User's manual
Please read this manual carefully before
operating your TV set and retain it for further reference.
HL32K300L HL39K300PL
Model Number:
HL42K300PL
Part Number:
ES-G120117
Http://www.hisense.com.au
K300
series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HL32K300L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense HL32K300L

  • Page 1 K300 series User’s manual Please read this manual carefully before operating your TV set and retain it for further reference. HL32K300L HL39K300PL Model Number: HL42K300PL Part Number: ES-G120117 Http://www.hisense.com.au...
  • Page 2 Ver 2012-02-24 HISENSE WARRANTY TERMS AND CONDITIONS 1. HISENSE Australia will provide parts and labour to you the Customer as set d. Normal maintenance costs and costs incurred through the installation of items listed as requiring periodic replacement; out herein.
  • Page 3 12 MONTHS IN HOME REPLACEMENT LCD WARRANTY* Hisense Australia will provide its nearest service centre for repairs or replacement under warranty. You will need to ensure that you have already called Hisense Warranty Centre and have received a JOB NUMBER.
  • Page 4 This page has been left blank intentionally.
  • Page 5: Table Of Contents

    Table of Contents Table of Contents Hisense Declaration................... Important safety precautions..............Safeguards..................Warning..................Setting Up....................Accessories..................Installing the Stand................. TV Front..................TV Rear..................Rear TV Connectors............... Connection Instructions..............Using the Remote Control................. Installing batteries................The Remote Control Panel.............. Quick starts..................
  • Page 6: Hisense Declaration

    Hisense reserves the rights to restrict the use or access of certain content or service. As the content and service are transmitted through third party’s network and transmission facilities, Hisense undertakes no customer...
  • Page 7: Important Safety Precautions

    Important safety precautions Safeguards This symbol alerts user about the presence of ATTENTION a dangerous voltage not isolated inside the product which can be sufficiently powerful to RISK OF SHOCK constitute a risk of electrocution. ELECTRIC This symbol alerts user about the presence of Do not open the back cover important operating instructions and In no case the user is allowed to operate inside the TV...
  • Page 8 Important safety precautions Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference. 2.
  • Page 9 Important safety precautions Safeguards 12.Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. Where installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 10: Warning

    Important safety precautions Warning If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: ● Using cabinets or stands recommended by the manufacturer of the television. ●...
  • Page 11: Setting Up

    Setting Up Accessories/Installing the Stand Accessories list ALCD101 Batteries Manual Book Remote AV/COMP Adapt AV OUT Adapt Installing the Stand 1. Secure the stand column to the base plate with the 4 screws (M4 x L12) provided. 2. Secure the stand cover to the stand column vertically with the 2 screws (M4 x L12) provided.
  • Page 12: Tv Front

    Setting Up TV Front TV Front MENU SOURCE ˄ ˅ ˄ ˅ No. Component Component Description POWER Switch Press to turn the main power ON or OFF. POWER Indicator Red indicates standby mode. Blue shows that the unit is on. Remote sensor Receives signals from the remote control.
  • Page 13: Tv Rear

    Setting Up TV Rear TV Rear AC INPUT HDMI 1 HDMI 2 VGA AUDIO COMP/AV1/AV2 OPTICAL...
  • Page 14: Rear Tv Connectors

    Setting Up Rear TV Connectors Brief Description Cables Connectors ANT 75Ω Connect an outdoor VHF/UHF antenna Yellow White Connect a composite video cable and left-right audio cables from optical equipment. Yellow White Connect a component video cable and left-right audio cables from optical equipment.
  • Page 15: Connection Instructions

    Setting Up Connection Instructions ■ Connecting an Aerial (For analogue and digital signals) To view television channels correctly, a signal must be received by the set from the following source: -An outdoor VHF/UHF antenna -Before connecting any external device please connect the supplied 15 pin to RCA adaptor. ■...
  • Page 16 -Use an audio cable to connect the TV's WOOFER jack to the bass speaker's audio in jack. (It is suggested to use Passive Bass Speaker. The Max power Output is 7W (HL32K300L, HL39K300L) or 8W (HL42K300PL) with 8 ohm impedance speaker.)
  • Page 17: Using The Remote Control

    Using the Remote Control Installing batteries Installing the remote control batteries 1. Slide open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment.
  • Page 18: The Remote Control Panel

    Using the Remote Control The Remote Control Panel The Remote Control Panel Buttons instructions(from up to down) (1) Remote sensing Window. (2) Indicator glows from white to red when buttons are pressed. (3) D/A: Digital /Analog TV. (4) Power Standby: Power button. (5) Source: Available source selection.
  • Page 19: Quick Starts

    Using the Remote Control Quick start ■ Turning your TV on and off To turn your TV on: Connect the TV to an AC power outlet and an external antenna, then turn on the power via switch located below the front right hand side of unit. A few seconds later an image will appear on the screen. Use the setup wizard select your state and press [OK], then press [OK] again to start the turning process.
  • Page 20 Using the Remote Control Quick start ■ Selecting the picture mode ● To select a picture mode: Press the [Picture] button to select between 5 different pre-adjusted picture modes: Dynamic, Bright, Standard, Soft and User (configurable mode). The User mode automatically preserves your personal settings after adjusting brightness, colour and contrast etc.
  • Page 21 Using the Remote Control Quick start ■ Electronic Programming Guide (EPG) Provides convenient access to the television programs that will be available in the next 7 days. The information displayed by the EPG is made available by the commercial television networks for digital channels only. The EPG also provides a simple way to program the recording of your favourite programs.
  • Page 22: Changing The Tv Settings

    Changing the TV Settings Using the Installation Guide Menu The Installation Guide menu appears the first time you Installation Guide turn on the TV. It will assist you to specify the Mode Home Mode Mode Setting Settings, OSD Language, Country, Scan Type and Auto OSD Language English Tuning.
  • Page 23: Using The Channel Menu

    Changing the TV Settings Using the Channel Menu ● Press [Menu] to open the main menu. CHANNEL ● Press [▲/▼] to select Channel, then press [►/OK] to Country Australia enter the Channel menu. Tuning Type DTV+ATV ● Press [▲/▼] to select an option. Auto Tuning ●...
  • Page 24 Changing the TV Settings Using the Channel Menu ■ ATV Manual Tuning -In Analog signal source Manual Install is only needed when analogue channels are not found with an automatic tuning. ● Press [▲/▼] to select ATV Manual Tuning, then press [►/OK] to enter ATV Manual Tuning menu. ●...
  • Page 25: Using The Picture Menu

    Changing the TV Settings Using the Picture Menu PICTURE ● Press [Menu] to open the main menu. Color Temperature Normal Noise Reduction Medium ● Press [▲/▼] to select Picture, then press [►/OK] to enter the Picture menu. ● Press [▲/▼] to select an option. PICTURE ●...
  • Page 26: Using The Sound Menu

    Changing the TV Settings Using the Sound Menu SOUND ● Press [Menu] to open the main menu. Lip-Sync ● Press [▲/▼] to select Sound, then press [►/OK] to SOUND enter the Sound menu. Sound Mode Standard ● Press [▲/▼] to select an option. Equalizer ●...
  • Page 27: Using The Option Menu

    Changing the TV Settings Using the Option Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Function, then press [►/OK] to OPTION enter the Function menu. OSD Language Enlish ● Press [▲/▼] to select an option. Audio Language ●...
  • Page 28 Changing the TV Settings Using the Option Menu ● Press [Menu] to open the main menu. ● Press [▲/▼] to select Function, then press [►/OK] to OPTION enter the Function menu. Restore Factory Default ● Press [▲/▼] to select an option. PVR File System ●...
  • Page 29 Changing the TV Settings Using the Option Menu ■ Auto-Light - Set DBC (Dynamic Backlight Control) option on to enable Auto-Light. This feature increases the dynamic contrast ratio, that is the relative light intensity between black and white areas of the image. Some video content may produce brightness flickering, in which case DBC should be turned off.
  • Page 30: Using The Lock Menu

    Changing the TV Settings Using the Lock Menu ● Press [Menu] to open the main menu. LOCK ● Press [▲/▼] to select Lock, then press [►/OK] to enter Lock System the Lock menu. Change Password ● Press [▲/▼] to select an option. Block Program ●...
  • Page 31: Using The Screen Menu

    Changing the TV Settings Using the Screen Menu ● Press [Menu] to open the main menu. SCREEN ● Press [▲/▼] to select Screen, then press [►/OK] to H.Position enter the Screen menu. V.Position ● Press [▲/▼] to select an option. H.Size ●...
  • Page 32: Pc Setting

    Changing the TV Settings PC Setting PC Setting Set the PC Software properly to match one of the below options. Supported VGA Modes: VGA____ (640×480 60Hz) SVGA___ (800×600 60Hz) XGA____ (1024×768 60Hz) SXGA___ (1280×1024 60Hz) Note: Your PC/Notebook may not be able to display some of these resolutions. Take Windows XP as an example, and the Windows system display setting is as illustrated: 1.
  • Page 33: Using The Dmp Menu

    Changing the TV Settings Using the DMP Menu Information ● Press [Source] to open Source menu. File Name: ISP_Tool_4505 _MSTPVR LTDN46T28GA ● Press [▲/▼] to select DMP, then press MOVIE MUSIC [►/OK] to enter the DMP menu.(or press 20070516_21_ tek00000.png tek00001.png PHOTE [D/EMP] to enter the DMP menu.)
  • Page 34 Changing the TV Settings Using the DMP Menu ■ Watching a movie Select the MOVIE option. ● Press [▲/▼/◄/►] to select a movie, press [OK] to enter, then press [Play/Pause] to play the movie. Also you can select more than one movie at the same time, press [Play/Pause] to play all the movies. ●...
  • Page 35 Changing the TV Settings Using the DMP Menu Tool Bar Menu: If you've opened a photo, press [Menu] to open the play menu Tool Bar, the following items will be available: (1) - Back - Select previous photograph. (2) - Forward - Select next photograph. (3) - Rotates the photograph clockwise.
  • Page 36: Appendix

    Appendix Trouble shooting If you feel there's a problem with your TV, you can try turning off the TV then restart it. You can also check below chart of remedies. If the problem isn't resolved, please contact ph 1800 447 367. for further assistance.
  • Page 37: Specifications

    Wall Mount size 100mm x 100mm 200mm x 400mm 400mm x 400mm Temperature 5˚C~35˚C Environmental Conditions Humidity: 20%-80%RH Atmospheric pressure: 86kPa-106kPa NOTE: Hisense is committed to continued product improvement which may result in changes to specifications and appearance without previous notice.
  • Page 38 HL32K300L HL39K300PL HL42K300PL Http://www.hisense.com.au...
