Wireless Presentation Gateway

User Manual

WPG-100
Version: 1.00
Date: August 28, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPG-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Planet WPG-100

Summary of Contents for Planet WPG-100

  • Page 1: User Manual

    Wireless Presentation Gateway User Manual WPG-100 Version: 1.00 Date: August 28, 2006...

  • Page 2: Federal Communication Commission Interference Statement

    Copyright Copyright © 2006 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual for PLANET Wireless Presentation Gateway Model: WPG-100 Rev: 1.0 (September. 2006) Part No. EM-WPG100...

  • Page 4: Table Of Contents

    WPG-100 User Manual Contents of Table OVERVIEW ..........................5 QUICK START ..........................8 CLIENT UTILITY ........................11 Starting Program..................11 Login......................12 Buttons Description.................12 Start Presentation ..................13 Stop Presentation..................13 Open Admin Web Page................13 Searching Server ..................14 System Information.................15 Exit Program ...................15 WEB MANAGEMENT ......................15 Home Page ....................15...

  • Page 5: Overview

    PCs / Notebooks will be easier to project screen to the attached Projector. Plug & Play WPG-100 is a plug-and-play device which is easy to install and connect with. Any Notebooks/PCs with built-in Centrino or Wi-Fi card can easily download driver and connect to WPG-100.
  • Page 6 User-friendly graphic interface to allow users to use it without any training. Intelligent searching function After perform WPG-100 utility, the utility will automatically search all the WPG-100 which are available and within the wireless LAN cover range. Users don’t need to do any other setting, without worrying about the operation procedures.
  • Page 7 WPG-100 User Manual Features Wireless presentation … no more cable swapping. Compatible to all projectors with standard VGA connectors. One-Click to switch presenters’ displays. Real time display for PowerPoint presentations, images and applications. Supports display resolutions up to 1024x768 with 24-bit color.

  • Page 8: Quick Start

    WPG-100 is ready now. Make sure your PC LAN port or WLAN interface is enabled already, and connect your PC with WPG-100 (wireless default SSID is WPG-100). Open your browser and enter the WPG-100 IP address to get in WPG-100 web home page.
  • Page 9 WPG-100 User Manual ♦ The default IP address of WPG-100 is 192.168.1.10. If you have modified the IP address, you can refer to the IP address shown on the left-down corner of projector screen. Click on “Download”. You will see a file download dialog box appear, press “Run” to execute the installation...
  • Page 10 WPG-100 User Manual After install the program, WPG-100 shortcut will come out on the desktop. If there is any firewall, please make sure your personal firewall has allow WPG-100 software to pass through. Enter the LOGIN CODE and press “OK”.

  • Page 11: Client Utility

    1) Click WPG-100 icon to execute the program. 2) Program start to search for WPG-100 box automatically, 3) If WPG-100 box founded then “Login Code” dialog box will be pop up on the PC screen. 4) If not, will enter to disconnected state and “Reconnect” button shown for you to try again.

  • Page 12: Login

    WPG-100 User Manual 3.2 Login 1) After “Login Code” dialog box shown, enter login code to start presentation. 2) You can see the login code shown on the projector screen. 3.3 Buttons Description 1) After login successfully, operating deck comes out.

  • Page 13: Start Presentation

    WPG-100 User Manual Refresh projecting screen Server Login Code Function menu While projecting in progress, this icon is blinking Minimize the program    E xit the program 3.4 Start Presentation Click to start wireless presentation. 3.5 Stop Presentation Click to stop wireless presentation.

  • Page 14: Searching Server

    WPG-100 User Manual 3.7 Searching Server Click “Search Server” to search for WPG-100 box.

  • Page 15: System Information

    WPG-100 User Manual If there is not any WPG-100 available, the utility will show the result below: 3.8 System Information Click “Info” to show system information. It includes product model number, IP address and other information. 3.9 Exit Program Click to terminate the program.

  • Page 16: Download Software

    WPG-100 User Manual 4. Than you will see the WPG-100 home screen. 4.2 Download Software Select “Download software” function. 1. Press “Login” button to download Utility, the default password is blank 2. You can save file first then execute later or execute this utility directly.

  • Page 17: Conference Control

    3. Enter password, the default value is “trainer”, and then press [Login]. 4. After login, you can see a User List on the screen which indicates all of users connected to WPG-100 box. 5. There are three columns, “Computer Name”, “Play Control” and “IP...
  • Page 18 “Play” button and “Stop” button. Computer Name: The name of PC connected to WPG-100 box. Play control Show current user’s projecting status. : Start projecting : Stop projecting. IP address The IP address of PC...

  • Page 19: Login Web Admin

    WPG-100 User Manual 4.4 Login Web Admin 1. Click [Admin] and then enter password to login web page. 2. The password default value is “admin”.

  • Page 20: System Status

    1. Operating Mode: current operating mode 2. IP address IP address of WPG-100 3. MAC address. 4. Subnet Mask. 5. Default Gateway Connection Status: 1. Projecting status: which is “Waiting for projecting” or “Projecting” 2. Total Users: how many users login to WPG-100 now.

  • Page 21: Operating Mode

    WPG-100 User Manual 4.6 Operating Mode There are three kinds of operating mode, which one is suitable for you that depend on your office network configurations. 1. [ Independent Mode ]...
  • Page 22 This mode is the simplest and easiest way to get presentation up and running. ♦ Your client PC can only connect to WPG-100 through WLAN, and your PC’s IP address get from WPG-100 automatically. ♦ In this mode, WPG-100 provides DHCP server capability.
  • Page 23 SSID: SSID string, max. length is 32 bytes. ♦ Channel: to set fixed channel or Auto. The “Auto” means after power on WPG-100, it will scan all of wireless channel and select clear one channel automatically. ♦ WEP: you can Disable WEP key or select one of 64bit or 128bit in ASCII or HEX string..
  • Page 24 SSID: This is SSID of WPG-100. The string length is 32 bytes. ♦ Channel: to set fixed channel or Auto. The “Auto” means after power on WPG-100, it will scan all of wireless channel and select clear one channel automatically. ♦...
  • Page 25 *** Click [WLAN Infrastructure Mode] button to select this mode. ♦ This mode is purely “wireless”, WPG-100 act as a WLAN client station to connect your office Access Point/Router to accommodate to existing office network. So that Internet browsing is possible.
  • Page 26 WPG-100 want to connect to. The string length is 32 bytes. ♦ Channel: to set fixed channel or Auto. The “Auto” means after power on WPG-100, it will scan all of wireless channel and select clear one channel automatically. ♦...

  • Page 27: Projection Setup

    *** Click [Projection Setup] button ♦ <Device Name>: The device name of WPG-100. ♦ <Color Depth>: provide WPG-100 output with 16bit or 32 bit color depth. It depends on your PC settings. ♦ <Screen Refresh Rate>: This is VGA output refresh rate, provides 60 Hz and 70Hz to suit for different kinds of projectors..

  • Page 28: Change Passwords

    WPG-100 User Manual 4.8 Change Passwords *** Click [Change Password] button, to change password value. ♦ <Enter New Password>: enter new password you want to change for each category. ♦ <Confirm New Password>: double confirm new password. ♦ <Apply>: Confirmation and Save modifications.

  • Page 29: Reset To Default

    1. Power off WPG-100. 2. On the rear panel, press [Reset] button and Hold. 3. Turn on WPG-100 box. 4. Wait for over 10 seconds and relief [Reset] button. 5. It will take effect to restore factory default settings.

  • Page 30: Firmware Upgrade

    2. Click <Browse> to specify file name you want to upgrade. 3. Click <Upgrade> to start. 4. A warning message shown and count down counter on the screen. 5. After a few minutes, a complete message shown on the screen. 6. Restart WPG-100 box to take effect.

  • Page 31: Reboot System

    WPG-100 User Manual Warning: Don’t power off WPG-100 while firmware upgrade in progress, otherwise will cause your Box doesn’t work and have to return device to your vendor for fixing. 4.11 Reboot System *** Click [Reboot System] button, to restart system ♦...

  • Page 32: Wall Mount Instructions

    WPG-100 User Manual Wall Mount Instructions Remove the rubber foots at back plane side. Screw mounting screws on unit. Use screws to fix mount bracket on the wall. Hang up unit on mounting bracket.

  • Page 33: Specification

    WPG-100 User Manual Specification Standards IEEE 802.11b/g IEEE 802.3/802.3u Channels 11 (US, Canada), 13 (Europe) and 14 (Japan) Data Rate Wireless: up to 54Mbps LAN: 10/100 Mbps with auto MDI/MDIX Operating Access Point mode Network Type Ad-Hoc mode Infrastructure mode...

  • Page 34: Troubleshooting

    WPG-100 User Manual Troubleshooting Q1. Can I use older client utility working with new server box ? : After you did firmware upgrade complete, you should download Client utility from server box to replace older one, otherwise it might cause working improperly because version compatibility issue.
