AD-25V
Parts Manual
24 VAC Phase 5
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 450342 - 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-25V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dryer Corp. AD-25V

Summary of Contents for American Dryer Corp. AD-25V

  • Page 1 AD-25V Parts Manual 24 VAC Phase 5 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450342 - 4...
  • Page 2 POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. Important AD-25V MODEL NO. ______________...

  • Page 3: Table Of Contents

    Table of Contents Non-Coin Control Door Assembly for Models Mfd. as of July 1, 2002 ... 4 Coin Control Door Assembly for Models Mfd. as of July 1, 2002 ... 5 Control Door Assembly for Models Mfd. prior to July 1, 2002 ... 6 Phase 5 Non-Coin Microprocessor Control Panel Assembly ...

  • Page 4: Non-Coin Control Door Assembly For Models Mfd. As Of July 1, 2002

    Non-Coin Control Door Assembly For Models Mfd. as of July 1, 2002 Illus. No. Part No. Qty. Description 881053 ADC Logo with Tape 870011 Double Sided Tape Kit 883550 White Control Door Assembly (includes illus. nos. 2 and 3) 883551 Ivory Control Door Assembly (includes illus.

  • Page 5: Coin Control Door Assembly For Models Mfd. As Of July 1, 2002

    Illus. No. Part No. Qty. Description 160015 High Security Lock Assembly 160104 Key ONLY 160016 Lock Cam ONLY 881053 ADC Logo with Tape 883477 White Control Door Assembly with Black Trim (includes illus. nos. 4 through 7) 883478 Ivory Control Door with Black Trim (includes illus.

  • Page 6: Control Door Assembly For Models Mfd. Prior To July 1, 2002

    Control Door Assembly For Models Mfd. prior to July 1, 2002 Illus. No. Part No. Qty. Description 160015 High Security MK-100 Lock Assembly with Key (for coin models Only) 160017 Special Dummy Lock ONLY (for non-coin models Only) 160104 MK-100 Key ONLY 160052 Lock Cam ONLY 881053...

  • Page 7: Phase 5 Non-Coin Microprocessor Control Panel Assembly

    Phase 5 Non-Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 Non-Coin English Keypad Label Assembly 112276 Non-Coin Stick-On Labels (English Only) … Not Illustrated 112275 3-Language Non-Coin Stick-On Label (Spanish, Italian, and Hebrew) … Not Illustrated 112277 3-Language Non-Coin Stick-On Label (English, Spanish, and Hebrew) …...

  • Page 8: Phase 5 Coin Microprocessor Control Panel Assembly

    Phase 5 Coin Microprocessor Control Panel Assembly American Dryer Corporation 450342 - 4...
  • Page 9 Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keypad Label Assembly 883537 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, and 4 through 6) (for models mfd. as of June 25, 2002) 883538 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus.

  • Page 10: Coin And Non-Coin Control Box Assembly

    Coin and Non-Coin Control Box Assembly Illus. No. Part No. Qty. Description 132002 Transformer (for mechanical steam dampers 208 VAC and higher) 150300 #10-16 x 1/2” Hex Washer TEK Screw 150301 #8 x 7/16” Phillips Pan Head TEK Screw 131931 Steam Valve Relay –...

  • Page 11: Coin Vault Assembly

    Illus. No. Part No. Qty. Description 802112 Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 5) 802117 Microprocessor Coin Vault ONLY 802110 Non-Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 5) 802115 Non-Microprocessor Coin Vault ONLY 160028 Cam for 1/4 Turn Lock ONLY 875061...

  • Page 12: Dual Timer "Tap Touch" Controls For Models Mfd. As Of November 1, 2000

    Dual Timer “Tap Touch” Controls For Models Mfd. as of November 1, 2000 Illus. No. Part No. Qty. Description 824298 15 Minute Timer – 24 VAC 824299 60 Minute Timer – 24 VAC 824175 Red Pilot Light – 24 VAC 122301 “Tap Touch”...

  • Page 13: Dual Timer Control Panel Assembly For Models Mfd. Prior To November 1, 2000

    Illus. No. Part No. Qty. Description 123005 Red Indicator Light – 24 VAC 122400 Rocker Heat Selector Switch 882596 Dual Timer Control Panel Assembly Complete – 24 VAC (includes illus. nos. 1 through 16) 882600 Dual Timer Reversing Control Panel Assembly Complete – 24 VAC (includes illus.

  • Page 14: Non-Microprocessor Coin Meter Control Panel Assembly For Models Mfd. As Of January 25, 2002

    Non-Microprocessor Coin Meter Control Panel Assembly For Models Mfd. as of January 25, 2002 Illus. No. Part No. Qty. Description 123005 Red Indicator Light – 24 VAC 122400 Rocker Heat Selector Switch 824172 Coin Meter Control Panel Assembly Less Coin Meter (includes illus.

  • Page 15: Non-Microprocessor Coin Meter Control Panel Assembly For Models Mfd. Prior To January 25, 2002

    Non-Microprocessor Coin Meter Control Panel Assembly Illus. No. Part No. Qty. Description 123005 Red Indicator Light – 24 VAC 122400 Rocker Heat Selector Switch 824020 Coin Meter Control Panel Assembly Complete – 24 VAC (includes illus. nos. 1 through 6 and 8 through 12) 800054 Coin Meter Control Panel ONLY 131917...

  • Page 16: Front Panel Assembly For Models Mfd. With Steel Main Door As Of July 1, 2002

    Front Panel Assembly For Models Mfd. with Steel Main Door as of July 1, 2002 Illus. No. Part No. Qty. Description 883567 White Front Panel Assembly (includes illus. nos. 1, 5, and 6) 883568 Ivory Front Panel Assembly (includes illus. nos. 1, 5, and 6) 883569 Coral Blue Front Panel Assembly (includes illus.

  • Page 17: Front Panel Assembly For Models Mfd. With Steel Main Door Prior To July 1, 2002

    Illus. No. Part No. Qty. Description 883137 White Front Panel Assembly (includes illus. nos. 1, 5, and 6) 883138 Coral Blue Front Panel Assembly (includes illus. nos. 1, 5, and 6) 883139 Ivory Front Panel Assembly (includes illus. nos. 1, 5, and 6) 150313 #10-16 x 1/2”...

  • Page 18: Front Panel Assembly For Models Mfd. With Plastic Main Door

    Front Panel Assembly For Models Mfd. with Plastic Main Door Illus. No. Part No. Qty. Description 882529 White Front Panel Assembly (includes illus. nos. 1, 3, 5, and 6) 882530 Almond B Front Panel Assembly (includes illus. nos. 1, 3, 5, and 6) 882531 Coral Blue Front Panel Assembly (includes illus.

  • Page 19: Main Door "Steel" Assembly

    Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170731 Black Gasket Adhesive (10.3 oz. cartridge) 881152 Black Top Hinge Block Assembly (includes illus. nos. 3 and 4) 150445 1/4-20 x 3/4”...

  • Page 20: Plastic Main Door Assembly

    Plastic Main Door Assembly Illus. No. Part No. Qty. Description 881422 Black Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 800448 12-1/2” Stainless Steel Main Door Hinge Assembly 150410 #10-24 x 3/8” Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102349...

  • Page 21: Main Door Switch Assembly For Models Mfd. With Steel Main Door

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Door Switch 122636 Flag Terminal 881211 Black Main Door Switch Housing ONLY 881153 Black Main Door Switch Housing Complete (includes illus.

  • Page 22: Main Door Switch For Models Mfd. With Plastic Main Door

    Main Door Switch For Models Mfd. with Plastic Main Door Illus. No. Part No. Qty. Description 152013 #6-32 Hex Nut 153008 #6 Lock Washer 137005 Single Pole Door Switch 121028 Insulated Female Terminal 154281 3/8” Standard Nylon Spacer 800448 12-1/2” Stainless Steel Main Door Hinge Assembly (includes illus.

  • Page 23: Tumbler / Support Assemblies

    Illus. No. Part No. Qty. Description 800702 Galvanized Tumbler ONLY (without felt collar) 817085 Galvanized Tumbler / Support Assemblies Complete (includes illus. nos. 1 through 10) 800731 Stainless Steel Tumbler ONLY (without felt collar) 800752 Stainless Steel Tumbler / Support Assemblies Complete (includes illus.

  • Page 24: Drop Lint Door Assembly For Models Mfd. As Of July 1, 2002

    Drop Lint Door Assembly For Models Mfd. as of July 1, 2002 Illus. No. Part No. Qty. Description 802277 Drop Lint Door (for non-coin models) (includes illus. nos. 1 through 3) 802265 Drop Lint Door (for coin models) (includes illus. nos. 1, 2, and 4) 117604 Sponge Tape (sold by the foot) 170226...

  • Page 25: Lint Trap Assembly For Models Mfd. As Of July 1, 2002

    Illus. No. Part No. Qty. Description 801070 Lint Trap Assembly Complete (for 60 Hz units) (includes illus. nos. 1 and 3 through 5) 800401 Lint Trap Assembly Complete (for 50 Hz units) (includes illus. nos. 1 and 3 through 5) 801069 Lint Trap ONLY (for 60 Hz units) 800443...

  • Page 26: Lint Drawer / Lint Drawer Switch Assembly For Models Mfd. Between July 25, 2000 And July 1, 2002

    Lint Drawer / Lint Drawer Switch Assembly For Models Mfd. between July 25, 2000 and July 1, 2002 Illus. No. Part No. Qty. Description 883140 White Lint Drawer Assembly (includes illus. nos. 1 and 2) 883136 Coral Blue Lint Drawer Assembly (includes illus.

  • Page 27: Lint Drawer / Lint Drawer Switch Assemblies For Models Mfd. Prior To July 25, 2000

    Illus. No. Part No. Qty. Description 882616 White Lint Drawer Assembly (includes illus. nos. 1 and 2) 882614 Almond B Lint Drawer Assembly (includes illus. nos. 1 and 2) 882615 Coral Blue Lint Drawer Assembly (includes illus. nos. 1 and 2) 117605 Noise Suppressor Tape (sold by the foot) 108223...

  • Page 28: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100107 5L-670 V-Belt (tumbler to idler) (for non-reversing models Only) 100108 5L-680 V-Belt (tumbler to idler) (for reversing models Only) 101129 9” x 2-1/2” Compound Pulley 100103 4L-510 V-Belt (for non-reversing models Only) 100112 4L-610 V-Belt (idler to motor) (for reversing models Only)

  • Page 29: Tumbler Bearing Assembly

    Illus. No. Part No. Qty. Description 153002 5/16” Lock Washer 880213 1-1/4” Flange Bearing with Nylock Setscrew 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 150501 5/16-18 x 3/4” Hex Head Machine Bolt 153002 5/16” Lock Washer 153004 3/8” Flat Washer 801100 1”...

  • Page 30: Non-Reversing Motor Mount Assembly

    Non-Reversing Motor Mount Assembly American Dryer Corporation 450342 - 4...
  • Page 31 Illus. No. Part No. Qty. Description 100103 4L-510 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key (for use on 3ø models Only) 101104 1/2” x 2” Motor Pulley (for use on 1ø – 60 Hz motors Only) 101132 5/8”...

  • Page 32: Reversing Motor Mount Assembly

    Reversing Motor Mount Assembly American Dryer Corporation 450342 - 4...
  • Page 33 Illus. No. Part No. Qty. Description 100112 4L-610 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101132 5/8” x 2” Motor Pulley (for 60 Hz models Only) 101133 5/8” x 2-1/4” Motor Pulley (for 50 Hz models Only) 120200 3/8”...

  • Page 34: Sensor Bracket Assemblies For Models Mfd. As Of July 1, 2002

    Sensor Bracket Assemblies For Models Mfd. as of July 1, 2002 American Dryer Corporation 450342 - 4...

  • Page 35: Sensor Bracket Assemblies

    Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130301 225° Large Manual Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605 4-Pin Socket Connector ONLY 154007...

  • Page 36: Sensor Bracket Assemblies For Models Mfd. Prior To July 1, 2002

    Sensor Bracket Assemblies For Models Mfd. prior to July 1, 2002 American Dryer Corporation 450342 - 4...
  • Page 37 Illus. No. Part No. Qty. Description 882533 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 7) 130301 225° Manual Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605 4-Pin Socket Connector ONLY 154007...

  • Page 38: Gas Burner Assembly For Models Mfd. As Of September 29, 2000

    (includes illus. nos. 1 through 3 and 5 through 18) 817088 Direct Spark Ignition Burner Box ONLY 882267 AD-25V Liquid Propane Conversion Kit (includes orifices) 880604*** Steam to Gas Interface Assembly * Consult factory for elevations over 2,000 feet. ** Burner orifices are not included and must be ordered separately.

  • Page 39: Direct Spark Ignition Burner Assembly For Models Mfd. Prior To September 29, 2000

    817088 Direct Spark Ignition Burner Box ONLY — 882267 AD-25V Liquid Propane Conversion Kit (includes orifices) 882604 Steam to Gas Interface Assembly * Consult factory for elevations over 2,000 feet. ** Burner orifices are not included and must be ordered separately.

  • Page 40: Electric Oven Assembly

    Electric Oven Assembly American Dryer Corporation 450342 - 4...
  • Page 41 Illus. No. Part No. Qty. Description 803003* Small Electric Oven Box ONLY ––––––* Electric Oven Assembly Complete ––––––* – Electric Element 150300 #10-16 x 1/2” Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Box Assembly Complete (includes illus.

  • Page 42: Sail Switch / Hi-Limit Assemblies

    Sail Switch / Hi-Limit Assemblies Illus. No. Part No. Qty. Description 154004 Twin Speed Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 802799 Sail Switch Box Cover and Bracket ONLY 150303 #4 x 3/4” Pan Head “A” Machine Screw 122200 Sail Switch ONLY 105500...

  • Page 43: Single-Phase (1Ø) Motor, Electric Relay Panel Assembly

    Single-Phase (1Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 151000 #6-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120716 2-Position Terminal Block 322817 Rear Electric Mounting Plate ONLY 882662 Rear Electric Panel Assembly Complete –...

  • Page 44: 3-Phase (3Ø) Motor, Electric Relay Panel Assembly

    3-Phase (3Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 151000 #6-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block (for models mfd. with 3ø motors) 120716 2-Position Terminal Block (for models mfd.

  • Page 45: 460-480 Vac 3-Phase (3Ø) Motor, Electric Relay Panel Assembly

    460-480 VAC 3-Phase (3Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150009 #6-32 x 1-1/2” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block 830208 Transformer Assembly (460 VAC) for Micro Models ONLY 824161 Transformer Assembly (460 VAC) for Non-Micro Models ONLY 135501 1-Amp Double-Pole Circuit Breaker (460 VAC Only) 120768...

  • Page 46: Reversing Electric Relay Panel Assembly

    Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block 132458 3-Pole Reversing Contactor 882653 Transformer Assembly – 208-240 Volt for Gas and Steam Models ONLY 825428 Transformer Assembly –...

  • Page 47: 460-480 Vac Reversing Electric Relay Panel Assembly

    460-480 VAC Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 132458 24 VAC Reversing Contactor 150297 #10 x 1/2” Hex Head TEK Screw (green) 121010 L-70 Ground Lug 152004 5/16-18 Hex Nut 153002 5/16” Lock Washer 132459 24 VAC 3-Pole Blower Contactor 150300 #10-16 x 1/2”...

  • Page 48: Steam Coil / Air-Operated Steam Damper Assembly

    Steam Coil / Air-Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165013 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 880835 Steam Damper Assembly (includes illus.

  • Page 49: Steam Coil / Mechanical Steam Damper Assembly

    Illus. No. Part No. Qty. Description 165013 Steam Coil Assembly ONLY 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 880835 Steam Damper Assembly (includes illus. nos. 7 through 9) 115995 Steam Damper Gasket (sold by the inch) 102350...

  • Page 50: Outer Top / Back Guard Assemblies

    Outer Top / Back Guard Assemblies Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 314424 Gas Top Back Guard 322075 Electric Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150300 #10-16 x 1/2”...

  • Page 51: Microprocessor Coin Acceptors Listing

    NOTE: Coin acceptors listed include optical switch. Replacement optic switch for Hanke acceptors is Part No. 881143. Replacement optic switch for Greenwald acceptors is Part No. 137056. ADC Part No. Nation 883363 United States 882689 United States 125100 U.S. and Canada 125107 Australia 881768...

  • Page 52: Coin Meter Replacement Parts

    Coin Meter Replacement Parts Illus. No. Part No. Qty. Description 125541 1/60 RPM 24 VAC / 60 Hz Meter Motor 125540 1/30 RPM 24 VAC / 50 Hz Meter Motor 125500 2-Point Cam 125501 3-Point Cam 125502 4-Point Cam 125503 5-Point Cam 125504 6-Point Cam...

  • Page 53: Electrical Oven Component Application Chart

    Oven Voltage Phase Wire Assembly Part No. 460/480 3Ø 3 or 4 824951 3Ø 3 or 4 826394 3Ø 883557 3Ø 3 or 4 824915 3Ø 3 or 4 826243 1Ø 883559 1Ø 883561 460/480 3Ø 3 or 4 883560 3Ø...

  • Page 54: Additional Parts Available

    Additional Parts Available Part No. Description 114006 “WARNING – Fire Hazards” Label 112280 “Clean Lint Screen” Label 114001 “CAUTION – Exhaust / Lint Screen” Label 112533 “Phase 5 Coin Program Location Summary” Label 112534 “Phase 5 OPL Program Location Summary” Label 120100 3/8”...
  • Page 55 Notes 450342 - 4 www.amdry.com...
  • Page 56 ADC Part No. 450342 4 - 09/09/08 - 0...
