AD-285 Parts Manual 1987 thru 1991 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450085...
Page 2
These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. Important MODEL NO. __________________________________________ AD-285...
High Security Control Door Assembly ... 3 Phase 4.1 Single Coin Microprocessor Control Panel Assembly For Direct Spark Ignition (DSI) Models Only ... 4 Phase 4.1 Single Coin Microprocessor Control Box Assembly For Direct Spark Ignition (DSI) Models Only ... 5 Phase 4.1 Dual Coin Microprocessor Control Panel Assembly For Direct Spark Ignition (DSI) Models Only ...
Page 4
Main Door Switch Assembly Plunger-Type ... 29 Drop Lint Door Assembly ... 30 Lint Trap Assembly ... 31 Basket (Tumbler)/Support Assembly Tapered Rib For Models Mfd. as of April 18, 1991 ... 32 Basket (Tumbler)/Support Assembly Standard Rib For Models Mfd. prior to April 18, 1991 ... 33 Basket (Tumbler) Bearing Assembly ...
High Security Control Door Assembly Illus. No. Part No. Qty. 160015 160104 160017 160016 112350 870011 800019* 800143 180203 102307 150201 150415 102600 102601 102503 Specify color when ordering. 450085-8 Description High Security MK-100 Lock Assembly ONLY with Key MK-100 Key ONLY Special Dummy Lock (noncoin models Only) Lock Cam ONLY ADC Logo ONLY...
Phase 4.1 Single Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. 112526 865098 865099 800040 800039 150415 137130 137131 152001 153012 -------- 137056 137023 137021 865050 122800 IMPORTANT: Check label on computer chip to verify correct part number for microprocessor controller. For Direct Spark Ignition (DSI) Models ONLY Description Coin Keyboard Label Assembly...
Phase 4.1 Dual Coin Microprocessor Control Box Assembly For Direct Spark Ignition (DSI) Models ONLY Illus. No. Part No. Qty. Description 137021 Microprocessor Socket ONLY 137020 15-Pin Microprocessor Connector ONLY 122800 Microprocessor (female) Pin Extraction Tool...Not Illustrated 150315 #6 x 3/8” Phillips Pan Head Screw 137022 15-Pin Strain Relief ONLY 137013...
Page 10
Phase 4 Single Coin Microprocessor Control Panel/Box Assemblies ® For Glo-Bar Ignition Models ONLY American Dryer Corporation 450085-8...
Phase 4 OPL Microprocessor Control Box Assembly For Direct Spark Ignition (DSI) Models ONLY Illus. No. Part No. Qty. Description 137021 12* Microprocessor Socket ONLY 137020 15-Pin Microprocessor Connector ONLY 122800 Microprocessor (female) Pin Extraction Tool...Not Illustrated 150315 #6 x 3/8” Phillips Pan Head Screw 137022 15-Pin Strain Relief ONLY 137013...
Non-Microprocessor Coin Control Panel/Box Assemblies ® For Direct Spark Ignition (DSI) and Glo-Bar Ignition Models American Dryer Corporation 450085-8...
Illus. No. Part No. Qty. 125511 125532 125512 125513 125500 125501 125502 125503 125504 125506 125507 125508 125510 125515 125516 Description 1/60 RPM 115 Volt 60 Hz Meter Motor 1/60 RPM 230 Volt 60 Hz Meter Motor 1/60 RPM 240 Volt 50 Hz Meter Motor 1/30 RPM 240 Volt 50 Hz Meter Motor 2-Point Cam 3-Point Cam...
Illus. No. Part No. Qty. 800676 800677 154215 170330 150300 150415 121405 150205 --------- Specify color when ordering. Description Front Panel Assembly (latch-type) Complete with Hinge (includes illus. nos. 1 through 3 and 6) Stainless Steel Front Panel Assembly (latch-type) Complete with Hinge (includes illus.
Front Panel Assembly Magnet-Type Illus. No. Part No. Qty. 800389 800384 170340 154200 121405 150415 150300 150201 --------- Specify color when ordering. 450085-8 Description Front Panel Assembly (magnet-type) Complete with Hinge (includes illus. nos. 1 through 3 and 6) Stainless Steel Front Panel Assembly (magnet-type) Complete without Hinge (includes illus.
Illus. No. Part No. Qty. Description 800285 Gray (lightweight) Main Door Assembly (latch-type) Complete (includes illus. nos. 1 and 5 through 7) 103050 12-1/2” Stainless Steel Main Door 150410 #10-24 x 3/8” Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102353 Main Door Gasket 102210...
Main Door Assembly Magnet-Type Illus. No. Part No. Qty. 800136** 800133** 800134** 103050 150410 152014 102350 102210 150002 102105 152013 306802 102102 150410 800131 170730 170725 All dryers manufactured as of June 1, 1989 are built with a lightweight (plastic) main door assembly. ** Contact factory for colors other than gray.
Illus. No. Part No. Qty. Description 313215 Door Switch Actuator Arm ONLY 800445* N.S. Series Microprocessor Main Door Switch Housing Assembly Complete (for models mfd. as of November 21, 1990) (includes illus. nos. 1 through 7) 800446** N.S. Series Non-Microprocessor Main Door Switch Housing Assembly Complete (for models mfd.
Main Door Switch Assembly Plunger-Type Illus. No. Part No. Qty. Description 137003 Plunger-Type Main Door Switch (includes illus. nos. 1, 2, and 4) 401551 Door Switch Spacer/Washer 870010 Plunger-Type Main Door Switch Assembly Complete (for microprocessor models mfd. prior to November 21, 1990 and for non-microprocessor models mfd.
Basket (Tumbler)/Support Assembly Standard Rib For Models Mfd. prior to April 18, 1991 Illus. No. Part No. Qty. Description 800815 Standard Rib Basket (tumbler) and Support Assembly Complete with Felt Collar (includes illus. nos. 1 through 11) 800863 Stainless Steel (standard rib) Basket (tumbler) and Support Assembly Complete with Felt Collar (includes illus.
Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly For 60 Hz Models with Tapered Ribs ONLY Illus. No. Part No. Qty. Description 100105 4L-520 V-Belt (to idler bearing assembly) 100701 3/16” x 3/16” x 1” Key (for use on 3Ø models Only) 101131 1/2”...
Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly For 60 Hz Models with Standard Ribs ONLY Illus. No. Part No. Qty. Description 100105 4L-520 V-Belt (to idler bearing assembly) 100701 3/16” x 3/16” x 1” Key (for use on 3Ø models Only) 101104 1/2”...
Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly For 50 Hz Models with Tapered and Standard Ribs Illus. No. Part No. Qty. Description 100105 4L-520 V-Belt (to idler bearing assembly) 100701 3/16” x 3/16” x 1” Key (for use on 3Ø models Only) 101131 5/8”...
Direct Spark Ignition (DSI) Burner Assembly DSI module may be mounted on the left outside wall of the control box (as shown) or may be mounted on the inside of the left side panel. American Dryer Corporation 450085-8...
Illus. No. Part No. Qty. Description 132002 200-Watt Transformer 115 VAC (terminals not included) 150415 #10-16 x 1/2” Phillips Round Head Crimptite Screw 121400 Universal Bushing 880120 Terminal Package for Glo-Bar Used on 208/230 volt models ONLY. Control/Heat Step Down Transformer For Glo-Bar ®...
Outer Top/Back Guard Assembly Illus. No. Part No. Qty. Description 330626 Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150300 #10-16 x 1/2” Hex Washer TEK Screw 330623 Center Back Guard 150300 #10-16 x 1/2” Hex Washer TEK Screw 330621 Outer Top Guard 150300...
Microprocessor Coin Acceptor Listing NOTE: Coin acceptors listed include optical switch (ADC Part No. 137056). Part Number Nation 125100 United States and Canada 125127 Canada 125101 United Kingdom 125114 United Kingdom 125115 United Kingdom 125102 Belgium 125106 France 125120 France 125124 France 125109...
A wiring diagram is located on the back side of the control (service) door of each ADC dryer. Due to the various electrical options available on the model AD-285 dryer, the wiring diagrams on the following pages may not necessarily depict your specific dryer. The various wiring diagrams are identified by number, in the upper right-hand corner of each diagram.
Internal Single-Phase (1Ø) Motor Wiring The motor used in an ADC dryer is a dual voltage motor. When replacing a motor in the field, the replacement motor could have been pre-wired by the factory for operation at either 115 volts or 230 volts. Check the internal wiring of the motor to assure that the motor is wired internally for the correct voltage application.
