3. Use the RS232C cable (serial cable, RJ-45 to DB-9) supplied with the server in the Accessory Kit, and
connect the administration console to the serial port (see
You can use any of the following devices with a DB-9 serial port as the administration console: ASCII
terminal, workstation, terminal server (or a patch panel connected to a terminal server), or personal
computer. A Serial-to-USB port adapter may be required for laptops.

▼ Initialize the XSCF

The following steps will log in to the XSCF Shell and initialize the XSCF settings. XSCF is a system control
facility to set up and control the server.
1. Set the mode switch on the operator panel to the Service mode (
The key for the operator panel is supplied with the server.
Operator Panel
FIGURE 2
Figure Legend
Location No. Name
1 POWER LED
2 XSCF STANDBY LED
3 CHECK LED
4 Power button
5 Mode switch (Key switch)
2. Turn the AC power source circuit breaker to "ON".
After AC power is turned on, the server starts the XSCF initialization that can take up to 5 or more minutes.
When the initialization completes, the XSCF STANDBY LED (
3. After the XSCF initialization completes, enter default at the login prompt.
login: default
, #3) on the rear panel of the server.
FIGURE 1
).
1
2
3
4
5
) on the operator panel lights.
3
