A0246IVZ.fm
KGS 303
Betriebsanleitung . . . . . . . . . . . . . . . . . . . . .3
Operating Instruction . . . . . . . . . . . . . . . . .16
Instructions d'utilisation . . . . . . . . . . . . . . .28
Manuale d'istruzioni . . . . . . . . . . . . . . . . . .41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KGS 303 and is the answer not in the manual?

Questions and answers

Related Manuals for Metabo KGS 303

Summary of Contents for Metabo KGS 303

  • Page 1 A0246IVZ.fm KGS 303 Betriebsanleitung .....3 Operating Instruction ....16 Instructions d'utilisation .
  • Page 2 * EN 61029-1(2000), prEN 61029-2-9(2001), DIN EN 55014-1, DIN EN 55014-2, EN ISO 3744, DIN EN 62079 ** 98/37/EG - 73/23/EG - 89/336/EWG Ing. grad. Hans-Joachim Schaller Leitung Entwicklung und Konstruktion Metabowerke GmbH Business Unit Elektra Beckum Daimler Str. 1 D - 49716 Meppen Meppen, 11.10.2002 1001093/ 02...

  • Page 3: Parts Identification (Standard Delivery)

    XA0040E2.fm Operating Instruction ENGLISH ENGLISH 1. Parts identification (standard delivery) Handle 12 Table insert Tools ON/OFF switch 13 Rotating table locking screw 21 Allen key 6 mm Holder for Allen key 6 mm 14 Saw base Motor 15 Fence Machine documents Track arm guide bars 16 Retractable blade guard –...

  • Page 4: Table Of Contents

    ENGLISH Retain proof of purchase in case of Stock having a round or irregular cross Table of Contents warranty claims. section (such as firewood) must not be cut, as it can not be securely held during Parts identification If you lend or sell this machine be cutting.

  • Page 5: Symbols On The Machine

    ENGLISH objects such as radiators, pipes, pieces are caught by the saw blade Before any use check tool for possi- cooking stoves, refrigerators when uncontrolled. ble damage: before operating the operating this tool. tool all safety devices, protective guards or slightly damaged parts Do not use the power cable for pur- Drawing-in/trapping hazard! need to be checked for proper func-...

  • Page 6: Safety Devices

    ENGLISH Information on the nameplate: (22) Manufacturer (23) Serial number (24) Machine designation (25) Motor specifications (see also "Technical specifications") (26) Year of make For cutting the safety lock is pushed to Place tool on a suitable base: the side (arrow). Only then can the saw- (27) CE-mark –...

  • Page 7: Machine Details

    ENGLISH cutting angle range for mitre cuts (50 left thru 60 right) with ten positive stops. Soft start. Integrated cutting depth stop for grooving. Perfect for mobile use because of its low weight and small dimensions. Precise and sturdy die-cast alumin- ium construction.

  • Page 8: Initial Operation

    ENGLISH Bevel tilt setting 7. Initial operation 8. Operation After loosening the ratchet lock lever (44) at the rear, the sawhead tilts step- Connection of a dust col- Danger! lessly up to 48° from vertical to the left or lector Before starting any work, check right.

  • Page 9: Mitre Cuts

    ENGLISH Cutting the workpiece: Width Height Hold workpiece against the fence. approx. approx. Push the safety lock to the side and press and hold the ON/OFF switch. 15° Slowly swing the sawhead fully 22.5° down, holding the handle firmly. 30° When sawing, exert only moderate pressure to keep the motor speed 45°...

  • Page 10: Compound Mitre Cuts

    ENGLISH If the sawhead is to be tilted between 22.5 ° and 48° to the right, Note: Note: swing the hinged fence down. The track arm holder engages at For the groove to be cut at the positive stops at the 0°, 22.5°, and 45° desired depth across the whole work- Locking screw of the track arm loos- position.

  • Page 11: Drive Belt Tensioning

    ENGLISH In the upper starting position of the sawhead the safety lock must lock the retractable blade guard to prevent unintentional opening. Check the saw blade lock – the saw blade must turn freely. Drive belt tensioning The drive belt, running on the right-hand side of the sawhead behind a plastic cover, needs to be re-tensioned if it can Mount the new saw blade (53) –...

  • Page 12: Adjustments

    ENGLISH Lever the table insert (61) up with a Machine storage screwdriver. Doing so will damage Note: the table insert; it can not be used The rotating table engages at Danger! again. positive stops at the 0°, 15°, 22.5°, 30°, Store the saw in such way that it 45°, and 60°...

  • Page 13: Available Accessories

    ENGLISH Keep the supporting surfaces clean TCT saw blade 250 x 2.8 / 2.0 x 30 Check that all safety devices are – in particular, remove resin residue 80 trapezium-flat teeth operational again after each fault with a suitable cleaning and mainte- For wood, panels, ducting, NF service.

  • Page 14: Available Saw Blades

    ENGLISH Maximum workpiece cross section Standard cross cuts width / height 285 / 81 285 / 81 Mitre cuts (rotating table 45°) width / height 200 / 81 200 / 81 Bevel cutss (track arm holder 45° left) width / height 285 / 50 285 / 50 Compound mitre cuts (rotating table 45°...
  • Page 15 U3a0246.fm 091 005 7561 091 005 8010 091 005 7553 091 005 7537 091 005 7545 091 005 7529 HW 250 x 2,8 / 2,0 x 30 24 W HW 250 x 2,4 / 1,8 x 30 48 W HW 250 x 2,4 / 1,8 x 30 60 W 091 003 0973 091 003 1058 091 003 0981...
