Page 1: User Manual
SW16-8PB 16 Port Fast Ethernet with 8 Port PoE Switch User Manual Version 1.2... -
Page 2: Ce Mark Warning
This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. -
Page 3: Unpacking Information
Unpacking Information Thank you for purchasing this switch. Before installation, please check that your package contains the following items. 1. One 8+8 10/100 PoE Switch 2. One power cord 3. User’s Manual Introduction General Description The device is a powerful, high-performance Fast Ethernet Switch, with all 8 ports capable of 10 or 100Mbps auto-negotiation operation (NWay),... -
Page 4: Key Features
eliminates effort constructing your network. You could easily connect a Wireless AP or a VoIP phone to this switch without looking outlets them. Over current protection and circuit shorting protection are also supported to ensure the safety. The switch is plug-n-play without any software to configure and also fully compliant with all kinds of network protocols. -
Page 5: The Front Panel
Supports MDI/MDI-X auto crossover Wire-speed packet filtering and forwarding rate Store-and-forward architecture filters fragment & CRC error packets Supports extensive LED indicators for network diagnostics Internal universal switching power supply FCC Class A, CE, VCCI Class A The Front Panel The front panel consists of LED indicators Please refer to the following paragraph for detailed LED definition. -
Page 6: The Rear Panel
System LED: Status Operation Steady Blue The switch is powered on Power The switch is powered off Port LEDs Status Operation Blue The port is connected Blinking Data transmitting 10/100M Blue /receiving. No valid link on this port One PoE compliant Blue device is connecting with this port. -
Page 7: Installation
Power Receptacle To be compatible with the electric service standards around the world, the switch is designed to afford the power supply in the range from100 to 240VAC, 50/60Hz. Please make sure that your outlet standard to be within this range. To power on the switch, please plug the female end of the power cord firmly into the receptacle of the switch and the other end into... - Page 8 beyond recommend moisture Desktop Installation 1. Install the switch on a level surface that can support the weight of the unit and the relevant components. 2. Plug the switch with the female end of the provided power cord and plug the male end to the power outlet.
- Page 9 Installation of Network Cables 1. Crossover or straight-through cable: All ports switch support Auto-MDI/MDI-X functionality. Both straight-through or crossover cables can be used to connect the switch 2. Category 3, 4, 5 or 5e UTP/STP cable: To make a valid connection and obtain the optimal performance.
- Page 10 Product Specifications IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX Standard IEEE802.3af Power over Ethernet IEEE802.3x flow control 16 * 10/100 Mbps auto MDI/MDI-X RJ-45 ports Interface (Port1~8 support PoE power feeding) Network Data 10/100 Mbps Rate Auto-negotiation Transmission 10/100Mbps Full-duplex, Mode Half-duplex System: Power indications Ports: 10/100M, PoE FCC Class A,...
-
Page 11: Technical Support
Technical Support Please visit our website for up-to-date support information: Website: www.pakedge.com Email: support@pakedge.com CONTACT INFORMATION: Pakedge Device & Software Inc. 1011 Edwards Road Burlingame, CA 94010 © Pakedge Device & Software Inc. 2009 All Rights Reserved...
