- Page 1 WPG-120 User Manual Wireless Presentation Gateway WPG-120 User’s Manual...
-
Page 2: Federal Communication Commission Interference Statement
Further, PLANET reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes. - Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual for PLANET Wireless Presentation Gateway Model: WPG-120 Rev: 1.0 (October. 2009) Part No. EM-WPG120...
-
Page 4: Table Of Contents
WPG-120 User Manual Table of Contents 1. Overview .....................5 2. Quick Start ....................6 3. Windows Client Utility ................9 Starting Program .................9 Login ......................10 Main User Interface ................10 Screen Projection ................10 Menu Description ................11 3.5.1 Show Login Code ................11 3.5.2... -
Page 5: Overview
PLANET WPG-120 is a portable wireless presentation gateway based on 802.11g technology. The size is only 8*3.5*2 cm and the weight is 53g. You cloud take WPG-120 to anywhere you want present at anytime. It cloud provide four wireless users to easily display their presentations without swapping cables at the same time. -
Page 6: Quick Start
WPG-120 User Manual 2. Quick Start 1) Plug the WPG-120 into the projector VGA input or connect a VGA cable to the WPG-120 VGA connector and turn on projector power. 2) Turn on WPG-120. ♦ When projector shows the default menu on the screen as below, it indicates the WPG-120 is ready. - Page 7 5) Download the client software, select “ Windows Vista / XP / 2000” and execute the installation program. ♦ After installing the program, you will see the WPG-120 shortcut on the PC screen.
- Page 8 WPG-120 User Manual 6) Make sure your personal firewall allows WPG-120 software to pass through. 7) Enter the LOGIN CODE and ♦ You can see the login code is the top left of the projector screen. 8) Click the “Play” button to start projection!
-
Page 9: Windows Client Utility
1) Click WPG-120 icon to execute the program. 2) Program will start to search for WPG-120 automatically, 3) If WPG-120 is found the “Login Code” dialog box will pop up on the PC screen. Searching for WPG-120. -
Page 10: Login
WPG-120 User Manual 3.2 Login 1) After “Login Code” dialog box shown, enter login code to start presentation. 2) You can see the login code shown in the top left of the projector screen. 3.3 Main User Interface Menu Area... -
Page 11: Menu Description
WPG-120 User Manual Button Description Full Screen projection Project to Split #1 Project to Split #2 Project to Split #3 Project to Split #4 Stop projecting Pause projecting 3.5 Menu Description Menu Login Code Exit Minimize 3.5.1 Show Login Code Click “Show Login Code”... -
Page 12: Open Admin Web Page
WPG-120 User Manual the area to close this window manually. 3.5.2 Open Admin Web Page Click to open the function menu and select “Web Admin” management web page. The detailed functions of the web page will be described in the... -
Page 13: Searching Server
WPG-120 User Manual 3.5.3 Searching Server Click “Search Server” to search for the WPG-120 again. 3.5.4 Projection Quality Click the “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best” for better image quality but slower... -
Page 14: Projection Source
WPG-120 User Manual 3.5.5 Projection Source Click “Projection Source” to project the main screen of the desktop or the virtual extended screen. Note -This function is only supported by Windows XP and a virtual display utility must first be installed. -
Page 15: Connection Profile
WPG-120 User Manual 3.5.6 Connection Profile Click “Connection Profile”, then click “save current as” to save current connection configuration into Profile, or click the “Manage Profile” to add, delete or modify current profiles. Save Current as Click “Save current as”, to save your current connection as a profile for future quick-connect. -
Page 16: Auto Wifi Connect
WPG-120 User Manual 3.5.7 Auto WiFi Connect Click “Auto WiFi Connect” to enable the AWZC function, this function can save the WiFi connection steps. 3.5.8 Auto Power Manager For best projection performance the auto power manager application will switch the PC’s current power setting to “highest performance”. Click the... -
Page 17: Hide Ui
WPG-120 User Manual 3.5.9 Hide UI Click the “Hide UI” to hide or display the application control panel. 3.5.10 Advanced Screen Capture Click “Advanced Screen Capture” to see tip windows and other layered windows (including the main UI) on the connected display. -
Page 18: Make Pns Token
WPG-120 User Manual Tip windows is not shown in projector Enable “Advanced Screen Capture”. Tip windows is shown in projector 3.5.11 Make PnS Token Click “Make PnS Token” to make a USB Token, you can insert a USB thumb drive... -
Page 19: Copy Application To Desktop
WPG-120 User Manual 3.5.12 Copy Application to desktop Click “Copy Application to desktop” to copy the application to your desktop immediately even if you don’t have the system privilege. -
Page 20: About
WPG-120 User Manual 3.5.13 About Click “About” to show system information, including Client version, IP address and other information. 3.5.14 Exit Click “Exit” to exit this application. It will stop current session and close the application immediately. -
Page 21: Web Management
Home Page 1. Make sure your PC connects to WPG-120 successfully. 2. Open your browser, it will enter WPG-120 home page automatically. 3. If not, enter your IP address on the browser, you can see the IP on the projector screen. -
Page 22: Download Software
WPG-120 User Manual Download Software 1. Select “Download software” function. 2. Please select the ‘Windows Vista / XP / 2000” and execute the installation program. 3. Follow Installation Wizard instructions to proceed till the installation process complete. 4. If pop up “Windows Security Alert” because Windows firewall block this program. -
Page 23: Login Web Admin
WPG-120 User Manual Login Web Admin 1. Click [Admin] and then enter password to login web page. 2. The password default value is “admin”. 4.3.1 System Status Click [System Status], shows current system status. Model Name: Product model name. Versions: 1. -
Page 24: Network Setup
SSID Broadcast: The default value is “Enable” ♦ Channel: to set fixed channel or Auto. In “Auto” mode the WPG-120 will scan all of wireless channels and select one clear channel automatically. ♦ Encryption: you can select “Disable” or one of WEP/WPA/WPA2 64bit or 128bit in ASCII or HEX string. -
Page 25: Projection Setup
WPG-120 User Manual <Back>: Back to main menu. 4.3.3 Projection Setup Click [Projection Setup] button ♦ <Resolution>: XGA (1024x768) and SVGA (800x600). The default value is “XGA”. ♦ <Login Code>: You can select “Disable”, “Random”, or “Use the following code” to set a specified 4-characters Number. -
Page 26: Reset To Default
*** Another way to restore Factory Default Settings, Follow below procedures. 1. Press [Reset] button and Hold. 2. Turn on WPG-120. 3. Wait for over 10 seconds and release [Reset] button. 4. It will take effect to restore factory default settings. -
Page 27: Firmware Upgrade
2. Click <Browse> to select file you want to upgrade. 3. Click <Upgrade> to start. 4. A warning message and countdown timer will appear on screen. 5. After a few minutes, a “complete” message will appear on screen. 6. Restart WPG-120 to allow upgrade to take effect. -
Page 28: Reboot System
WPG-120 User Manual 4.3.7 Reboot System Click [Reboot System] button, to restart system ♦ <Reboot>: reboot system automatically. -
Page 29: Logout
WPG-120 User Manual 4.3.8 Logout Click [Logout] button, to leave the control system. - Page 30 *Model Number WPG-120 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the 2004/108/EC R&TTE.
