Summary of Contents for Sanus SA808
- Page 1 SA808 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help! Scan for easy install video san.us/447...
- Page 2 No — Perfect! 50 lb (22.7 kg) Yes — This product is NOT compatible. Visit Sanus.com or call 1-800-359-5520 [UK: 0800 056 2853] to fi nd a compatible product. What is your wall made of? Drywall with studs spaced a minimum of...
-
Page 3: Supplied Parts
Supplied Parts WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! STEP 1 Parts STEP 2 Parts STEP 3 Parts... - Page 4 STEP 1 Cut Hole for Housing CAUTION: Avoid potential personal injuries and property damage! ● Minimum drywall thickness 1/2 in. (13 mm). ● Box must be mounted between studs that are at least 16 in. (406 mm) apart. Locate the studs using an edge-to-edge stud finder. Verify the edges of the studs using an awl or thin nail. Mark the inner edges of the studs with pencil.
- Page 5 STEP 1 Cut Hole for Housing cont. Use a drywall saw or similar tool to cut the drywall where marked. Remove cut section of drywall. WARNING! Electric Shock Hazard! Avoid potential serious injuries or death. Ensure there are no electrical wires behind the wall before cutting or drilling into the surface.
- Page 6 STEP 2 Install Housing Break out the sections of the housing that are required to install the power and cable outlets that are needed. Thread the elastic-velcro strap into the housing...
- Page 7 STEP 2 Install Housing cont. Mount a power outlet (if needed) to the housing . Slide cables and additional wires through the hole in the bottom of the housing and the rubber cable grommet . Fit the cable grommet into the hole. Using a screwdriver, turn the screws in the corners of the housing .
-
Page 8: Step 3 Install Components
STEP 3 Install Components ECO-Mini (purchased separately) with the SA808 - Optional To use the ECO-Mini (purchased separately) in the SA808, first remove feet. Fit the ECO-Mini into the ECO-Mini bracket supplied with the SA808. - Page 9 STEP 3 Install Components cont. ECO-Mini (purchased separately) with the SA808 - Optional Use two of the screws from the feet to secure the ECO-Mini in the bracket Slide the ECO-Mini and bracket into the top of the housing . Lock the bracket...
- Page 10 STEP 3 Install Components cont. Use the elastic-velcro strap to attach components to the housing Power the ECO-Mini with the power cord supplied with the ECO-Mini.
- Page 11 The SA808 can be installed behind most large wall plates of wall mounts or underneath or above most small wall plates. To access the SA808 after installation, disconnect all cables and wires from the TV, then either slide or remove the arm or TV mount from the wall plate.
- Page 12 Dimensions 4.00 in. [101.6 mm] 125° 7.80 in. [198.1 mm] 5.83 in. [148.0 mm] 11.80 in. [299.8 mm] 13.80 in. [350.5 mm]...
- Page 14 1. Will your accessories weigh more than 50 lb (22.7 kg)? No — Perfect! Yes — This product is NOT compatible. Visit Sanus.com or call 1-800-359-5520 [UK: 0800 056 2853] to fi nd a compatible product. 2. What is your wall made of? 3.
- Page 15 Tighten only until secure. Do not over-tighten screws. STEP 3 Install Components - see page 8 ECO-Mini (purchased separately) with the SA808 - Optional To use the ECO-Mini (purchased separately) in the SA808, first remove feet. Fit the ECO-Mini into the ECO-Mini bracket supplied with the SA808.
- Page 16 The SA808 can be installed behind most large wall plates of wall mounts or underneath or above most small wall plates. To access the SA808 after installation, disconnect all cables and wires from the TV, then either slide or remove the arm or TV mount from the wall plate.
- Page 17 ESPAÑOL...
- Page 18 ©2013 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
