Safety Information

For your own safety please read the following important safety instructions carefully
before attempting to connect this unit to the mains power supply. They will also enable
you to get the best performance from and prolong the life of the unit.

Voltage Selection

The rear panel includes a voltage selection switch with two settings: '115' and '230' .
Check to see that it is properly configured for your location before connecting AC
power. Actually, the AC input has a very wide input voltage range and can operate
over a frequency range of 47.5 to 52.5 or 57 to 63 Hz. At 115, the Essence One Series
will operate normally over a range of 95 to 132 VAC. At 230, the Essence One Series will
operate normally over a range of 190 to 264 VAC.
CAUTION: Always insure that the voltage setting is correct for your locality.
Incorrect configuration may blow fuses or cause erratic operation.
VOLTAGE SELECTOR
230V

Repairs

Do not service or repair this product unless properly qualified. Only a qualified
technician should perform repairs.

Fuses

The fuse holder is built into a drawer next to the IEC power connector.
CAUTION: For continued fire hazard protection always replace the fuses with
the correct size and type (1A 250V, 5 x 20 mm).
4
230
VOLTAGE SELECTOR
115V
Use tools to replace the fuses.
ASUS Essence One Series
115
