Memmert VO200 Operating Instructions Manual page 11

13
14
15
16
1 Computer connection,
serial communication interface
2 Printer connection, parallel printer interface
3 Air/gas connection IN1
4 Air/gas connection IN2
5 Vacuum connection OUT
6 Norprene connecting tube vacuum
pump to vacuum unit
7 Vacuum pump connection, pump module
8 Control connection for vacuum pump purge
9 Mains power connection pump module
10 Connecting line pump purge
11 Control connection pump purge
12 Mains power connection vacuum unit
13 Socket
14 Thermotray
15 Main switch pump module
16 Vacuum pump
page 11 PERFECT
