Menu Item
EQ SETTING
[SUPER BASS], [POWERFUL],
[NATURAL], [VOCAL], [CUSTOM1],
[CUSTOM2], [FLAT]
Select an equalizer band and
level for further customizing.
Equalizer band: [80HZ], [250HZ],
[800HZ], [2.5KHZ], [8KHZ]
Equalizer level: [+6] to [–6]
LOUDNESS
[OFF], [LOW], [MID], [HI]
SUB.W*2
[NOR], [REV], [OFF]
SUB.W CTRL*2*3
Cut-off frequency: [50HZ],
[63HZ], [80HZ], [100HZ], [125HZ],
[160HZ], [200HZ]
Output level: [–24] to [+6]
Slope level: [–12], [–24]
BASS BOOST
[0] to [+6]
HPF SETTING
Cut-off frequency: [OFF], [50HZ],
[63HZ], [80HZ], [100HZ], [125HZ],
[160HZ], [200HZ]
Slope level: [–12], [–24]
SLA
[+4] to [–4]
14
En
Description
Select or customize the equalizer curve.
[CUSTOM1] can be set separately for each source.
However, each of the below combinations are set
to the same setting automatically.
• USB, iPod, and APP (iPhone)
• USB, iPod, PANDORA (iPhone), and APP
(iPhone)
• BT AUDIO, PANDORA (Android), and APP
(Android)
[CUSTOM2] is a shared setting used for all
sources.
Compensate for clear sound at low volume.
Select the subwoofer phase.
Only frequencies lower than those in the
selected range are output from the subwoofer.
Select the bass boost level.
Only frequencies higher than the high-pass filter
(HPF) cutoff are output from the speakers.
Adjust the volume level for each source except
FM.
Each of the below combinations are set to the
same setting automatically.
• USB, iPod, PANDORA (iPhone), and APP
(iPhone)
• BT AUDIO, PANDORA (Android), and APP
(Android)
*1 Not available when [SUB.W/SUB.W] is selected in [SP-P/O MODE] in the INITIAL settings (page 6).
*2 Not available when [REAR/REAR] is selected in [SP-P/O MODE] in the INITIAL settings (page 6).
*3 Not available when [OFF] is selected in [SUB.W].
SYSTEM settings
You can also access to these menus when the unit is turned off.
Menu Item
CLOCK SET
12H/24H
[12H], [24H]
AUX
[ON], [OFF]
BT AUDIO
[ON], [OFF]
PANDORA
[ON], [OFF]
BT MEM CLEAR
[YES], [CANCEL]
BT VERSION
APP CONN. SET*
[WIRED], [BLUETOOTH]
* Not available when [PANDORA] or [APP] is selected as the source.
Description
Set the clock (page 6).
Select the time notation.
Set to [ON] when using an auxiliary device
connected to the unit.
Set the Bluetooth signal on/off.
Set to [ON] when using the Pandora function.
Clear the Bluetooth device data (device list, PIN
code, call history, phone book, preset phone
numbers) stored in the unit.
[CLEARED] appears when data is successfully
deleted.
Displays the system version of the unit and the
Bluetooth module.
Select the appropriate connection method
according to your device.
