Shark
Read instructions carefully before attempting to assemble, install, operate or service this pressure
washer. Failure to comply with instructions could result in personal injury and/or property damage!
Output specifications are based on engine power curves at 100
meters above sea level and 25
dance with SAE J1349.
SERIAL NUMBER:
DATE PURCHASED:
FOR SALES AND SERVICE, PLEASE CONTACT:
R

SPECIFICATIONS

Pump Volume At Pump Head: 3.0 GPM/180 GPH
Pump Pressure At Pump Head: 3000 PSI
Burner Type: Fuel Oil Fired, 249,000 BTU/Hr.
Burner Fuel Pressure: 140 PSI
Machine Power: 9.0 HP Gasoline Engine, Manual Start
Machine Weight: 385 Lbs.
Shipping Weight: 415 Lbs.
Burner Exhaust Vent: 8"
Machine Dimensions: Length = 47", Width = 31", Height = 45"
MODEL DH3030HGB
OPERATING INSTRUCTIONS
AND PARTS MANUAL
o
C ambient temperature in accor-
SHARK PRESSURE WASHERS
21 INVERNESS WAY EAST
ENGLEWOOD, CO 80112
1-800-771-1881

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH3030HGB and is the answer not in the manual?

Questions and answers

Related Manuals for Shark DH3030HGB

Summary of Contents for Shark DH3030HGB

  • Page 1: Specifications

    MODEL DH3030HGB Shark OPERATING INSTRUCTIONS AND PARTS MANUAL Read instructions carefully before attempting to assemble, install, operate or service this pressure washer. Failure to comply with instructions could result in personal injury and/or property damage! SPECIFICATIONS Pump Volume At Pump Head: 3.0 GPM/180 GPH Pump Pressure At Pump Head: 3000 PSI Burner Type: Fuel Oil Fired, 249,000 BTU/Hr.
  • Page 2 Do not operate machine in areas where removed or become damaged they should flammable vapors, (gasoline, solvents, etc.) be replaced. Contact your dealer for may be present, as this machine may replacement decals. ignite the vapors. Page 2 Shark DH3030HGB...
  • Page 3 NOZZLE HOLDERS ENGINE BATTERY BOX BURNER SWITCH THERMOSTAT DETERGENT INJECTOR CONTROL BOX GARDEN HOSE CONNECTOR ENGINE OIL DRAIN OIL BURNER FUEL TANK COIL DRAIN PLUG PUMP OIL BURNER DETERGENT INLET LINE Figure 1 - Machine Component Layout Shark DH3030HGB Page 3...

  • Page 4: Parts Included

    Use a standard 12 volt automotive battery. Select a battery similar to the one in Figure 4 for proper fit and installation. RELIEF VALVE 8-3/4” 6-3/4” 10-1/2” PRESSURE HOSE Figure 4 - Battery Dimensions Figure 2 - Pressure Hose Installation Page 4 Shark DH3030HGB...

  • Page 5: Installation

    Normal precautions should main jet in the carburetor. Contact an authorized engine be taken by the operator to prevent moisture from reaching sales and service center for details. the pressure washer. It is recommended that a partition Shark DH3030HGB Page 5...

  • Page 6: Oil Burner

    Figure 7. The trigger lock should be used 2. Connect water supply hose to the garden hose con- whenever the trigger gun is not in use. nector located on pump. The water faucet and supply Page 6 Shark DH3030HGB...
  • Page 7 1. Insert detergent inlet line into container of mixed 6. Turn water supply OFF. detergent. Squeeze the trigger of the trigger gun. 7. Squeeze trigger of trigger gun to relieve system Open detergent control handle on the dual lance wand, pressure. Shark DH3030HGB Page 7...

  • Page 8: Maintenance

    40 hours of operation. After that, replace oil every 3 months or 500 hours of operation, whichever comes first. OIL FILL / DIPSTICK GARDEN HOSE CONNECTOR OIL DRAIN OIL GAUGE Figure 10 - Pump Lubrication Figure 9 - Winterizing Page 8 Shark DH3030HGB...

  • Page 9: Burner Fuel Filter

    Figure 23. The motor bearings are permanently An optional hour meter (P/N 783865) is available for use lubricated and will not require any additional lubrication. on the Model DH3030HGB. This hour meter will monitor the total hours of operation of the pressure washer to Relief Valve signal when routine maintenance is required.

  • Page 10: Troubleshooting Guide

    Operation. Engine not running. Engine must be running before burner will light. Inadequate water supply. Fully open faucet. Check for kinked or damaged hose. Use 5/8 inch mini- mum hose. Check for debris clogging inlet screen. Page 10 Shark DH3030HGB...
  • Page 11 IMPORTANT If the pressure washer demonstrates other symptoms or the corrective actions listed do not correct the problem, contact the local authorized Shark Pressure Washer Service Center. The Shark Pressure Washer Service Center can be identified by contacting:...
  • Page 12 When ordering from your dealer, please provide the following: Model Number: DH3030HGB Machine Serial Number: ________________________________ Component Part Number: _______________________________ Description: __________________________________________ FOR HELP OR ADDITIONAL INFORMATION, CONTACT: Customer Service Department Shark Pressure Washers 21 Inverness Way East Englewood, CO 80112...
  • Page 13 Fig. 17 Control Box Assembly 826167 Strain Relief 646089 Decal Warnings 703127 Strain Relief Nut 646352 Decal Shark Detergent Fig. 14 Coil Inlet Assembly Fig. 18 Fuel Tank Assembly 834153 Decal Fuel Type 829980 Shark Logo Plate Bolt 1/4” - 20 x 1/2”...
  • Page 14 Regulator Harness Fender Washer 5/16” Locknut 1/4” - 20 Flange Nut 5/16” - 18 Flat Washer 1/4” 646047 Decal Troubleshooting 213191 Insulation Order amount needed in feet. Fig. 22 Burner Assembly Standard hardware item available locally. Page 14 Shark DH3030HGB...
  • Page 15 Decal Operating Instructions 890783 Tag Gasoline Engine 815329 Snap Bushing 444462 Decal Caution Gasoline 646351 Decal Winterize 232025 Decal Important Battery 226222 Coil 646026 Decal Carbon Monoxide 859815 Grommet (Nozzle Holder) 646115 Decal Hot Surface 859806 Grommet Shark DH3030HGB Page 15...
  • Page 16 Ref. No. Part No. Description Qty. 935159 Filter Screen 754711 Tee 3/8” 961534 Tubing 1/4” 801102 Hex Nipple 3/8” x 1-1/2” 823989 Hose Clamp 873594 Detergent Injector 715744 Coil Drain Plug Order amount needed in feet. Page 16 Shark DH3030HGB...
  • Page 17 Thermal Relief Valve 801139 Garden Hose Connector 644751 Elbow 3/8” 890769 Tag Unloader 856035 Garden Hose Connector Gasket 707179 Hose 3/8” x 30” Replacement Parts 921813 Unloader Valve 830624 Pump Fig. 16 753209 Unloader Valve Repair Kit Shark DH3030HGB Page 17...
  • Page 18 Figure 16 - Pump, Exploded View Ref. No. Part No. Description Qty. Ref. No. Part No. Description Qty. 753084 Valve Plug Kit 753079 Oil Seal Kit 753083 Check Valve Kit 753085 Plunger Seal Kit Page 18 Shark DH3030HGB...
  • Page 19 Standard hardware item available locally. 615414 Control Box Back Order amount needed in feet Locknut 1/4” - 20 Bolt 1/4” - 20 x 3/4” Replacement Parts 955940 Thermostat 753134 O-Ring Kit 860140 Isolation Relay 875653 Switch Shark DH3030HGB Page 19...
  • Page 20 Fuel Tank Cap 309294 Nipple 3/8” Hose x 1/4” Hose 661277 Elbow 1/4” Hose x Stand Pipe 867368 Hose 1/4” Black 823988 Hose Clamp 890890 Fuel Tank 707116 Hose 1/4” Green 815230 Bushing Order amount needed in feet. Page 20 Shark DH3030HGB...
  • Page 21 Vibration Mounts 823988 Hose Clamp Flat Washer 5/16” 867368 Hose 1/4” Locknut 5/16” - 18 860285 Reducer 1/4” x M12 Order amount needed in feet. 698020 Nipple 1/4” x 1/4” Hose Standard hardware item available locally. Shark DH3030HGB Page 21...
  • Page 22 Relief Valve Seat 780565 Copper Washer 783845 Relief Valve Manifold 915630 Plug 3/8” 630720 Relief Valve Cartridge 698247 Hex Nipple 1/2” x 2” 644802 Street Elbow 3/8” 844806 Quick Disconnect Plug Standard hardware item available locally. Page 22 Shark DH3030HGB...
  • Page 23 799178 Pressure Nozzle (Yellow) 915786 Quick Disconnect Plug 799179 Pressure Nozzle (White) 691867 Trigger Gun 826170 Quick Disconnect Replacement Parts 900958 Detergent Nozzle 859762 Insulator Grip Assembly 936686 Dual Lance Wand 753179 Trigger Gun Repair Kit Shark DH3030HGB Page 23...
  • Page 24 Nipple 3/8” x 1/4” Hose 826167 Strain Relief 851080 Fuel Filter 703127 Strain Relief Nut 615279 Reducer Bushing 3/8” x 1/4” Replacement Parts 698200 Pipe Nipple 1/4” x 2-1/2” 661257 Street Elbow 1/4” 875490 Filter Element Page 24 Shark DH3030HGB...
  • Page 25 Ref. No. Part No. Description Qty. 900650 Nozzle 753046 Brush Kit 944422 Solenoid Valve 891210 Ignitor 919791 Fuel Pump 676894 Fuel Line 630730 Coupling 901230 Solenoid Metering Bolt 723355 Blower Fan 661413 Electrode (Pair) 784751 Motor Shark DH3030HGB Page 25...
  • Page 26 ISOLATION 30 AMP FUSE RELAY BRIDGE RECTIFIER THERMOSTAT BURNER SWITCH CAPILLARY TUBE CONTROL BOX THERMO- ENGINE STAT PROBE PRESSURE GRAY SWITCH GRAY VOLTAGE REGULATOR GRAY GRAY 12V BATTERY Figure 24 - Wiring Diagram Page 26 Shark DH3030HGB...
  • Page 27 OIL BURNER FUEL SOLENOID MOTOR RED/WHT CONTROLLER CAD CELL IGNITOR Figure 24 - Wiring Diagram Shark DH3030HGB Page 27...

  • Page 28: Warranty

    Shark liability in all events is limited to, and shall not exceed, the purchase price paid for the equipment. Shark liability excludes field labor charges, loss of use of the unit, loss of time or rental, inconvenience, or commercial loss and is limited to repair or replacement of defective parts only, at the option of Shark Pressure Washers.
