Introducing the SGI 1400 Family of Servers
Chassis Configurations
2
The SGI 1400 server is designed to either be mounted in a rack (rack mode) or stand
upright (pedestal mode). Figure 1 shows examples of these configurations. You must
contact your sales or service provider and purchase an adapter kit if you wish to change
the configuration of your server from one mode to another after receiving the unit.
For instructions on mounting your rack-mode server in a 19-inch equipment rack, see the
SGI 1400 Server Family User's Guide.
Table 1 SGI 1400 Server Physical Specifications
Specification Pedestal Mode
Height 48.26 cm (19 inches)
Width 31.12 cm (12.25 inches)
Depth 63.5 cm (25 inches)
Weight 38.25 kg (85 lbs) minimum
configuration
45 kg (100 lbs) maximum
configuration
Required front 25.4 cm (10 inches) (inlet airflow
clearance <35 ˚C / 95 ˚F)
Required rear 20.3 cm (8 inches) (no airflow
clearance restriction)
Required side 0.0 cm/inches for airflow (additional
clearance side clearance required for service)
Rack Mode
48.26 cm (7u)
19-inch rack
63.5 cm (25 inches)
38.25 kg (85 lbs) minimum
45 kg (100 lbs) maximum
10 inches (inlet airflow <35 ˚C /
95 ˚F)
20.3 cm (8 inches) (no airflow
restriction)
N/A
