Shark DG-2323 Operating And Parts Manual
Dg series
Hide thumbs
Also See for DG-2323:
- Operating instructions and parts manual (22 pages) ,
- Operating instructions and parts manual (34 pages) ,
- Operating instructions and parts manual (22 pages)
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Shark DG-2323
Summary of Contents for Shark DG-2323
- Page 1 Model: dG operating instruction and parts manual ■ dG-2323 ■ dG-2324 ■ dG-2527 ■ dG-3030 ■ dG-3532 ■ dG-3835 ■ dG-2123 For technical assistance or the sHarK dealer nearest you visit our website at www.shark-pw.com 8.914-450.0 / 97-720...
-
Page 2: Table Of Contents
CoNTeNTS important safety information ..............3-4 component identification ................. 5 assembly instructions ................6 operating instructions................7-8 applying detergent and general operating techniques ......9 shut down and clean-up ..............10 storage ....................10 troubleshooting ................11-12 preventative maintenance ..............13 oil change record ................13 exploded View .................. -
Page 3: Important Safety Information
INTRodUCTIoN & IMpoRTaNT SafeTy INfoRMaTIoN thank you for purchasing this pressure Washer. WARNING: Risk of asphyxiation. WaRNING Use this product only in a well We reserve the right to make changes at any time ventilated area. without incurring any obligation. 5. - Page 4 IMpoRTaNT SafeTy INfoRMaTIoN 9. do not spray water on or near electrical compo- 13. never make adjustments on machine while in op- nents. eration. 14. Be certain all quick coupler fittings are secured WARNING: Flammable liquids WaRNING before using pressure washer. can create fumes which can ig- nite, causing property damage WARNING: Protect machine from...
-
Page 5: Component Identification
CoMpoNeNT IdeNTIfICaTIoN detergent Injector pressure Nozzle Unloader pump pump protector detergent bucket (not included) Inlet Screen Spray Gun Garden hose (not included) Trigger Straight Through Wand Starter Grip high pressure hose pump — develops high pressure. high pressure hose — connect one end to water pump discharge nipple and the other end to spray Starter Grip—... -
Page 6: Assembly Instructions
aSSeMbly INSTRUCTIoNS Carriage hose/Gun handle bolt Storage bracket alignment bolts holes frame assy. Studs STep 1: attach the handle to the STep 2: insert the carriage bolt STep 3: attach the spray gun/hose frame of the pressure washer. Note: through the holes from the outside storage handle and bracket to it may be necessary to move the of the unit and attach a nut from... -
Page 7: Operating Instructions
opeRaTING INSTRUCTIoNS dipstick oil dipstick oil Window STep 1: check engine oil level. oil level should be level with the bottom STep 2: remove shipping cap and of the oil filler neck. Be sure the machine is level when checking the oil install oil dipstick. - Page 8 opeRaTING INSTRUCTIoNS (CoN'T) on-off Switch STep 8: turn the engine switch to "on" position. STep 9: pull the starter grip. if the engine fails to start after 2 pulls, squeeze the trigger gun to release pres- on Briggs engines, move the throttle lever to "Fast" sure and repeat step.
-
Page 9: Applying Detergent And General Operating Techniques
deTeRGeNT aNd GeNeRal CleaNING TeChNIqUeS TheRMal pUMp pRoTeCTIoN WARNING: Some detergents WaRNING may be harmful if inhaled or if you run the engine on your pressure washer for 1-2 ingested, causing severe nau- minutes without pressing the trigger on the spray gun, sea, fainting or poisoning. -
Page 10: Shut Down And Clean-Up
ShUTTING doWN aNd CleaN-Up on-off Switch STep 1: remove detergent suc- STep 2: turn off the engine. STep 3: turn off water tion tube from container and insert supply. into one gallon of fresh water. slide nozzle forward for low pressure or to connect black detergent nozzle. -
Page 11: Troubleshooting
TRoUbleShooTING pRobleM poSSIble CaUSe SolUTIoN loW opeRaTING insufficient water supply. closed use larger garden hose; clean inlet water pReSSURe faucet. inlet hose kinked screen. open faucet. clogged inlet hose strainer check plumbing system for leaks. retape leaks with teflon tape. Faulty or mis-adjusted unloader adjust unloader for proper pressure. -
Page 12: Troubleshooting
TRoUbleShooTING pRobleM poSSIble CaUSe SolUTIoN eNGINe opeRaTeS not enough gas or engine oil Fill tank with gas. check oil level. Vapor lock developed by heat of day Keep gas tank full to avoid vapor locking. 15 MIN. TheN STopS obstruction in fuel filter clean or replace fuel filter. -
Page 13: Preventative Maintenance
pReveNTaTIve MaINTeNaNCe this pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. attention to regular preventa- tive maintenance procedures will assist in preserving the performance of your equipment. contact your dealer for maintenance. -
Page 14: Exploded View
exploded vIeW e-z Start valve for 9, 11, 13 hp honda dG Models 232336, engines only 232437, 252737, 303037, 353237, 383537, 212328 Models 232336, 323326 Models 232437, 252737, 3-24324, 3-27324 96-716, 97-718, 97-720 • rev. 7/07... -
Page 15: Exploded View Parts List
exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 10-08020 label, instructions, pc models 1 engine, see specifications page 11-0359 label, instructions, dB models 1 pump, see specifications page 11-0358 label, instructions, dg models 1 unloader, see specifications page 2-1904 strainer, plastic, 1/4"... -
Page 16: Exploded View Parts List
exploded vIeW paRTS lIST CoNT. ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 95-07102382 Hanger, Hose/Wand 95-07141120 Key, .185 sqr x 1.75" (5 Hp, 5.5 Hp, 6.5 Hp) 90-100473 Bolt, 1/4"-20 x 1-3/4", carriage, 95-07141121 Key, .247 sqr x 2.125" (9 Hp, Zinc 11 Hp, 13 Hp) 95-07104950 Handle, lower grab, chrome... -
Page 17: Vertical Exploded View
veRTICal exploded vIeW 25, 26 - on Reverse Side of plate To detergent Supply 96-716, 97-718, 97-720 • rev. 7/07... -
Page 18: Vertical Exploded View Parts List
veRTICal exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 4-011106 Wand, 18" m22 x 1/4" Qc 90-4001 Washer, 5/16" Flat 4-011137 spray gun, sK2, 3/8" inlet, 90-2001 nut, 5/16" esna lance W/m22 cplr 2-0103 grommet, rubber 2-2115 nipple, 3/8"... -
Page 19: Specifications
SpeCIfICaTIoNS machine pressure nozzle pump pump unloader engine engine model (psi) size Hose p/n part # model part # part # dB-232336 2300 8.739-106.0 9.120-032.0 2427g gc160 (5) 5-0101 dB-232439 2400 8.739-107.0 5-1250 Hg2530g 5-3329 gX160(5.5) 5-0104 dB-252739 2700 8.739-107.0 5-1250 Hg2530g 5-3329... -
Page 20: G1 Pump W/1" Hollow Shaft Exploded View And Parts List
G1 pUMp w/1" holloW ShafT exploded vIeW G3035G 5-1754, 5-1255, 5-1155, 5-1455 ToRqUe SpeCS item # Ft.-lbs G1 pUMp exploded vIeW aNd paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 17 70-180118 manifold stud Bolt 70-020292 crankcase see Kit Below plunger oil seal 18 70-140001 Washer 19 70-060306... - Page 21 G1 pUMp exploded vIeW aNd paRTS lIST (CoNT) ITeM paRT No. deSCRIpTIoN 35 70-050055 engine Flange 36 70-140002 spring Washer 37 70-180132 Flange screw 38 70-000109 crankshaft seal 39* 70-030211 plunger nut 40* see Kit Below plunger, 15mm 41* 70-140027 copper spacer 42* 70-060130 o-ring Ø1.78x5.28...
-
Page 22: G Pump W/3/4" Hollow Shaft Exploded View And Parts List
G pUMp w/3/4" holloW ShafT exploded vIeW G2530G 5-1750, 5-1250, 5-1451 ToRqUe SpeCS item # Ft.-lbs G pUMp exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 70-020292 crankcase 70-140001 Washer see Kit Below plunger oil seal 70-060306 copper Washer 3/8"... - Page 23 G pUMp exploded vIeW paRTS lIST (CoNT) ITeM paRT No. deSCRIpTIoN 70-000105 crankshaft seal 70-030211 plunger nut see Kit Below plunger, 15mm 70-140027 copper spacer 70-060130 o-ring Ø1.78x5.28 70-000913 teflon ring 70-000320 plunger rod 70-150204 connecting rod pin 70-010008 connecting rod 70-140102 spring Washer 70-180132...
-
Page 24: Hs-1 Pump Exploded View And Parts List
S-1 pUMp exploded vIeW 5-1262, 5-1461, 5-1462, 5-1762 ToRqUe SpeCS item # Ft.-lbs S-1 pUMp exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 70-020232 crankcase 70-180112 Hexagonal screw 70-140002 Washer 70-060201 plunger guide 70-050056 closed Bearing Housing See Kit Below plunger oil seal 70-060109... - Page 25 pUMp exploded vIeW paRTS lIST (CoNT) ITeM paRT No. deSCRIpTIoN 70-140103 spring Washer 70-180221 engine screw 3/8" 70-140052 Washer 70-140053 spring Washer 70-000109 crankshaft seal 45* 70-030211 plunger nut 46* see Kit Below plunger, 15mm 47* 70-140027 copper spacer 48* 70-060130 o-ring Ø1.78x5.28 49* 70-000913 teflon ring...
-
Page 26: Faip 5-1100 Pump Exploded View And Parts List
faIp 5-1100 pUMp exploded vIeW 96-716, 97-718, 97-720 • rev. 7/07... - Page 27 faIp 5-1100 pUMp exploded vIeW paRTS lIST ITeM paRT # deSCRIpTIoN kIT qTy ITeM paRT # deSCRIpTIoN kIT qTy spring 18-190571 cap, oil 18-190593 Ball 18-190627 manifold Chemical o-ring 18-190575 o-ring Injection connection, chemical inlet g 18-190576 screw o-ring screw, Fitting 18-190577 connection, chemical inlet Back ring...
-
Page 28: 0-032.0 Pump Exploded Views And Parts Lists
pUMp exploded vIeW aNd paRTS lIST 9.120-032.0 ITeM paRT # deSCRIpTIoN ITeM paRT # deSCRIpTIoN 9.175-007.0 unloader assembly 6.362-851.0 o-ring, d. 4 x 2 nBr 90 6.362-384.0 o-ring seal, 9.0 x 1.5 9-154-036.0 m18 pipe plug 6.362-480.0 o-ring seal, 12.42 x 1.78 4.769-034.0 nozzle insert only for replacement... - Page 29 pUMp exploded vIeW paRTS lIST 9.120-032.0 piston view ITeM paRT # deSCRIpTIoN 9.139-193.0 spare parts list set 1 6.365-393.0 grooved ring 12 x 20 x 4/6 9.134-016.0 spacer, oil seal and seal Housing 6.363-058.0 grooved ring 9.155-011.0 Housing, low pressure seal 6.362-833.0 o-ring seal, 21.5 x 1.78 9.177-310.0...
-
Page 30: Vba35 Unloader Exploded View And Parts List
vba 35 UNloadeR exploded vIeW #5-3329, #5-3330 vba35 UNloadeR exploded vIeW paRTS lIST ITeM paRT # deSCRIpTIoN ITeM paRT # deSCRIpTIoN kIT qTy 70-020444 Body Valve 70-110207 poppet 70-020452 Body Valve 70-140802 seal Washer 3/8 70-060141 o-ring a, c 70-180004 Hollow Bolt, 3/8 70-150316 seat... - Page 31 PARTICULAR PURPOSE. SHARK does not authorize any other party, including authorized Dealers, to make any representa- tion or promise on behalf of SHARK, or to modify the terms, conditions, or limitations in any way. It is the buyer’s responsibility to ensure that the installation and use of SHARK products conforms to local codes. While SHARK attempts to assure that its products meet national codes, it cannot be responsible for how the customer chooses to use or install the product.
- Page 32 Form #8.914-450.0 / 97-720 • revised 7/07 • printed in u.s.a.
