these types of applications. The IBM Ultrium WORM cartridges work with the IBM System Storage LTO
Ultrium Tape Drives to help prevent the alteration or deletion of user data. In addition, IBM has taken
several steps to reduce the possibility of tampering with the information:
The bottom of the cartridge is molded in a different color than rewritable cartridges.
The special cartridge memory helps protect the WORM nature of the media.
A unique format is factory-written on each WORM cartridge.
Table 2 lists the cabling ordering information for the TS3100 and TS3200.
Table 2. TS3100 and TS3200 cabling ordering information
Cables
4.5 m VHDCI/HD68 SCSI Cable
10.0 m VHDCI/HD68 SCSI Cable
13.0 m LC/LC Fibre Cable
25.0 m LC/LC Fibre Cable
LC-SC Fibre Cable Interposer
2M SAS/Mini-SAS 1x Cable
2M Mini-SAS/Mini-SAS 1x Cable
SAS/Mini-SAS 4x Interposer
Mini-SAS/Mini-SAS 4x Interposer
Table 3 lists the common specifications for the TS3100 and TS3200.
Table 3. TS3100 and TS3200 specifications
Specifications
Tape drive type
Tape drive physical capacity
Data transfer rate (per drive)
Attachment support
Warranty
Operating environment
Temperature
Relative humidity
Electrical power
IBM System Storage TS3100 and TS3200 Tape Libraries
IBM Ultrium LTO-5 Full-High and Half-High
IBM Ultrium LTO-4 Full-High and Half-High
IBM Ultrium LTO-3 Half-High
Up to 3.0 TB per cartridge compressed; 1.5 TB native with LTO-5 media
Up to 1.6 TB per cartridge compressed; 800 GB native with LTO-4 media
Up to 800 GB per cartridge compressed; 400 GB native with LTO-3 media
Up to 140 MBps native with LTO-5 tape drive
Up to 120 MBps native with LTO-4 tape drive
Up to 80 MBps native with LTO-3 tape drive
8 Gbps fibre channel and 6 Gbps SAS interfaces
LVD SCSI (LTO-4 Full-High)
4 Gbps fibre channel and 3 Gbps SAS interfaces (LTO-4 Full-High)
Three-year, customer-replaceable unit (CRU) service in most countries
50 to 113 degrees F (10 to 45 degrees C)
10% RH to 80% RH (non-condensing)
4.0 amps at 100 V ac; 2.0 amps at 240 V ac 0.1 KVA
Part number
23R7134
23R7135
23R7137
23R7138
23R7140
95P4711
95P4713
95P4994
95P4996
