SA808 INSTRUCTION MANUAL
We'll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520. We're ready to help!
Scan for more information
san.us/447

Advertisement

loading
Need help?

Need help?

Do you have a question about the SA808 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sanus SA808

  • Page 1 SA808 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help! Scan for more information san.us/447...
  • Page 2 No — Perfect! 10 lb (4.5 kg) Yes — This product is NOT compatible. Visit Sanus.com or call 1-800-359-5520 [UK: 0800 056 2853] to fi nd a compatible product. What is your wall made of? Drywall with Unsure? Call 1-800-359-5520 [UK: 0800 056 2853]...
  • Page 3: Supplied Parts

    Supplied Parts WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! STEP 1 Parts STEP 2 Parts STEP 3 Parts...
  • Page 4 Box must be mounted between studs that are at least 406 mm (16 in.) apart. After installation there will not be enough space between the SA808 and the studs for electrical wires/cables, plumbing, ductwork, or insulation. Choose your SA808 location carefully.
  • Page 5 STEP 1 Cut Hole for Housing cont. Use a drywall saw or similar tool to cut the drywall where marked. Remove cut section of drywall. WARNING! ELECTRICAL SHOCK HAZARD! CUTTING OR DRILLING INTO ELECTRICAL WIRES OR CABLES CAN CAUSE DEATH OR SERIOUS PERSONAL INJURY! Always make certain the area behind mounting surfaces is free of electrical wires and cables before cutting, drilling, or installing fasteners.
  • Page 6 STEP 2 Install Housing Break out the sections of the housing that are required to install the power and cable outlets that are needed. NOTE: Knockouts are provided for ease of installation. Any unused knockouts that have been punched are to be closed up with a metal plug.
  • Page 7 STEP 2 Install Housing cont. Optionally, install a UL Listed 120 VAC electrical outlet box (not included) capable of attaching to the SA808 housing following the instructions included with the outlet box. Slide cables and additional wires through the hole in the bottom of the housing...
  • Page 8: Step 3 Install Components

    National Electric Code, ANSI/NFPA 70-1999. Refer to communication equipment manufacturer’s specifications for minimum spacings. To use the ECO-Mini (purchased separately) in the SA808, first remove feet. Fit the ECO-Mini into the ECO-Mini bracket...
  • Page 9 STEP 3 Install Components cont. ECO-Mini (purchased separately) with the SA808 - Optional Use two of the screws from the feet to secure the ECO-Mini in the bracket Slide the ECO-Mini and bracket into the top of the housing . Lock the bracket...
  • Page 10 STEP 3 Install Components cont. Use the elastic-velcro strap to attach components to the housing Power the ECO-Mini with the power cord supplied with the ECO-Mini.
  • Page 11 The SA808 can be installed behind most large wall plates of wall mounts or underneath or above most small wall plates. To access the SA808 after installation, disconnect all cables and wires from the TV, then either slide or remove the arm or TV mount from the wall plate.
  • Page 12 Dimensions 4.00 in. [101.6 mm] 125° 7.80 in. [198.1 mm] 5.84 in. [148.4 mm] 11.80 in. [299.8 mm] 13.80 in. [350.5 mm]...
  • Page 14 1. ¿Los accesorios pesan más de 4,5 kg (10 lb)? No — ¡Perfecto! Sí — Este producto NO es compatible. Visite Sanus.com o llame al 1-800-359-5520 (Reino Unido: 0800-0562853) para encontrar un producto compatible. 2. ¿De qué está hecha su pared? 3.
  • Page 15 PASO 3: Colocar los componentes Ver página 8 ECO-Mini (se vende por separado) con SA808 - Opcional NOTA: Distancias mínimas entre los accesorios y componentes y la carcasa de Tecnología de la Información Equipo de Comunicación se mantendrán para el funcionamiento correcto de este equipo cuando se instala de acuerdo con el Código Eléctrico Nacional, ANSI / NFPA 70-1999.
  • Page 16 Ver página 11 SA808 se puede instalar en la parte posterior de la mayoría de las placas murales de los soportes murales, debajo o encima de la mayoría de las placas murales pequeñas. Para tener acceso a SA808 después de la instalación, desconecte todos los cables del televisor, luego deslice o retire el brazo o el soporte del televisor de la placa mural.
  • Page 17 ESPAÑOL...
  • Page 20 Thank you for choosing Sanus! Please take a moment to let us know how we did: Call us: 1-800-359-5520 Email us: info@sanus.com Leave a review: sanus.com UK: 0800 056 2853 Find us on Facebook: SANUS Follow us on Twitter @sanussystems Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete.
