DELIVERY
Your LeMond RevMaster will arrive packed in 1 carton. Upon arrival fully inspect the carton for damage.
Point out any damage to the delivery person and have the delivery person record the damage on the
delivery paperwork. Contact the Customer Service Department at (425) 482-6773 to report any damage.
Please follow these detailed instructions and you will find that your bike can be unpacked and assem-
bled with ease.
M4 x 10 (2)
M5 x 10 (1)
M8 x 15 (10)
Star Washer (4)
Curved Washer (4)
Brass Washer (1)
10
Handlebar Assy. (1)
Seat Assy. (1)
Assembly Parts
ASSEMBLY INSTRUCTIONS
Adjustment Lever (1)
Water Bottle Holder (1)
Rear Stabilizer (1)
Front Stabilizer (1)
Stretch Pad (1)
Pedal, left (1)
Pedal, right (1)
Track Cap (1)
[not to scale]
