- Page 1 AMX/Panja Viewpoint Training Manual Version 3...
-
Page 2: Table Of Contents
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Battery Charging…… ………………………………………2 Getting Started……………………………………………3-4 Muting……………………………………………………… 5 Volume Control……………………………………………. 5 Button Reference Guide……………………………………. 6 Instructor Camera Controls………………………………… 7 Student Camera Controls……………………………………7 Camera Presets……………………………………………... 8 Auto Tracking……………………………………………….9 Monitor Controls……………………………………….10-11 Picture-In-Picture (Sony TV)..……………………………..12 Picture-In-Picture (RCA TV)..……………………………..13... -
Page 3: Battery Charging
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 The AMX/Panja Viewpoint is the one-way Infrared remote device that controls the audio/visual equipment that comes with the CEC/Vision Athena Distance Learning Package. This device is the next step in the evolution of the distance learning equipment package. -
Page 4: Getting Started
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Getting Started The Viewpoint should be asleep (black screen) when you begin. Touch any area on the touch screen. The Viewpoint will now come on and your ViewPoint touch panel should now be at the last menu screen used. - Page 5 AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 INSTRUCTOR CAMERA: this is the camera usually mounted on the back wall, facing the front of the room. Think of it as the camera facing the instructor as they stand in the front of the room.
-
Page 6: Muting
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Muting buttons: three buttons (MUTE LOCAL, MUTE REMOTE and MUTE ALL) control the audio outputs of the system. Pressing MUTE LOCAL (Upper left external purple button) will mute your microphone audio to the remote sights. -
Page 7: Button Reference Guide
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Button Reference Guide = Sources = Audio controls = Monitor controls = Utilities/Help Copyright 2003, Video Images Indiana - 6 -... -
Page 8: Instructor Camera Controls
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 SOURCE SUBMENUS Cameras: When either the INSTRUCTOR or STUDENT CAMERA buttons are pressed a camera submenu appears. PAN: (Directions are from the camera’s perspective.) LEFT ARROW - used to pan (turn) camera to the left... -
Page 9: Camera Presets
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 HOW TO PRESET A CAMERA POSITION Adjust the camera position using the Pan, Tilt and Zoom controls until you get a properly “framed” view of your room and participants. Using the ViewPoint touch panel, these camera positions can be saved as presets. -
Page 10: Auto Tracking
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 AUTO TRACKING The instructor camera and student camera both have auto- tracking capabilities. To use it, complete the following steps. 1. Press the ON/OFF button in the tracking menu. -
Page 11: Monitor Controls
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Monitor controls: The Preview monitor is the 13” television monitor that is located on top of your workstation console. The large monitor is the 53” Sony television monitor that sits on top of the pedestal. - Page 12 AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Pressing the LARGE MONITOR button accesses the 53” monitor’s controls. The LARGE MONITOR and PIP submenus will appear. The LARGE MONITOR menu contains the TV/VIDEO button and DISPLAY button, as well as the CHANNEL CONTROL buttons.
-
Page 13: Picture-In-Picture (Sony Tv)
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Sony PIP Control Controlling the PIP (Picture in Picture) [Sony TV’s only. Please go to next page for RCA PIP control] The PIP submenu contains four buttons. Pressing the ON/OFF button will make the PIP box appear. -
Page 14: Picture-In-Picture (Rca Tv)
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 RCA PIP Control Controlling the PIP (Picture in Picture) RCA TV’s only. Please go to the previous page for Sony PIP control] The PIP submenu contains four buttons. Pressing the ON/OFF button will make the PIP box appear. -
Page 15: Vcr Controls
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 VCR Controls: STOP PLAY FAST FORWARD PAUSE REWIND RECORDING AN EVENT Using the VCR, you may record either the local or remote video source, but not both at the same time. To do this;... -
Page 16: Document Camera Controls
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Document Camera Controls: ZOOM ARROW DOWN-zoom out ZOOM ARROW UP-zoom in FOCUS ARROWS UP & DOWN-adjusts focus AUTO FOCUS ON/OFF-turns on or off auto focus function LIGHTING-pressing the LIGHTING button once will activate the backlight option. -
Page 17: Help Menu
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 HELP MENU Pressing the HELP button will bring up the Video Images Helpdesk screen, which displays the Video Images Helpdesk phone number. Additionally, there are four buttons at the bottom of the screen that provide tips for a successful distance-learning event. -
Page 18: System Menu
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 SYSTEM MENU The SYSTEM button when pressed will display the battery life indicator as well as the following selections: SYSTEM POWER ON/OFF-turns system power off and on EXTERNAL BUTTONS-displays functionality assigned to... -
Page 19: Cleaning The Touch Overlay
AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 CLEANING THE TOUCH OVERLAY The manufacturer suggests you clean the touch screen overlay after each day’s use. 1. Obtain two clean cotton cloths and spray bottle of cleaning solution consisting of 50% isopropyl alcohol and 50% water. - Page 20 AMX/Panja Viewpoint Training Manual By Video Images Indiana Revised Edition 3 Copyright 2003, Video Images Indiana - 19 -...
-
Page 21: Appendix
This type of battery resists developing a “memory”. • Each fully charged battery pack can deliver “up to 6 hours of non-stop operation” according to the manufacturer, PANJA / AMX. Recharging: • When cradled on the docking station the battery inside the Viewpoint will “trickle charge”...
