Operating Other Manufactures' Components

This remote control supplied with the receiver can transmit control signals for other
manufacturers' VCRs, TVs, CATV converters and DBS tuners. By changing the
transmittable signals from preset ones to the other manufacturers', you can operate the
other manufacturer's components using this remote control.
When operating the other manufacturers' components, refer also to the manuals
supplied with them.
To operate these components with the remote control, first you need to set the
manufacturer's code each for the VCR, TV, CATV converter, and DBS tuner.
IMPORTANT:
When using the Remote Control, check to see if its remote control
AUDIO/TV
mode selector is set to the correct position:
/VCR
To operate an audio system, TV, and VCR, set it to "AUDIO/TV/
CATV
/DBS
VCR."
To operate a CATV converter and DBS tuner, set it to "CATV/
DBS."
To change the transmittable signals for operating another
manufacturer's TV
1. Set the remote control mode selector to "AUDIO/TV/
VCR."
2. Press and hold TV/CATV/DBS
3. Press TV/DBS.
4. Enter the manufacturer's code (three digits) using
buttons 1 – 9, and 0.
See the lists on pages 70 and 71 to find the code.
5. Release TV/CATV/DBS
The following buttons can be used for operating the TV
(with the remote control mode selector set to "AUDIO/TV/
VCR"):
TV/CATV/DBS : Turns on and off TV.
TV VOLUME +/–: Adjusts the volume.
TV/VIDEO: Sets the input mode (either TV or
VIDEO).
After pressing TV/DBS (with the remote control mode
selector set to "AUDIO/TV/VCR"), you can perform the
following operations on the TV:
CHANNEL +/–: Changes the channels.
1 – 10, 0, 100+(+10): Selects the TV channels.
100+(+10) button will function as the
ENTER button if your TV requires
pressing ENTER after selecting a
channel number.
6. Try to operate your TV by pressing TV/CATV/DBS
When your TV turns on or off, you have entered the correct code.
7. If there are more than one code listed for your brand of TV, try each one until
the correct one is entered.
67
.
.
RM-SR884RU REMOTE CONTROL
VCR1 ANALOG AUDIO
TV/CATV
/DIGITAL
/DBS
DVD VCR1 VCR2 VIDEO
CD TAPE/MD PHONO FM/AM
CNTR TONE CNTR
MENU
TV/DBS
1 2 3
SURROUND
TEST ENTER REAR L
MODE
4 5 6
SOUND
EFFECT REAR R
CONTROL
7 8 9
/P
CD
SEA MODE SUBWOOFER
DISC
10 0 +10
RETURN FM MODE/MUTE 100+
AUDIO/TV
/VCR
CATV
/DBS
CONTROL
VCR1 TAPE
SET EXIT
.
Note:
Refer also to the manual
supplied with your TV.
