Dear customer, Thank you for choosing this LCD color TV. We expect our product and service will deliver many years of visual enjoyment. This manual is to guide you to set up and operate your TV as quickly as possible. Please read all the safety and operation instructions carefully before you begin, then follow the instructions carefully.
IMPORTANT SAFEGUARD FIRE AND SHOCK PRECAUTIONS Adequate ventilation must be provided to prevent heat build up inside the unit. Keep the inside of unit free from foreign objects, such as hairpins, nails, paper, etc. Do not put the set into a bookcase or other enclosures in which it would be poorly ventilated.
Selecting a location for the TV 1) Place the TV on a sturdy platform (away from direct sunlight for optimal viewing). 2) Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating which may damage the TV.(150mm minimum recommended distance around covered enclosure Note: Please contact retail dealer for wall mounting.
Back Connections HI7600501-L3205 COMPONENT VIDE VIDE ACINPUT RS-232 AUDIO/R AUDIO/L AUDIO/R VIDEO AUDIO/L COMPONENTIN2 Connector Description AC INPUT Connect the power cord to this connector. RS-232 For service purposes ONLY (will not support consumer products) Plug headphone into this jack. When headphones are plugged in, no sound Headphone jack comes from the headphones.
Connecting your TV SPDIF HDMI1 HDMI2 HDMI3 PC/DVIAUDIO IN VIDEO AUDIO/L AUDIO/R ANt75 COMPONENT IN1 SVIDEO1 S-VIDEO2 ACINPUT RS-232 AUDIO/L AUDIO/R VIDEO AUDIO/L AUDIO/R COMPONENT IN2 Power Input Power Input Whenever you connect an audio system to your set ensure that all elements are switched off When connecting an external device, match the color of the connection terminal to the cable.
Connecting an Aerial (For analogue and Digital signals) To view television channels correctly, a signal must be received by the set from the following source: -An outdoor VHF/UHF antenna Connecting External A/V Devices -Connect a Video RCA or S-VIDEO cable to an appropriate external A/V device such as a VCR, DVD or Camcorder. - Connect RCA audio cables to “R -AUDIO - L”...
What is HDMI? - HDMI, or high-definition multimedia interface, is a next-generation interface that enables the transmission of digital audio and video signals using a single cable without compression. -“Multimedia interface” is a more accurate name for it especially because it allows multiple channels of digital audio (5.1 channels).The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.
Using the remote control Preparing the remote control for use Installing the remote control batteries 1) Open the battery cover on the back of the remote control. 2) Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. 3) Close the battery cover.
Using the remote control Learning about the remote control Remote sensing Window Power Indicator On/Off(Standby) Available source selection SLEEP SOURCE Set the sleep time For direct channel access To return to the last view program LAST Digital TV/Analog TV signal Fast access to your saved favorite programs Select the HDMI source Select the component source...
Power ON/OFF Turning on: Connect the TV to an AC power outlet and turn on the power switch located below the front right hand Ø side of unit. The power indicator will initially be red and then will change to blue. A few seconds later an image will appear on the screen.
Display channel information Press [INFO] button to view current channel information in TV source. Press [EPG] button to view channel information in digital signal source. Select picture modes Picture Mode Press the [PICTURE] button to select between 4 different pre-adjusted picture modes: Vivid PICTURE Standard...
Menu System You can conveniently control all functions of your television using an advanced menu system which is visible on the screen via the On Screen Display (OSD) . Press the [ Menu] button to access the menu system. Six submenus will be immediately available: Picture, Audio, Screen, Channel, Lock Settings, System.
Installing in television channels Your television has been pre-adjusted to receive the five major TV networks available (only available in analogue TV mode) in capital cities of Australia; however you can add or delete channels at any time using the functions under the Channel submenu.
Page 18
Fine tuning [Menu, Channel , Fine Tune] Under poor reception conditions, or when receiving analogue signals from distant TV stations, the picture quality might be improved by using the Fine Tune option in the Channel submenu. Select Fine Tune and adjust to display the best image using [v+/-] buttons.
Adjusting the Picture [Menu, Picture, ...] Picture A wide variety of adjustments and optional advanced picture enhancement features Brightness Contrast are available in the Picture submenu. Their purpose is described below. Saturation Sharpness Color Temp. Cold Enhanced Settings : Move : Change EXIT/MENU: Exit The purpose and recommended use of these features is explained below.
Controlling the Audio The Audio [Menu, Audio,...] submenu contains all controls necessary to adjust audio to suit your needs and preferences. Audio AVC - 'Automatic Volume Control' Balance Lessens the gap in audio volume between the networks. DigitalAudio Equalizer Settings With the Digital Audio (PCM, 5.1 CH Audio) effect, you can enjoy higher quality audio.
Lock Settings The Lock Settings [Menu, Lock Settings,...] submenu contains Parental Guidance, Child Lock Settings Lock, Change Password, y ou can adjust them for your requirements. Parental Guidance Block None Hotel Lock Change Password [Menu, System, Change Password] Child Lock Change Password -Set and change your password to protect your TV settings.
Page 22
Controlling the System [Fig. 1] The System [Menu, System,...] submenu contains: Bluescreen, SetupWizard, System OSD Settings, Time and Factory reset. You can adjust them to your liking. Bluescreen SetupWizard OSD Settings Time Bluescreen setting [Menu, System, Bluescreen] Factory Reset :Move : Change MENU : Back...
Lock Settings Hotel Lock [Menu, Lock Settings, Hotel Lock] Lock Settings Parental Guidance Block None -An option to secure major settings in place.(Used for commercial purpose only) Hotel Lock Child Lock If you set the Hotel Lock “On”, you can change some of its options to control some of the Change Password functions, and the password protection is being activated, Most of OSD functions are locked except inputting password.
Using the TELETEXT Activating teletext Teletext is only available on a specific digital/analogue television station, example, Channel 7 (in digital television station). Select the channel that is broadcasting the desired Teletext program. Press [TEXT/MIX] button on the remote control to enter the Teletext mode and press the [CANCEL] /[D/A]button to exit the Teletext mode.
Cleaning and care WARNING: Do not try to remove the cabinet back. Refer servicing to qualified service technicians. To clean the TV screen: 1) Unplug the TV to avoid possible shock hazard. 2) Use a clean cellulose sponge or chamois cloth dampened with a solution of mild detergent and warm water to clean the TV screen and trim.
Innovation is life Specifications Model HSLC8129HDI HSLC10629HDI LCD panel 32.0 inches TFT LCD 42.0 inches TFT LCD Native Screen 1366X768 Pixels Resolution Television system PAL B/G DVB-T PAL/NTSC color system VHF-L: 48.25 to 168.25MHz Channel coverage VHF-H: 175 .25 to 463.25MHz UHF: 471.25 to 863.25MHz...
