GRAVITY DOWN SYSTEM - STG, MTG, HTG
ITEM
PART NO.
1
96105043
96001261
2
96005034
96005046
3
96005036
96005100
17
LIFT CYLINDERS
2
3
DESCRIPTION
Cylinder, Lift, 1-1/2" (Single Action) - STG ..................................................... 1
Cylinder, LIft, 2" (Single Action) - MTG & HTG............................................... 1
Kit, Seal, For 1-1/2" Cylinder - STG................................................................ 1
Kit, Seal, For 2" Cylinder - MTG & HTG ......................................................... 1
Nut, Gland For 1-1/2" Cylinder (includes Wiper) - STG .................................. 1
Nut, Gland, For 2" Cylinder (includes Wiper) - MTG & HTG........................... 1
1
QTY
