instruction manual
Mio R-1
Remote Control Device
C o n t r o l S y s t e m A c c e s s o r i e s

Advertisement

Table of Contents
loading

Related Manuals for AMX Mio R-1

Summary of Contents for AMX Mio R-1

  • Page 1 Mio R-1 Remote Control Device C o n t r o l S y s t e m A c c e s s o r i e s...
  • Page 2 RMA number. AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not liable for any claim made by a third party or by an AMX Dealer for a third party.
  • Page 3 The AMX Software is owned by AMX and is protected by United States copyright laws, patent laws, international treaty provisions, and/or state of Texas trade secret laws. Licensee may make copies of the AMX Software solely for backup or archival purposes. Licensee may not copy the written materials accompanying the AMX Software.

  • Page 5: Table Of Contents

    Inserting Batteries into The Mio R-1.................. 6 Battery Low Indicator......................6 Programming The Mio R-1 ..................7 Using Connector Ports on The Mio R-1 ................7 IR Code Matrix ........................8 Configuration Mode ......................9 Setting The IR Frequency ....................10 Persistent Serial Commands...................
  • Page 6 Table of Contents Mio R-1...

  • Page 7: Overview

    The Mio R-1 The Mio R-1 (FG147) remote provides custom control features, contained in an elegant handheld device. The Mio R-1 controls 6 different device modes, supports 3 macro functions and is capable of executing 219 functions. Selecting a source device sends a command to the master and runs predetermined events associated with that source.
  • Page 8 The Mio R-1 wakes up upon touching either the chrome side rails or pressing a button. You can reawaken the device by tilting it. The Mio R-1 is ready for input when you pick it up, but it can return to sleep in your hand. Errant jostling such as a bumped table will not wake the device unless you are holding it.
  • Page 9 Overview Specifications The Mio R-1 device specifications are as follows: Mio R-1 Specifications Battery 4 AAA Alkaline Batteries (5 hours battery life) Transmission AMX 38 KHz/455 KHz IR Frequencies Transmission • 100 feet at 38KHz Range (distance) • 50 feet at 455KHz...
  • Page 10 Overview Mio R-1...

  • Page 11: Mio R-1 Setup

    Mio R-1 Setup Installing Your Custom Buttons 1. Flip and turn the Mio R-1 device so that the buttons are facing away from you and the device is upside down. 2. Holding the device in both hands, place your thumbs on the battery door and push up to slide the battery door free.

  • Page 12: Inserting Batteries Into The Mio R-1

    Inserting Batteries into The Mio R-1 To install your 4 AAA batteries into the Mio R-1 device: 1. Flip and turn the Mio R-1 device so that the buttons are facing away from you and the device is upside down.

  • Page 13: Programming The Mio R-1

    To download KeypadBuilder Configuration Files: 1. Set the Mio R-1 Download mode to ON. See the Configuration Mode section for details. 2. Flip and turn the Mio R-1 device so that the buttons are facing away from you and the device is upside down.

  • Page 14: Ir Code Matrix

    Programming The Mio R-1 IR Code Matrix The IR Code emitted depends upon which of the 6 configurable modes is selected. Below is the list of codes for each button within each mode. IR Code Matrix Button Label Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6...

  • Page 15: Configuration Mode

    Programming The Mio R-1 IR Code Matrix (Cont.) Button Label Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6 S. REV Z PLAY A S. FWD Y REW E FWD D Configuration Mode The configuration mode allows you to set the following device features:...

  • Page 16: Setting The Ir Frequency

    Pressing "3" on the remote toggles the Download mode OFF and ON. The Download mode must be ON before you can download a file to the Mio R-1 device. While the Download mode is ON the device will not go to sleep. A power cycle will return the device to Download OFF.

  • Page 17: Persistent Serial Commands

    Programming The Mio R-1 Persistent Serial Commands There are a select number of persistent commands the Mio R-1 recognizes. Establish a HyperTerminal session with your device to use the following commands: Serial Commands @BRT Set Brightness level Syntax: "'BRIT-<awake brightness level>,<sleep brightness level>'"...
  • Page 18 Programming The Mio R-1 Mio R-1...

  • Page 19: Mio Remote Charging Base

    Mio-RCC rechargeable upgrade kit (FG147-03K). One charging base, a new back housing and a Mio-RBP rechargeable lithium ion battery (FG147-10) are included with the rechargeable upgrade kit. The charging base upgrade kit transforms the Mio R-1 into a rechargeable device. Begin with Installing The Rechargeable Battery for the Mio-RCC rechargeable upgrade kit (FG147-03K) or Charging The Mio Remote with Charging Base for the Mio-RCC charging base (FG147-02).

  • Page 20: Specifications

    • Back housing Kit only • Mio-RCC Charging base (FG147-02) with Power Supply • Power supply Kit only Other AMX Equipment: • Mio-RCC Charging Base (FG147-02) with Power Supply • Mio R-1 (FG147) • Mio R-2 RF 418 (FG147-418) • Mio R-2 RF 433 (FG147-433) •...

  • Page 21: Installing The Rechargeable Battery

    Mio Remote Charging Base Installing The Rechargeable Battery 1. Flip and turn the Mio R-1 device so that the buttons are facing away from you and the device is upside down. 2. Holding the device in both hands, place your thumbs on the battery door and push up to slide the battery door free.

  • Page 22: Charging The Mio Remote With Charging Base

    Battery Type 2. Pressing button "6" on the remote toggles the battery type between Normal and Recharge. The display indicates the selected type. The type of battery in the Mio R-1 dictates the battery type you need to set. 3. Press the EXIT key when you are finished.
  • Page 23 Programming The Mio R-1 Mio R-1...
  • Page 24 ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
