- Page 1 Back to Index OWNER’S INSTALLATION AND OPERATION MANUAL PLOW CONTROL PACKAGE FOR PLOW SERIAL NUMBERS AFTER STD200000, STG20000 MTD200000, MTG20000 HTD200000, HTG20000 HTV200000, HTVG10000 32C100000, 32D10000, 32G10000 26D10000, 26G10000 28V10000, 28VG10000 ©2005 Sno-Way® International 97100737G...
-
Page 2: Table Of Contents
Back to Index TABLE OF CONTENTS TABLE OF CONTENTS Page INTRODUCTION ...................... 1 SAFETY ........................2 INSTALLATION ......................3 Receiver Installation on Plow Power Pack ............. 3 FCC Statement of Conditions ................3 Industry Canada Statement ................3 Programming Receiver to Learn Transmitter Code (Wireless Control) ..3 Wire Harness Installation, Control Harness (Hard-Wired Control).... -
Page 3: Introduction
This manual was written for the assembly, installation and located on the bottom side of the controller, the Receiver maintenance your Sno-Way plow. Most serial number is located on the upper edge of the receiver. importantly, this manual provides an operating plan for This plate contains information that your Dealer needs to safe use. -
Page 4: Safety
ALWAYS inspect the unit periodically for defects. Parts begins. New decals can be obtained from Sno-Way or that are broken, missing or plainly worn must be replaced your local dealer. immediately. The unit, or any part of it should not be... -
Page 5: Installation
Back to Index INSTALLATION Receiver Installation on Plow Power Pack 6. Connect the single black ground wire on the receiver to the 5/16" bolt where the plow ground wire is attached 1. Loosen the four screws holding the pump cover in to the power unit. -
Page 6: Wire Harness Installation Control Harness (Hard-Wired Control)
Back to Index Remove the wire harness components from the bag of harness parts included in the control package. Install Control Harness Bracket WARNING 1. Using bracket as a template, mark and drill two 9/32" holes into vehicle bumper or other suitable location for mounting of harness bracket. - Page 7 Back to Index 4. When operating vehicle without plow attached, install clean repair should the plow ever be removed. Simply weatherproof cover onto connector to protect electrical place a piece of duct tape on the back side of the carpet contacts.
- Page 8 If the contact does not come out of the connector, it is properly installed. NOTE: A contact insertion tool is available from Sno-Way, part number 96105325. 9. After the three wires have been inserted into the connector, screw the strain relief onto the connector and then screw the boot onto the strain relief.
-
Page 9: Operation
The round button in the lower left has no function at this time, and was designed into the controller for possible 1. The Sno-Way Snow Plow Control System includes a future use. hand held controller. When a switch is actuated, the... -
Page 10: Functions - Joystick V Plow
Sno-Way snowplow. NOTE: For proper procedure in mounting and removal of The joystick on the top left side of the controller controls the snow plow, refer to your Sno-Way plow Owner’s the ’Raise’ and ’Lower’ functions. Pulling the joystick Manual. -
Page 11: Notes
Back to Index NOTES... -
Page 12: Wiring Schematic (Straight Blade - Down Pressure System)
Back to Index WIRING SCHEMATIC (STRAIGHT BLADE - DOWN PRESSURE SYSTEM) -
Page 13: Wiring Schematic (Straight Blade - Gravity Down System)
Back to Index WIRING SCHEMATIC (STRAIGHT BLADE - GRAVITY DOWN SYSTEM) -
Page 14: Wiring Schematic (V Plow - Down Pressure System)
Back to Index WIRING SCHEMATIC (V PLOW - DOWN PRESSURE SYSTEM) -
Page 15: Wiring Schematic (V Plow - Gravity Down System)
Back to Index WIRING SCHEMATIC (V PLOW - GRAVITY DOWN SYSTEM) -
Page 16: Warranty
FIVE YEAR STRUCTURAL LIMITED WARRANTY COVERAGE The Sno-Way snow plow structural elements are warranted to be free from defects in materials and workmanship for a period of five years from date of delivery from an authorized Sno-Way Dealer. The Sno-Way Warranty Registration card for the product must be properly filled out and mailed to Sno-Way within 30 days of date of purchase to obtain benefits of this section of warranty.
