT SERVING EACH DRYER MUST BE PROVIDED. The only electrical connections to the dryer are the 3-phase (3ø) leads (L1, L2, L3, and sometimes Neutral) and ground.
  • Page 27 ADG-25V (G ADS-25V (S TEAM LECTRICAL ERVICE PECIFICATIONS PER DRYER IMPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/ verify correct breaker size according to appliance amp draw rating and type of breaker used.

  • Page 28: Gas Information

    G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.
  • Page 29 Part Part Rating Qty. D.M.S.* Qty. D.M.S.* Rating NUMBER Number Number AD-25V 78,000 882267 19,656 140818 140802 Shaded area is stated in metric equivalent * D.M.S. (Drill Material Size) equivalents are as follows: Natural Gas ....#31 = .1200" (3.048mm) Liquid Propane Gas ..
  • Page 30 3. Piping Connections ALL components/materials must conform to National Gas Code, or in Canada, the Canadian Gas Code specifications. It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of ALL the appliance BTU's being supplied. The dryer is provided with a 1/2"...
  • Page 31 Consistent gas pressure is essential at ALL gas connections. It is recommended that a 3/4-inch pipe gas loop be installed in the supply line serving a bank of dryers. An in-line pressure regulator must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 12.0 inches of water column (29.9 mbar) pressure.

  • Page 32: Steam Information

    H. STEAM INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the steam plumbing installation is adequate and conforms with local and state regulations or codes. Care must be exercised when leveling steam dryers into final position. After leveling the dryer, check the downward pitch of the heat exchanger from front to rear with a level.
  • Page 33 a. The pressure of the condensate in the steam supply will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made with a minimum 10-inch (25.4 cm) riser. This will prevent any condensate from draining towards the dryer.
  • Page 34 4. Steam Damper Air System Connections The ADS-25V is manufactured with a pneumatic (piston) damper system which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve which is located at the rear inner top area of the dryer just in front of the electric service relay box.
  • Page 35 5. Steam Damper System Operation The steam damper, as shown in the illustration below, allows the coil to stay constantly charged eliminating repeated expansion and contraction. When the damper is opened, the air immediately passes through the already hot coil, providing instant heat to start the drying process. When the damper is closed, ambient air is drawn directly into the basket (tumbler), allowing a rapid cool down.
  • Page 36 a. Steam Damper Air Piston (Flow Control) Operation Adjustment Damper operation was tested and adjusted prior to shipping at 80 psi (552 kPa). If damper air adjustment is necessary, locate the flow control valve and make the necessary adjustments as noted below.

  • Page 37: Preparation For Operation/Start-Up

    I. PREPARATION FOR OPERATION/START-UP The following items should be checked before attempting to operate the dryer: 1. Read ALL "CAUTION," "WARNING," and "DIRECTION" labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label affixed to the back side of the top front control/service door.

  • Page 38: Preoperational Tests

    J. PREOPERATIONAL TESTS ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.

  • Page 39: Preoperational Instructions

    NOTE: The sail switch can be checked for proper operation by opening the lint drawer. While pushing the lint drawer switch in, start a drying cycle. The heating unit should not activate (wait 30- seconds). If heat does activate, make the necessary adjustments to the sail switch. 5.
  • Page 40 d. Once the preprogrammed dryness level and cool down period have been reached, or the maximum automatic time has expired, the tone (buzzer) will sound for 5-seconds, and the L.E.D. (light emitting diode) display will read "donE", at which time the dryer will shut off. NOTES: 1.
  • Page 41 b. Select Temperature... The dryer will start, the L.E.D. (light emitting diode) display will read the temperature cycle selected, and the drying time portion of the L.E.D. display will read "00" and count upward as time elapses, or the vended time will count downward, depending on the program parameter setting. IMPORTANT: If the door is opened during a cycle, both the heat and motor will stop.

  • Page 42: Shut Down Instructions

    2) Press the "E" on the touchpad of the keyboard. 3) The L.E.D. (light emitting diode) display will quickly show "Ld30," "LC04," "F180." The dryer will start, and the L.E.D. display will show "dr30." b. Dual Timer Dryers 1) Turn drying timer knob for a time of 20 minutes. 2) Select "High Temp."...

  • Page 43: Service/Parts Information

    SECTION IV SERVICE/PARTS INFORMATION A. SERVICE 1. Only properly licensed or trained technicians should service the dryer. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Service Department for a distributor in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.

  • Page 44: Warranty Information

    SECTION V WARRANTY INFORMATION A. RETURNING WARRANTY CARD(S) 1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you, if you file a warranty claim.
  • Page 45 e. Specify whether the part(s) being returned is for a replacement, a credit, or a refund. NOTE: If a part is marked for a credit or a refund, the invoice number covering the purchase of the replacement part must be provided. NOTE: Warranty tags (ADC Part No.

  • Page 46: Routine Maintenance

    SECTION VI ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location.

  • Page 47: Adjustments

    STEAM DRYERS Clean the steam coil fins. We suggest using compressed air and a vacuum cleaner with brush attachment. WARNING: When cleaning steam coil fins, be careful not to bend the fins. If fins are bent, straighten by using a fin comb which is available from local air-conditioning supply houses. 90 DAYS Inspect and remove lint accumulation in customer-furnished exhaust duct work system and from dryer's internal exhaust ducting.

  • Page 48: Lint Drawer Removal

    D. LINT DRAWER REMOVAL To remove the lint drawer from the dryer pull drawer out approximately halfway. Rotate/move lint drawer stop hinge (refer to the illustration below) downward and pull the drawer out. IMPORTANT: After replacing the lint drawer back into the dryer, be sure to rotate/move hinge back to the upward stop position.

  • Page 49: Troubleshooting

    SECTION VII TROUBLESHOOTING IMPORTANT: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 50 4. Failed microprocessor controller (computer). . Drive motor (reversing) operates in one direction only...stops and restarts in same direction... 1. Failed drive motor contactor (relay). 2. Failed arc suppressor (A.S.) board (for Reversing Models Only). 3. Failed microprocessor controller (computer). D.
  • Page 51 3. Failed arc suppressor (A.S.) board (for Reversing Models Only). 4. Failed microprocessor controller (computer). 5. Failed 24 VAC transformer. H. Both drive motor and blower motor run a few minutes and then stop...microprocessor controller (computer) display continues to read time or percent of extraction and ALL indicator dots are off...
  • Page 52 M. Microprocessor controller (computer) locks up and the L.E.D. (light emitting diode) display reads erroneous message(s) or only partial segments... 1. Transient power voltage (spikes)...disconnect power to dryer, wait one (1) minute, and reestablish power to dryer. If problem is still evident ... a.
  • Page 53 3. Fault in lint chamber sensor bracket or tripped manual reset hi-heat protector thermostat. 4. Failed Direct Spark Ignition (DSI) module. 5. Failed DSI (Direct Spark Ignition) ignitor/flame-probe assembly. 6. Failed microprocessor controller (computer). LECTRIC ODELS 1. Fault in sail switch circuit ... a.
  • Page 54 3. Low and/or inconsistent gas pressure (for GAS MODELS ONLY). 4. Insufficient make-up air. 5. Poor air/ gas mixture at burner...yellow or poor flame pattern; adjust gas burner air adjustment shutters (for GAS MODELS ONLY). 6. Lint screen not being cleaned on a regular basis or often enough. 7.

  • Page 55: Dual Timer Models

    2. Impellor (fan/blower) out of balance ... a. Excessive lint build up on impellor (fan/blower). b. Failed impellor (fan/blower). 3. Loose basket (tumbler) tie rod. 4. Basket out of adjustment, or adjustment bolts (hardware) are loose. 5. Failed basket (tumbler) support. 6.
  • Page 56 C. Blower motor (only) is not operating... 1. Failed impellor (fan/blower) motor contactor (relay). 2. Failed blower (impellor/fan) motor. D. Both drive and blower motors is not operating (indicator light is on)... 1. Fault with L1 termination at reversing timer (for Reversing Models Only). 2.
  • Page 57 3. Tripped lint compartment manual reset (225º F [107º C]) safety thermostat circuit. 4. Failed oven contactor/relay. 5. Failed heat selector switch. TEAM ODELS 1. Steam damper binding and/or stuck. º º 2. Tripped lint compartment manual reset (225 F [107 C]) safety thermostat circuit.
  • Page 58 11. Fault in electric oven element circuit (for Electric Models Only) ... a. Failed element(s). b. Failed oven contactor (relay). 12. Exceptionally cold/humid or low barometric pressure atmosphere. 13. Blower (impellor/fan) motor rotation direction is incorrect. I. Dryer is cycling on or tripping hi-limit thermostat (for Gas and Electric Models Only)... 1.

  • Page 59: Data Label Information

    SECTION VIII DATA LABEL INFORMATION A. DATA LABEL Contact American Dryer Corporation When contacting American Dryer Corporation certain information is required to insure proper service/parts information from American Dryer. This information is on the data label located on the inside of the control door. When contacting ADC please have the model number and serial number available.
  • Page 60 THE DATA LABEL 1. MODEL NUMBER The model number is an ADC number which describes the size of the dryer and the type of heat (gas, electric, or steam). 2. SERIAL NUMBER The serial number allows ADC to gather information on your particular dryer. 3.

  • Page 61: Reversing Timer Spin/Dwell Adjustments

    SECTION IX REVERSING TIMER SPIN/DWELL ADJUSTMENTS Dual timer models with "reversing option" have an electric reversing timer in the electric service box which is located in the upper rear area of the dryer. Both the dwell (stop) time and basket (tumbler) spin time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below).

  • Page 62: Procedure For Functional Check Of Replacement Components

    SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor (computer) Board a. Upon completing installation of the replacement microprocessor (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motor(s) and the heat indicator dots, in the microprocessor (computer) L.E.D. (light emitting diode) display are on.
  • Page 63 e. Open main door. The dryer must stop and ALL output indicator lights on the back side of the microprocessor (computer) board must go out. (Refer to illustration on previous page [page 58].) f. Try to restart the dryer with the main door open. g.
  • Page 64 b. For models with Johnson Controls DSI (Direct Spark Ignition) Module (G760) Theory Of Operation; Start the drying cycle. When the gas burner ignites within the chosen trial for ignition time (6-seconds), the flame sensor detects gas burner flame and signals the Direct Spark Ignition (DSI) module to keep the gas valve open...as long as there is a call for heat.

  • Page 65: Burner And Lint (Tumbler) Chamber Manual Reset Hi-Limit Instructions

    SECTION XI BURNER AND LINT (TUMBLER) CHAMBER MANUAL RESET HI-LIMIT INSTRUCTIONS I M P O R T A N T MANUAL RESET HI-LIMIT INSTRUCTIONS FOR DUAL TIMER OR PHASE 5 WITHOUT HEAT FAULT (GAS MODELS ONLY) This dryer was manufactured with a manual reset burner hi-limit and tumbler/lint chamber hi-limit thermostat.

  • Page 66: Electric Or Steam

    I M P O R T A N T MANUAL RESET HI-LIMIT INSTRUCTIONS FOR DUAL TIMER OR PHASE 5 WITHOUT HEAT FAULT (ELECTRIC or STEAM) This dryer was manufactured with a manual reset tumbler/lint chamber hi-limit thermostat. If the manual reset thermostat is open prior to the start of the drying cycle, or during the cycle, the dryer will not recognize the open state of the hi-limit thermostat and will start or continue through the drying cycle with no heat.
