  • Page 1 PLANET 802.11n Wireless Presentation Gateway WPG-130N...

  • Page 2: Federal Communication Commission Interference Statement

    "as is". Should the programs prove defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User Manual for PLANET 802.11n Pocket Presentation Gateway Model: WPG-130N Version: 2...

  • Page 4: Table Of Contents

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Contents Chapter 1. PRODUCT INTRODUCTION ..............6 Package Contents ..................6 Product Description ................... 7 Product Features..................9 Product Specification ................10 Chapter 2. HARDWARE INSTALLATION ..............12 Hardware Description ................12 2.1.1 The Front Panel ................12 2.1.2...
  • Page 5 PLANET 802.11n Wireless Presentation Gateway WPG-130N 5.3.6 Reset to Default ................44 5.3.7 Firmware Upgrade ................. 45 5.3.8 Reboot System ................46 Appendix A: Configuring the PCs ................47 Appendix B: FAQ .....................51...

  • Page 6: Chapter 1. Product Introduction

    Chapter 1. PRODUCT INTRODUCTION Package Contents Thank you for choosing PLANET WPG-130N – the 802.11n Wireless Pocket Presentation Gateway. Before installing the router, please verify the contents inside the package box.  WPG-130N × 1  5V DC Power adapter × 1 ...

  • Page 7: Product Description

    4-to-1 Split Screen Projection With this 4-to-1 split screen feature, WPG-130N supports up to four PC / Laptop screens can be projected to one projector in the same time. Thus the participants can easily do side-by-side comparison from four PC /...
  • Page 8 USB token. It offers the most convenient way for the new user to make the presentation in seconds. Just link the PC / Laptop to WPG-130N wirelessly and the screen will be projected to the connected projector easily.

  • Page 9: Product Features

    WPG-130N AP Client Mode You can enable the AP Client Mode function to make WPG-130N join the existing Access Point through Wi-Fi. This feature provides the flexibility of wireless network deployment in enterprise environment. The participants in the meeting can enjoy surfing the Internet and access Intranet all the time, even while wireless presentations are projecting.

  • Page 10: Product Specification

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Product Specification Product WPG-130N Hardware Specification Interfaces Video VGA Port: D-Sub 15-Pin female port WLAN 802.11n 150Mbps Antenna Gain 2dBi Dual PIFA Antenna LED Indicator Power Material Plastic Dimension (W x D x H) 92.3 x 40 x 22 mm...
  • Page 11 PLANET 802.11n Wireless Presentation Gateway WPG-130N System Management Protocol TCP/IP IP configuration Automatic: DHCP Manual: Static IP address Management: Web-based configuration Supported Windows Account Administrators Right Limited User Guest Supported Operation System Windows XP/Vista/7 Windows Mobile 5/6 Mac OS X 10.4 or later...

  • Page 12: Chapter 2. Hardware Installation

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Chapter 2. HARDWARE INSTALLATION Please follow the instructions below to build the wireless network connection between WPG-130N, display equipment and your computers. Hardware Description 2.1.1 The Front Panel The front panel provides a simple interface monitoring the wireless presentation gateway.

  • Page 13: The Rear Panel

    Rear Panel Figure 2-2 The WPG-130N Rear Panel 2.1.4 The Top Side Hardware Connection Step 1. Please turn on your projector first, and connect the WPG-130N to the projector. Now you can power on WPG-130N. Figure 2-3 VGA Interface Connection...
  • Page 14 Step 3. User your laptop or desktop to site survey the wireless signal of WPG-130N, and connect your PC with it wirelessly. The default SSID is WPG-130N. Figure 2-5 Windows 7 Platform Wireless Site Survey...
  • Page 15 PLANET 802.11n Wireless Presentation Gateway WPG-130N Step 4. Open the web browser and it will redirect to WPG-130N web page automatically, or you can enter the default IP address 192.168.1.1 to access it. Figure 2-6 WPG-130N Web UI Screenshot Now you can configure the WPG-130N and download the client utility (WPG) of Windows 7/Vista/XP or Mac...

  • Page 16: Chapter 3. Windows Client Utility-Wpg

    WPG will start to search the available access points automatically if you have not connected your PC to WPG-130N manually. When the WPG-130N is displayed in the list, please click it to connect and then enter the Login Code shown on the projector screen.

  • Page 17: Control Panel

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Step 3. Click the button to start projection Figure 3-3 WPG Utility – Control Panel Control Panel Figure 3-4 WPG Utility – Control Panel Function Introduction Button Description Button Description Start Full Screen Projection Project to Split No.

  • Page 18: Show Login Code

    Figure 3-5 WPG Utility – Show Login Code 3.2.2 Web Admin Click “Web Admin” to open the web UI page of WPG-130N. With regard to the web management UI page, please refer to the next chapter. Figure 3-6 WPG Utility – Web Admin...

  • Page 19: Search Server

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure 3-7 3.2.3 Search Server Click “Search Server” to re-search the wireless signal of WPG-130N again. Figure 3-8 WPG Utility – Search Server...

  • Page 20: Projection Quality

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.4 Projection Quality Click the “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best” for clear screen image quality but slower projection speed. Figure 3-9 WPG Utility – Projection Quality 3.2.5 Projection Source...
  • Page 21 PLANET 802.11n Wireless Presentation Gateway WPG-130N When “Main Screen” is selected, WPG-130N will project out Main Screen the main desktop screen. When “Virtual Extended Screen” is selected, WPG-130N will project out the virtual screen. Virtual Extended The virtual second monitor is invisible, but it is just right of the Screen main one.

  • Page 22: Auto Wifi Connect

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.6 Auto WiFi Connect Click “Auto WiFi Connect” to enable the auto WiFi discovery and connection function for quick wireless connection established. Figure 3-13 WPG Utility – Auto WiFi Connect 3.2.7 Auto Power Manager If “Auto Power Manager”...

  • Page 23: Hide Ui

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.8 Hide UI You can click “Hide UI” to hide the WPG control panel from projection screen. Figure 3-15 WPG Utility – Hide UI 3.2.9 Advanced Screen Capture If you enable “Advanced Screen Capture”, all the tip windows and other layered windows (include the main UI) will be projected to the projector screen.

  • Page 24: Make Wpg Token

    PLANET 802.11n Wireless Presentation Gateway WPG-130N The Source Screen with Tip Window The Projector Screen without Tip Window Figure 3-17 3.2.10 Make WPG Token Click “Make WPG Token” to make a USB WPG Token, then you can insert the USB drive to any PC you want...
  • Page 25 PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure 3-18 WPG Utility – Make WPG Token Figure 3-19...

  • Page 26: Copy Application To Desktop

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.11 Copy Application to Desktop .2.11 Copy Application to Desktop Click the “Copy Application to desktop”, then it will copy the WPG Utility to your desktop immediately even Click the “Copy Application to desktop”, then it will copy the WPG Utility to your desktop immediately even you don’t have the system privilege.

  • Page 27: Hot Key

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.12. Hot Key Click “Hot Key” to show the guide of hot key. You can use the hot key to control the projection by keyboard. Figure 3-21 WPG Utility – Hot Key 3.2.13. About Click “About”...

  • Page 28: Exit

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 3.2.14. Exit Click “Exit” to exit the WPG utility. It will stop the current projection and close the application immediately. Figure 3-23...

  • Page 29: Chapter 4. Mac Os X Client Utility

    Step 2: Highlight and select the wireless network (SSID) to connect (1) Select and SSID [WPG-130N] (2) Double-click on the selected SSID Figure 4-2 Step 3: Enter the encryption key of the WPG-130N (1) Enter the encryption key that configured in section 5.4.2 (1) Click the [Join] button...
  • Page 30 Step 4: Check if the AirPort is connect to the selected wireless network. If “Yes”, then there will be a “check” symbol in the front of the SSID. Step 5: Open the web browser and it will redirect to WPG-130N home page automatically. Or you can enter the default IP address http://192.168.1.1...

  • Page 31: Download Mac Os X Client Utility

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 4.2. Download Mac OS X Client Utility Step 1. : Click “Download”. Step 2. : Choose the utility for “MAC”, then click Download button to download utility. Figure 4-6 Figure 4-7...
  • Page 32 WPG will start to search the available access points automatically if you have not connected your MAC to WPG-130N manually. When the WPG-130N is displayed in the list, please click it to connect and then enter the Login Code shown on the projector screen.
  • Page 33 PLANET 802.11n Wireless Presentation Gateway WPG-130N Step 6. Once the WPG-130N is connected, the application will temporarily adjust your PC resolution for best projection result, and then project your screen to projector or TV. Figure 4-10 You should see your PC Desktop on projector or TV screen now.

  • Page 34: Chapter 5. Web Ui Management

    Please follow the steps below to enter the web UI of WPG-130N. Step 1. First, please connect your Laptop to WPG-130N wirelessly. Step 2. Open the web browser and it will redirect to WPG-130N home page automatically. Or you can enter the default IP address http://192.168.1.1 to access it.

  • Page 35: Download

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure 5-2 The following sections will introduce the detailed instructions of the web UI functions. 5.2. Download Please follow the steps below to download and execute the WPG installation program. Click “Download”. Choose the WPG utility for “Windows 7 / Vista / XP” or “Mac OS X”, then click Download button and execute the installation program.

  • Page 36: Admin

    Figure 5-3 5.3. Admin This function allows you to login web management UI of WPG-130N. Click “Admin”, and enter the password. The default value is “admin”. Then click the Login button or press the Enter key. Please refer to the following sections for further configuration of the web management UI.

  • Page 37: System Status

    Description Product model name Model Name Firmware Version Product firmware version number Network Status IP Address The IP address of WPG-130N Subnet Mask The subnet mask Default Gateway The default gateway The wireless MAC address Wireless MAC Address Wire MAC Address...

  • Page 38: Network Setup

    The page includes the flowing detail fields: Object Description IP Setup If you select this option, the WPG-130N will detect the network environment automatically. When WPG-130N is connected to a LAN that has DHCP  server, the clients of WPG-130N will be assigned an IP...
  • Page 39 PLANET 802.11n Wireless Presentation Gateway WPG-130N  DHCP Server Setup Figure 5-7 The page includes the flowing detail fields: Object Description DHCP Server Setup Auto Select “Auto” to enable the built-in DHCP server of WPG-130N. (Default Settings) Start IP The default value is 192.168.1.11 The default value is 192.168.1.254...
  • Page 40  AP Client Setup Enable the “Connect to Existing AP” make the WPG-130N can join other access point wirelessly. Besides, the clients can also login WPG-130N for presentation and surf the Internet via other AP simultaneously. The WPG-130N supports multiple encryption methods in wireless security. Please make sure you have...
  • Page 41 AP you want to join. Enter the key of the existed AP you want to join. Table 4-2 The wireless security of WPG-130N supports AES (Advanced Encryption Standard). Click the Apply button to make the changes to take effect.

  • Page 42: Osd Setup

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 5.3.3 OSD Setup Users can customize their own OSD (on-screen display) standby image. Figure 4-8 The web page includes the flowing fields: Object Description Restore Initial Restore to the default OSD standby image. Image File Upload Upload the customized OSD standby image.

  • Page 43: Projection Setup

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 5.3.4 Projection Setup Figure 4-9 The web page includes the flowing fields: Object Description Resolution VGA: WXGA+ (1280x800) WXGA (1280x768) XGA (1024x768) (Default setting) SVGA (800x600). HDMI: 720p (1280x720) Login Code You can select “Disable”, “Random”, or “Use the following code”...

  • Page 44: Reset To Default

    Click the Apply button to make the changes to take effect. 5.3.6 Reset to Default This page allows you to reset the current configuration to factory default. Figure 4-11 Click the Apply button to restore the WPG-130N to the factory default settings.

  • Page 45: Firmware Upgrade

    PLANET 802.11n Wireless Presentation Gateway WPG-130N 5.3.7 Firmware Upgrade This page allows you upgrade the WPG-130N firmware to new version. Please note, do not power off the device during the upload because it may crash the system. Figure 4-12 If it is necessary to upgrade the firmware, please follow the steps below to operate carefully.

  • Page 46: Reboot System

    PLANET 802.11n Wireless Presentation Gateway WPG-130N New firmware versions posted at the website of PLANET Technology can be downloaded for free. There is no need to upgrade the firmware unless the new firmware has a new feature you want to use.

  • Page 47: Appendix A: Configuring The Pcs

    PLANET 802.11n Wireless Presentation Gateway WPG-130N Appendix A: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows XP. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed.
  • Page 48 PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure A-2 The following TCP/IP Properties window will display and the IP Address tab is open on this window by default. Now you have two ways to configure the TCP/IP protocol below:  Setting IP address automatically...
  • Page 49 PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure A-3  Setting IP address manually Select Use the following IP address radio button. If the device's LAN IP address is 192.168.1.1, type in IP address 192.168.1.x (x is from 2 to 254), and Subnet mask 255.255.255.0.
  • Page 50 PLANET 802.11n Wireless Presentation Gateway WPG-130N Figure A-4 Now click OK to keep your settings.

  • Page 51: Appendix B: Faq

    [ANSWERS] 1) Power off the WPG-130N. 2) Press and hold the button, and then plug in the DC jack of the AC adapter to power on WPG-130N. After 10~15 seconds, you can release the button. 3) Now, you should be able to login the WPG-130N by default setting. (Default username and password are...
  • Page 52 *Model Number: WPG-130N * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) is herewith confirmed to comply with the requirements set out in the Council Directive on the 1999/5/EC R&TTE.
  • Page 53 GatewayΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ essenciais e outras disposições da Directiva ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ 1999/5/CE. ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ Por medio de la presente, PLANET Technology Español Slovensky Výrobca PLANET Technology Corporation, Corporation, declara que 802.11n Pocket týmto deklaruje, že táto 802.11n Pocket Presentation Gateway cumple con los requisitos Presentation Gateway je v súlade so...
