SAN55BA Instruction Manual
We are here to help!
Please contact Customer Service with any questions.
Customer Service
Americas: 800-359-5520 • 651-484-7988 • info@sanus.com
Europe, Middle East, and Africa: + 31 40 2324700 • europe.sanus@milestone.com
Asia Pacifi c: 86 755 8996 9226 • sanus.ap@milestone.com
·
·
SANUS
2221 Hwy 36 West
Saint Paul, MN 55113 USA
©2011 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
accents.sanus.com
(6904-002015 <01>)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sanus SAN55BA
Summary of Contents for Sanus SAN55BA
- Page 1 Saint Paul, MN 55113 USA ©2011 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
- Page 2 Avoid potential personal injuries and property damage! Do not use this product for any purpose not explicitly specifi ed by Sanus Systems. The wall must be capable of supporting fi ve times the weight of the monitor and mount combined.
-
Page 3: Required Tools
Required Tools 13mm 5.5mm 13mm (1/2 in.) (7/32 in (1/2 in. Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;... - Page 4 Select TV Hardware and Mount TV Brackets Choose screw length and diameter Hand thread screws into the threaded inserts on the back of your TV to determine the correct screw diameter (M4, M6, or M8). Verify that there are adequate threads to secure the brackets to the monitor.
- Page 5 Attach selected hardware For TVs with a fl at back Ensure the bracket is level on the back of the TV. If you require additional space for cables, recesses, or M4/M6/M8 protrusions, see the confi guration below. [02] [03] [02], [03] [11], [12] [04], [06], [07], [09]...
- Page 6 Adjust Strap For ease of access, straps should be level with the bottom of the TV. Wall Mounting - Wood Stud 13mm 5.5mm (1/2 in.) (7/32 in.) Locate stud Verify the center of the stud using an awl, a thin nail, or an edge to edge stud fi nder.
- Page 7 Wall Mounting - Wood Stud - continued Drill pilot holes as illustrated CAUTION: Improper use could reduce the holding power of the lag bolt. To avoid potential injuries or property damage: pilot holes MUST be drilled to a depth of 75 mm (3 in.), using a 5.5 mm (7/32 in.) diameter drill bit.
- Page 8 Wall Mounting - Solid Concrete and Concrete Block - continued Drill pilot holes as illustrated CAUTION: To avoid potential injuries or property damage: Pilot holes MUST be drilled to a depth of 75 mm (3 in.) using a 13 mm (1/2 in.) diameter drill bit.
- Page 9 Hang the TV with Mounting Brackets onto the Wall Plate HEAVY! You will need assistance with this step. Install the TV / Bracket assembly by fi tting the top hook of the mounting bracket over the top edge of the wall mount.
- Page 10 Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product.
