USB 3.0 to 2.5" SATA HDD Enclosure with ISO
S2510BU3ISO
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 02/03/2014
Advertisement
Table of Contents
Related Manuals for StarTech.com S2510BU3ISO
Summary of Contents for StarTech.com S2510BU3ISO
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 02/03/2014...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Top View ............................... 1 Front View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Installation ....................3 Hardware Installation ..........................3 How to Use Virtual iSO ..........................5 Use as External Hard Drive ........................6 Disconnecting the Hard Drive ...................... -
Page 4: Product Diagram
Product Diagram Top View Operation LEDs Mode Button Front View USB Port Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • 1x USB 3.0 to 2.5” SATA HDD enclosure • 1x Carrying Pouch • 1x USB 3.0 Cable • 1x Instruction Manual System Requirements • Computer system with available USB 3.0 port (5 Gbit/s) or USB 2.0 port (480Mbps) •... -
Page 6: Installation
Installation Hardware Installation WARNING! Hard drives and storage enclosures require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Be sure that you are properly grounded by wearing an anti-static strap when handling computer components or discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. - Page 7 3. Slide the back pane back into place. 4. With the enclosure fully assembled, connect the USB 3.0 cable from the enclosure to a USB port on the host computer system using the included cable. Instruction Manual...
-
Page 8: How To Use Virtual Iso
How to Use Virtual iSO Initial Setup NOTE: For ISO functionality The File System on the Hard Drive must be NTFS. ISO function is supported on Mac and Linux based operating systems. However, the NTFS requirement limits the ISO creation to Windows based computer systems. 1. -
Page 9: Use As External Hard Drive
5. Save the desired ISO file(s) in the directory of your choice. One file per folder. 6. Press the “<Mode” button to toggle to and light the LED next to the ISO file you wish to work as a virtual BR/DVD/CD-ROM. iSO_1 = _iso1 iSO_2 = _iso2 iSO_3 = _iso3... -
Page 10: Specifications
Specifications Host Interface USB 3.0 External Connectors 1 x USB 3.0 female Maximum Data Transfer Rate USB 3.0: 5 Gbit/s Chipset ID Fujitsu MB86C311 Encryption Type AES-256bit Power Adapter USB Powered Enclosure Material Plastic Operating Temperature 0°C ~ 60°C (32°F ~ 140°F) Storage Temperature -20°C ~ 60°C (-4°F ~ 76°F) Dimensions... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
