Angle Cylinders - St, Mt, Ht - Sno-Way STD200000 Service & Parts Manual

Back to Index
ITEM PART NO.
1 96001044
96101057
96001262
2 96005035
96101082
96005034
3 96005101
96101566
96005036
4 96100419
96101084
96100417
19

ANGLE CYLINDERS - ST, MT, HT

2
3
DESCRIPTION
Cylinder, Angle, 1" - ST................................................................................... 1
Cylinder, Angle, 1-1/4" - MT ............................................................................ 1
Cylinder, Angle, 1-1/2" - HT ............................................................................ 1
Kit, Seal, 1" - ST.............................................................................................. 1
Seal, Square End................................................................................. 1
Seal, Inner............................................................................................ 4
Seal, Domed (metal or plastic)............................................................. 1
Kit, Seal, 1-1/4" - MT....................................................................................... 1
Seal, Square End................................................................................. 1
Seal, Inner............................................................................................ 4
Seal, Domed (metal or plastic)............................................................. 1
Kit, Seal, 1-1/2" - HT ....................................................................................... 1
Seal, Square End................................................................................. 1
Seal, Inner............................................................................................ 4
Seal, Domed (metal or plastic)............................................................. 1
Nut, Gland, 1" (includes Wiper) - ST............................................................... 1
Nut, Gland, 1-1/4" (includes Wiper) - MT ........................................................ 1
Nut, Gland, 1-1/2" (includes Wiper) - HT ........................................................ 1
Ring, Guide, 1" - ST ........................................................................................ 1
Ring, Guide, 1-1/4" - MT ................................................................................. 1
Ring, Guide, 1-1/2" - HT.................................................................................. 1
4
1
QTY
