American Dryer Corp. AD-235ED Parts Manual

American Dryer Corp. AD-235ED Parts Manual

24 vac phase 5 1999/2000
Hide thumbs Also See for AD-235ED:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
AD-235ED Parts Manual
24 VAC Phase 5
1999/2000
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail:
techsupport@amdry.com
ADC Part No. 450422

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-235ED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dryer Corp. AD-235ED

Summary of Contents for American Dryer Corp. AD-235ED

  • Page 1 AD-235ED Parts Manual 24 VAC Phase 5 1999/2000 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com ADC Part No. 450422...
  • Page 2 These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. Important MODEL NO. __________________________________________ AD-235ED...

  • Page 3: Table Of Contents

    Table of Contents Locking Control Door Assembly For Models Mfd. as of December 14, 1999 ... 2 Control Door Assembly For Models Mfd. prior to December 14, 1999 ... 3 Coin Microprocessor Control Panel/Box Assemblies For Models Mfd. as of December 2, 1999 ... 4, 5 Coin Microprocessor Control Panel/Box Assemblies For Models Mfd.

  • Page 4: Locking Control Door Assembly

    Illus. No. Part No. Qty. Description 882463 White Locking Control Door Complete (includes illus. nos. 1, 2, and 3) 882464 Almond Locking Control Door Complete (includes illus. nos. 1, 2, and 3) 882465 Blue Locking Control Door Complete (includes illus. nos. 1, 2, and 3) 882601 Black Trim (for models mfd.

  • Page 5: Control Door Assembly

    Control Door Assembly For Models Mfd. prior to December 14, 1999 Illus. No. Part No. Qty. 882413 882412 882414 882415 882416 882417 150212 150309 152103 450422-3 Telephone: (508) 678-9000 / Description Almond “ADC” Control Door White “ADC” Control Door Blue “ADC” Control Door White Control Door Almond Control Door Blue Control Door...

  • Page 6: Coin Microprocessor Control Panel/Box Assemblies

    Illus. No. Part No. Qty. 112526 882469 882472 882473 882474 160042 160136* ------- 881163** Coin Microprocessor Control Panel/Box Assemblies For Models Mfd. as of December 2, 1999 NOTE: Duplicate ALL components for right hand side of control box. Description Coin Keyboard (touch pad) Label Assembly Control Panel Assembly Less Acceptor (includes illus.

  • Page 7: Coin Microprocessor Control Panel/Box Assemblies

    Coin Microprocessor Control Panel/Box Assemblies For Models Mfd. as of December 2, 1999 Illus. No. Part No. Qty. 137021*** 137023** 880772 824080 137213 824998 153010 150005 122706*** 122641 122800 136057 1 or 2 150002 1 or 2 136008 1 or 2 826329 826326 150301...

  • Page 8: Top Front Panel Assembly

    Illus. No. Part No. Qty. 800692* 154215 170330 881053 870011 150313 150309 400505 121405 * Specify color when ordering. Description Right Hand Insulated Front Panel Assembly (includes illus. nos. 1, 2, 3, and 6) 1/8” Pop Rivet Friction Door Latch ADC Logo (with adhesive tape) Logo Double Tape Kit #10-16 x 1/2”...

  • Page 9: Bottom Front Panel Assembly

    Bottom Front Panel Assembly Illus. No. Part No. Qty. 882418 882419 882420 882432 882433 882434 154215 170330 315187 150313 150309 400505 121405 882602 450422-3 Telephone: (508) 678-9000 / Description Insulated White Bottom Front Panel With Trim (includes illus. nos. 1 through 6) Insulated Almond Bottom Front Panel With Trim (includes illus.

  • Page 10: Main Door Switch Assembly

    Illus. No. Part No. Qty. 152012 153008 137005 121028 154281 800448 153565 881246 150201 121405 NOTE: Duplicate ALL components for Description #6-32 Hex Nut #6 Lock Washer Single Pole Door Switch Insulated Female Terminal 3/8” Standard Nylon Spacer 12-1/2” Stainless Steel Main Door Hinge (includes illus.

  • Page 11: Main Door Assembly

    Main Door Assembly Illus. No. Part No. Qty. 881422 800448 150410 152014 102353 102212 170730 150448 170319 150431 450422-3 Telephone: (508) 678-9000 / Description Black Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 12-1/2”...

  • Page 12: Basket (Tumbler)/Support Assembly

    Illus. No. Part No. Qty. Description 800831 Basket (tumbler) and Support Assembly Complete with Felt Collar (includes illus. nos. 1 through 11) 800721* Basket (tumbler) ONLY (includes illus. nos. 1, 2, and 6) 800891 Stainless Steel Basket (tumbler) and Support Assembly Complete with Felt Collar (includes illus.

  • Page 13: Lint Drawer Assembly

    Lint Drawer Assembly Illus. No. Part No. Qty. 882421 882422 882423 882479 882480 882481 882478 450422-3 Telephone: (508) 678-9000 / Description Locking External White Lint Drawer Locking External Almond Lint Drawer Locking External Blue Lint Drawer External White Lint Drawer External Almond Lint Drawer External Blue Lint Drawer Lint Drawer Lock Assembly (with MK-100 key)

  • Page 14: Lint Drawer Switch Assembly

    Illus. No. Part No. Qty. 800972 122002* 150301 Note: duplicate lint drawer switch for upper pocket). Lint Drawer Switch Assembly Description Lint Drawer Switch Box (for bottom pocket Only) Lint Drawer Switch #8-18 x 7/16” Phillips Pan Head TEK Screw ... Not Illustrated (for bottom pocket Only) American Dryer Corporation 450422-3...

  • Page 15: Upper Pocket Sensor Bracket Assembly

    Upper Pocket Sensor Bracket Assembly Illus. No. Part No. Qty. Description 882931 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 through 4) 122605 4-Pin Socket Connector ONLY 122701 Socket Terminal ONLY 154007 1/4” Tinnerman Push On Fastener 150000 #6-32 x 1/4” Round Head Machine Screw 801428 Sensor Bracket Assembly Complete (includes illus.

  • Page 16: Lower Pocket Sensor Bracket Assembly

    Illlus. No. Part No. Qty. Description 800770 Temperature Sensor Bracket ONLY 882727 Temperature Sensor Bracket Complete (includes illus. nos. 1 through 11) 882931 Temperature Sensor Probe 130112 225º Automatic Reset Thermostat 150000 #6-32 x 1/4” Round Head Machine Screw 153010 #6 Star Washer 152000 #6-32 Hex Nut...

  • Page 17: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100111 5L-650 V-Belt (to basket [tumbler] pulley) (for models mfd. as of March 13, 2000) 100100 5L-660 V-Belt (to basket [tumbler] pulley) (for models mfd. prior to March 13, 2000) 101129 9”...

  • Page 18: Basket (Tumbler) Bearing Assembly

    Basket (Tumbler) Bearing Assembly American Dryer Corporation 450422-3...

  • Page 19: Basket (Tumbler) Bearing Assembly

    Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. 880203 153005 152005 882544 882545 882542 882543 880202 880779 150601 153004 153004 153005 152005 154326 152004 150621 153002 153004 150501 102120 824807 100713 101100 100111 100100 450422-3 Telephone: (508) 678-9000 / Description 1-3/8”...

  • Page 20: Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly

    Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. 100604 152006 153050 100702 153050 117604 Description 12-1/2” Impellor with 1/2” Bore 1/2-20 Left Hand Jam Nut 1/2” S.A.E. Flat Washer 1/8” x 1/8” x 1-1/2” Key 1/2” S.A.E. Flat Washer Neoprene Sponge Tape (sold by the foot) American Dryer Corporation 450422-3...
  • Page 21 Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. 850019 803963 803961 803902** 880848** 150501 153002 153001 154000 100065 100066 150501 153002 153001 153001 101131 101133 101130 100113 100115 122701 137030 122801 837005 837006 100007 120200 100701 As required.

  • Page 22: Direct Spark Ignition (Dsi) Gas Valve/Burner Assembly

    Direct Spark Ignition (DSI) Gas Valve/Burner Assembly Illus. No. Part No. Qty. 850804 809313* 809314* 150300 881367 318650 Description Direct Spark Ignition (DSI) Gas Valve/Burner Tube Mounting Plate ONLY Direct Spark Ignition (DSI) (natural gas) Gas Valve/Burner Assembly Complete Less Orifice (includes illus.
  • Page 23 Direct Spark Ignition (DSI) Gas Valve/Burner Assembly Illus. No. Part No. Qty. 150301 128927 140411 318650 150301 141235 140828 140811 153000 152001 141130 318009 141109 150315 128917 305412 128918 121006 132607 121028 882627 880815 151000 835045 801013 152014 --------- 874059** Burner orifice is not included and must be ordered separately.

  • Page 24: Gas Piping Assembly

    Illus. No. Part No. Qty. 318702 150300 141236 881367 Description Top Pipe Support Bracket ONLY #10 x 1/2” Hex Washer TEK Screw Gas Piping Manifold Union Shutoff with 1/2” Tail Piece American Dryer Corporation Gas Piping Assembly 450422-3...

  • Page 25: Gas Burner Assembly

    Gas Burner Assembly Illus. No. Part No. Qty. 804025 318006 150300 802502 319710 150301 150001 130301 151000 450422-3 Telephone: (508) 678-9000 / Description Gas Burner/Electric Oven Chamber Assembly (includes illus. nos. 1, 2, and 3) Flame Viewing Plate #10 x 1/2” Hex Washer TEK Screw Hi-Limit Bracket Assembly (includes illus.

  • Page 26: Sail Switch Assembly

    Illus. No. Part No. Qty. 150301 802800 154004 150415 802799 122200 150303 105500 319206 154002 Description #8-18 x 7/16” Phillips Pan Head TEK Screw Sail Switch Box with Cover and Bracket ONLY (includes illus. nos. 2, 4, and 5) Twin Speed Nut #10-16 x 1/2”...

  • Page 27: 3-Phase (3Ø) Motor, Electrical Relay Panel Assembly

    3-Phase (3Ø) Motor, Electrical Relay Panel Assembly Illus. No. Part No. Qty. 150300 321002 137015 132430 150100 150300 151001 311920 850909 450422-3 Telephone: (508) 678-9000 / Description #10 x 1/2” Hex Washer TEK Screw Electrical Relay Panel Cover ONLY Arc Suppressor (A.S.) Board (capacitor) ONLY (208/230/240v, 50/60 Hz) Impellor Contactor Coil - 24 VAC #8-32 x 1/2”...

  • Page 28: Back Guard Assembly

    Illus. No. Part No. Qty. 311014 150301 318702 150300 103500 Description Upper/Lower Back Guard Assembly #8-18 x 7/16” Phillips Pan Head TEK Screw Top Pipe Support Bracket ONLY #10 x 1/2” Hex Washer TEK Screw Adjustable Leveling Leg American Dryer Corporation Back Guard Assembly 450422-3...

  • Page 29: Exhaust Ducting Assembly

    Exhaust Ducting Assembly Illus. No. Part No. Qty. 880505 143527 143539 143537 143538 143536 121104 121105 150301 315025 150300 121104 121105 150301 143536 315025 150300 117505 As required. 450422-3 Telephone: (508) 678-9000 / Description Wye Branch Damper Assembly 6” Round x 7” Oval Straight Boot 15-1/2”...

  • Page 30: Microprocessor Coin Acceptor Listing

    Microprocessor Coin Acceptor Listing NOTE: Coin acceptor listed includes optical switch (Hanke includes Part No. 881143). Single Coin Part Number Nation Description 881163 United States and Canada 25¢ Hanke Coin Acceptor *FOR COIN ACCEPTORS NOT SHOWN CONSULT FACTORY FOR AVAILABILITY American Dryer Corporation 450422-3...

  • Page 31: Additional Parts Available

    Additional Parts Available Part No. Description 112039 “Black/White/Green Ground” Label 112280 “Clean Lint Screen” Label 112533 “Phase 5 Coin Program Location Summary” Label 114001 “Caution - Exhaust/Lint Screen” Label 114006 “Warning - Fire Hazards” Label 120800 1/4” In-Line Connector 120802 Red Butt Connector 120902 #74B Wire Nut...
  • Page 32 ADC 450422 3 - 03/23/05-0...
