OWNER'S MANUAL
2010
690 SMC USA
Art. no. 3211518en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 690 SMC USA 2010 and is the answer not in the manual?

Questions and answers

Related Manuals for KTM 690 SMC USA 2010

Summary of Contents for KTM 690 SMC USA 2010

  • Page 1 OWNER'S MANUAL 2010 690 SMC USA Art. no. 3211518en...
  • Page 3 DEAR KTM CUSTOMER Congratulations on your decision to buy a KTM motorcycle. You are now the owner of a state-of-the-art sports motorcycle that will give you DEAR KTM CUSTOMER enormous pleasure if you service and maintain it accordingly. We wish you a lot of enjoyment in riding this vehicle! Enter the serial numbers of your vehicle below.
  • Page 4 Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright owner. ISO 9001(12 100 6061) According to the international quality management standard ISO 9001, KTM uses quality assurance processes that lead to the maximum possible quality of the products.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Combination instrument - time .......... 35 TABLE OF CONTENTS MEANS OF REPRESENTATION ..........7 Setting the clock .............. 35 IMPORTANT INFORMATION ........... 8 Combination instrument - display ODO ....... 36 Overview of warning labels..........12 Combination instrument - setting/resetting TRIP 1....36 VIEW OF VEHICLE..............
  • Page 6 TABLE OF CONTENTS SERVICE PLAN ..............59 Cleaning the chain............79 Service schedule .............. 59 Checking the chain tension ..........80 MAINTENANCE WORK ON CHASSIS AND ENGINE ....62 Adjusting the chain tension ..........81 Jacking up front of motorcycle ........... 62 Checking the chain, rear sprocket and engine sprocket..
  • Page 7 TABLE OF CONTENTS Removing the seat ............115 Changing the engine oil and filter, cleaning the oil screens ..............146 Mounting the seat ............116 Draining the engine oil ..........146 Removing the battery ..........116 Removing the oil filter ..........
  • Page 8 TABLE OF CONTENTS AUXILIARY SUBSTANCES........... 185 STANDARDS..............188 INDEX ................189...

  • Page 9: Means Of Representation

    All work marked with this symbol requires specialist knowledge and technical understanding. In the interest of your own safety, have these jobs done in an authorized KTM workshop! There, your motorcycle will be serviced optimally by specially trained experts using the specialist tools required.

  • Page 10: Important Information

    Warranty The work prescribed in the service plan must only be carried out in an authorized KTM workshop and confirmed in the service record; oth- erwise all warranty claims will be disregarded. No warranty claim can be met for damage resulting from manipulation and/or other changes to the vehicle.
  • Page 11 Spare parts, accessories For your own safety, only use spare parts and accessory products that have been approved and/or recommended by KTM and have them installed by an authorized KTM workshop. KTM accepts no liability for other products and any resulting damage.
  • Page 12 IMPORTANT INFORMATION – Switch off the engine and remove the ignition key. – Use straps or other suitable devices to secure the motorcycle against accidents or falling over. Environment Offroad motorcycling is a wonderful sport and we naturally hope that you will be able to enjoy it to the fullest. However, it is a potential problem for the environment and can lead to conflicts with other persons.
  • Page 13 IMPORTANT INFORMATION...

  • Page 14: Overview Of Warning Labels

    IMPORTANT INFORMATION Overview of warning labels 100330-10...
  • Page 15 IMPORTANT INFORMATION Type label, Canada Type label, USA Information, emission control Information, noise emission Information, suspension setting Information, chain tension Information, fuel evaporation system Information, putting into operation 100341-01 Type label, Canada...
  • Page 16 IMPORTANT INFORMATION 100340-01 Type label, USA 100847-01 Information, emission control...
  • Page 17 IMPORTANT INFORMATION 100846-01 Information, noise emission Information, suspension setting 100344-01...
  • Page 18 IMPORTANT INFORMATION Information, chain tension 100338-01 Information, fuel evaporation system 100848-01 Information, putting into operation 700210-01...
  • Page 19 IMPORTANT INFORMATION Notes/warnings Pay close attention to the notes/warnings. Info Various information and warning labels are affixed to the vehicle. Do not remove information/warning labels. If they are missing, you or others may not recognize potential hazards and may therefore be injured. Grades of risks Danger Identifies a danger that will immediately and invariably lead to fatal or serious permanent injury if the appropriate measures are not...
  • Page 20 Noise emission warranty KTM Sportmotorcycle AG warrants that this exhaust system, at the time of sale, meets all applicable U.S. EPA Federal noise standards. This warranty extends to the first person who buys this exhaust system for purposes other than resale, and to all subsequent buyers.
  • Page 21 Consumer rights Warranty claims should be directed to an authorized KTM workshop. If you are not satisfied, please contact: KTM North America, Inc., Customer Support, 1119 Milan Ave., Amherst, OH 44001, USA Phone: (440) 985–3553...

  • Page 22: View Of Vehicle

    VIEW OF VEHICLE View of vehicle, front left side 100328-10...
  • Page 23 VIEW OF VEHICLE Hand brake lever Clutch lever Seat Filler cap Front brake caliper Shift lever Engine number Side stand Footrest Seat release strap...

  • Page 24: View Of Vehicle, Rear Right Side

    VIEW OF VEHICLE View of vehicle, rear right side 100329-10...
  • Page 25 VIEW OF VEHICLE Ignition/steering lock Light switch, flasher switch, horn button Rear mirror Combination instrument Emergency OFF switch, electric starter button Throttle grip Rear brake caliper Shock absorber rebound damping Foot brake pedal Engine oil level viewer...

  • Page 26: Location Of Serial Numbers

    LOCATION OF SERIAL NUMBERS Chassis number The chassis number is stamped on the steering head on the right.  100217-10 Type label Type label is located on the upper right frame tube below the seat.  100218-10...

  • Page 27: Key Number

    LOCATION OF SERIAL NUMBERS Key number The key number can be found on the KEYCODECARD.  Info You need the key number to order a spare key. Keep the KEYCODECARD in a safe place. 100179-10 Engine number The engine number is stamped on the left side of the engine under the engine sprocket.

  • Page 28: Fork Part Number

    LOCATION OF SERIAL NUMBERS Fork part number The fork part number is stamped on the inner side of the fork stub.  600480-10 Shock absorber part number The shock absorber part number is on the right of the shock absorber. ...

  • Page 29: Controls

    CONTROLS Clutch lever The clutch lever is fitted on the left side of the handlebar.  The clutch is hydraulically operated and self-adjusting. 700542-01 Hand brake lever The hand break lever is fitted on the right side of the handlebar. ...

  • Page 30: Light Switch

    CONTROLS Light switch The light switch is fitted on the left side of the handlebar.  Possible states Low beam on – Light switch is turned downwards. In this position, the low beam and tail light are switched on. High beam on – Light switch is turned upwards. In this position, the high beam and the tail light are switched on.

  • Page 31: Horn Button

    CONTROLS Horn button The horn button is fitted on the left side of the handlebar.  Possible states • Horn button in neutral position pressed – The horn is operated in this position. • Horn button 100224-10 Emergency OFF switch The emergency OFF switch is fitted on the right side of the handlebar.

  • Page 32: Electric Starter Button

    CONTROLS Electric starter button The electric starter button is fitted on the right side of the handlebar.  Possible states • Electric starter button in basic position pressed – In this position, the electric starter is actuated. • Electric starter button 100226-10 Ignition/steering lock The ignition/steering lock...

  • Page 33: Combination Instrument

    CONTROLS Combination instrument The combination instrument is installed in front of the handlebar. The combination instrument is divided into 4 function areas. Function buttons  Tachometer  Indicator lights  Display  400832-10 Combination instrument - function buttons 5.10 You can change the display mode with the MODE button ...

  • Page 34: Combination Instrument - Tachometer

    CONTROLS Combination instrument - tachometer 5.11 The tachometer shows the engine speed in revolutions per minute.  The red marking shows the excess speed range of the engine.  400834-10 Combination instrument - indicator lamps 5.12 The indicator lamps offer additional information about the operating state of the motorcy- cle.

  • Page 35: Combination Instrument - Display

    CONTROLS FI warning lamp (MIL) lights up/flashes orange – The OBD has detected an emission- or safety-critical fault. Battery warning lamp lights up red – Voltage in vehicle system too low. Combination instrument - display 5.13 When you switch on the ignition, all display segments light up for a second as a function test.

  • Page 36: Combination Instrument - Speedometer

    CONTROLS Combination instrument - speedometer 5.14 The speed is shown in kilometers per hour km/h or in miles per hour mph.  400838-10 Setting kilometers or miles 5.15 Info If you change the unit, the value ODO is retained and converted accordingly. Making the setting according to the country.

  • Page 37: Combination Instrument - Time

    CONTROLS – Switch on the ignition by turning the ignition key to position ON – Press the MODE button repeatedly until the ODO mode is active. – Keep the MODE button pressed until the display mode changes from km/h to mph or from mph to km/h.

  • Page 38: Combination Instrument - Display Odo

    CONTROLS – Switch on the ignition by turning the ignition key to position ON – Press the MODE button repeatedly until the ODO mode is active. – Keep the MODE button and the SET button pressed simultaneously. The time display begins to flash. –...

  • Page 39: Combination Instrument - Setting/Resetting Trip 2

    CONTROLS – Switch on the ignition by turning the ignition key to position ON – Press the MODE button repeatedly until the TRIP 1 mode is active. – Keep the SET button pressed. The TRIP 1 display is set to 0.0. 400840-01 Combination instrument - setting/resetting TRIP 2 5.20...

  • Page 40: Combination Instrument - Trip F Display

    CONTROLS Combination instrument - TRIP F display 5.21 If the fuel level drops to the reserve mark, the display automatically changes to TRIP F and starts to count from 0.0, regardless of the previous display mode. Info Parallel to the TRIP F display, the fuel warning light switches on. 400842-01 Combination instrument - coolant temperature indicator 5.22...

  • Page 41: Opening Filler Cap

    CONTROLS Opening filler cap 5.23 – Lift the cover of the filler cap and insert the ignition key.  – Turn the ignition key 90° counterclockwise and remove the filler cap. Info The filler cap has a tank air vent system. 100227-10 Closing filler cap 5.24...

  • Page 42: Handrails

    CONTROLS Handrails 5.25 The handrails are used for moving the motorcycle around.  When you have a passenger, the passenger can hold on the handrails during the journey. 100229-10 Seat release 5.26 The seat can be released using strap  100230-10...

  • Page 43: Passenger Footrests

    CONTROLS Passenger footrests 5.27 The passenger footrests can be folded up and down. Possible states Passenger footrests folded up – For operation without a passenger. • Passenger footrests folded down – For operation with a passenger. • 600640-01 Shift lever 5.28 The shift lever is mounted on the left side of the engine.

  • Page 44: Foot Brake Lever

    CONTROLS The gear positions can be seen in the photograph. The neutral or idle position is between the first and second gears. 600484-11 Foot brake lever 5.29 Foot brake lever is located in front of the right footrest.  The rear brake is engaged with the foot brake lever. 600485-10...

  • Page 45: Side Stand

    CONTROLS Side stand 5.30 The side stand is coupled with the safety electric starter system - see the riding instruc-  tions. Possible states Side stand folded out – The vehicle can be supported on the side stand. The safety •...

  • Page 46: General Tips And Hints On Putting Into Operation

    The front and rear wheels must be fitted with tires with similar tread patterns to prevent loss of control over the vehicle. Warning Danger of accidents Uncontrollable handling characteristic due to non-approved and/or non-recommended tires/wheels. – Only tires/wheels approved by KTM and with the corresponding speed index should be used. Warning Danger of accidents Reduced road grip with new tires. –...

  • Page 47: Running In The Engine

    When using your vehicle, remember that others may feel disturbed by excessive noise. – Make sure that the pre-delivery inspection work has been carried out by an authorized KTM workshop. You receive a delivery certificate and the service record at vehicle handover.

  • Page 48: Loading The Vehicle

    GENERAL TIPS AND HINTS ON PUTTING INTO OPERATION Loading the vehicle Warning Danger of accidents Unstable handling characteristics. – Do not exceed the maximum permitted weight and axle loads. The overall weight consists of: motorcycle operational and with a full tank, driver and passenger with protective clothing and helmet, baggage. Warning Danger of accidents Unstable handling characteristics due to incorrect mounting of suitcase and/or tank rucksack.
  • Page 49 GENERAL TIPS AND HINTS ON PUTTING INTO OPERATION Warning Danger of accidents Unstable handling characteristics due to slipped baggage. – Check the way your baggage is fixed regularly. Warning Danger of burns A hot exhaust system can burn baggage. – Fasten your baggage in such a way that it cannot be burned or singed by the hot exhaust system. –...

  • Page 50: Riding Instructions

    RIDING INSTRUCTIONS Checks before putting into operation Info Make sure that the motorcycle is in a perfect technical condition before use. In the interests of riding safety, make a habit of making a general check before you ride. – Check the engine oil level. ( p.

  • Page 51: Starting

    RIDING INSTRUCTIONS Starting Danger Danger of poisoning Exhaust gases are poisonous and inhaling them may result in unconsciousness and/or death. – When running the engine, always make sure there is sufficient ventilation, and do not start or run the engine in an enclosed space without an effective exhaust extraction system.

  • Page 52: Starting Up

    RIDING INSTRUCTIONS Info Do not press the electric starter button until the function test of the combination instrument is finished. When starting, DO NOT open the throttle. If you open the throttle during the start- ing procedure, fuel is not injected by the engine management system and the engine cannot start.
  • Page 53 RIDING INSTRUCTIONS Warning Danger of accidents Malfunctions caused by incorrect ignition key position. – Do not change the ignition key position during a journey. Warning Danger of accidents Distraction from traffic activity by adjustments to the vehicle. – Make all adjustments when the vehicle is at a standstill. Warning Risk of injury The passenger must be capable of sitting correctly on the passenger seat.
  • Page 54 If you continue with the coolant temperature warning lamp alight, you may have engine failure. Info If you hear unusual noises while riding, stop immediately, switch off the engine and contact an authorized KTM workshop.
  • Page 55 RIDING INSTRUCTIONS – When conditions allow (incline, road situation, etc.), you can shift into a higher gear. – Release the throttle while simultaneously pulling the clutch lever, shift into the next gear, release the clutch and open the throttle. Info You can see the positions of the 6 forward gears in the figure.

  • Page 56: Braking

    Danger of accidents Reduced braking efficiency caused by spongy pressure point of front or rear brake. – Check the brake system and do not continue riding. (Your authorized KTM workshop will be glad to help.) Warning Danger of accidents Failure of brake system.

  • Page 57: Stopping, Parking

    RIDING INSTRUCTIONS Warning Danger of accidents Delayed brake action on salted roads. – There may be salt deposits on the brake discs. In order to restore the normal braking efficiency, you will need to remove the deposits from the discs by carefully applying the brakes. –...

  • Page 58: Refueling

    RIDING INSTRUCTIONS – Do not park the vehicle near flammable or explosive substances. Do not place objects on the vehicle while it is still warm from being run. Always let the vehicle cool first. Note Material damage Damage and destruction of components by excessive load. –...
  • Page 59 RIDING INSTRUCTIONS Warning Danger of poisoning Fuel is poisonous and a health hazard. – Avoid contact of the fuel with skin, eyes and clothing. Do not inhale fuel vapors. If fuel gets into your eyes, rinse immediately with water and contact a doctor. Wash affected skin areas immediately with soap and water. If fuel is swallowed, contact a doc- tor immediately.
  • Page 60 RIDING INSTRUCTIONS – Press the SET button for two seconds.  The fuel level warning lamp switches off. TRIP F is set to 0.0 and appears in the  previous display mode. Info If you do not press the SET button , the reset takes place automatically after ...

  • Page 61: Service Plan

    • • • • • • • • Read out the fault memory using the KTM diagnostics tool. • • • • Change the engine oil and filter, clean the oil screens. p. 146) Check the front brake linings. ( p.
  • Page 62 • • • • • • Read out the fault memory using the KTM diagnostics tool after a test ride. • • • • Make the service entry in KTM DEALER.NET and in the service record. K10N: Once after 1,000 km (621.4 mi)
  • Page 63 SERVICE PLAN K75A: Every 7,500 km (4,660 mi) or annually K150A: Every 15,000 km (9,321 mi) or every 2 years K300A: Every 30,000 km (18,641 mi) or every 4 years...

  • Page 64: Maintenance Work On Chassis And Engine

    MAINTENANCE WORK ON CHASSIS AND ENGINE Jacking up front of motorcycle Note Danger of damage The parked vehicle may roll away or fall over. – Always place the vehicle on a firm and even surface. – Jack up the rear of the motorcycle. ( p.

  • Page 65: Jacking Up Rear Of Motorcycle

    MAINTENANCE WORK ON CHASSIS AND ENGINE Jacking up rear of motorcycle Note Danger of damage The parked vehicle may roll away or fall over. – Always place the vehicle on a firm and even surface. – Insert the work stand adapter in the work stand and screw it into the link forks. Work stand adapter (61029055110) Work stand rear (61029055100) –...

  • Page 66: Fork/Shock Absorber

    MAINTENANCE WORK ON CHASSIS AND ENGINE Fork/shock absorber The fork and the shock absorber offer many options of adapting the chassis to your riding style and the payload. Info To help you adapt the vehicle, we have summarized our findings in Table .

  • Page 67: Adjusting Rebound Damping Of Fork

    MAINTENANCE WORK ON CHASSIS AND ENGINE Guideline Compression damping Comfort 20 clicks Standard 15 clicks Sport 10 clicks Full payload 10 clicks Info Turn clockwise to increase damping, turn counterclockwise to reduce suspension damping. Adjusting rebound damping of fork Info The hydraulic rebound damping determines the fork rebound behavior.

  • Page 68: Compression Damping Of The Shock Absorber

    Danger Danger of accidents Disassembly of pressurized parts can lead to injury. – The shock absorber is filled with high density nitrogen. Adhere to the description provided. (Your authorized KTM workshop will be glad to help.) Info The low-speed setting can be seen during the slow to normal compression of the shock absorber.

  • Page 69: Adjusting The High-Speed Compression Damping Of The Shock Absorber

    Danger Danger of accidents Disassembly of pressurized parts can lead to injury. – The shock absorber is filled with high density nitrogen. Adhere to the description provided. (Your authorized KTM workshop will be glad to help.) Info The high-speed setting can be seen during the fast compression of the shock absorber.

  • Page 70: Adjusting The Rebound Damping Of The Shock Absorber

    Adjusting the rebound damping of the shock absorber 9.11 Danger Danger of accidents Disassembly of pressurized parts can lead to injury. – The shock absorber is filled with high density nitrogen. Adhere to the description provided. (Your authorized KTM workshop will be glad to help.)

  • Page 71: Measuring The Unloaded Rear Wheel Sag

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Turn adjusting screw clockwise to the last perceptible click.  – Turn back counterclockwise by the number of clicks corresponding to the shock absorber type. Guideline Rebound damping Comfort 20 clicks Standard 15 clicks Sport 10 clicks 100247-10...

  • Page 72: Checking The Static Sag Of The Shock Absorber

    MAINTENANCE WORK ON CHASSIS AND ENGINE Checking the static sag of the shock absorber 9.13 – Measure distance of rear wheel unloaded. ( p. 69)  – Ask someone to help you by holding the motorcycle upright. – Measure the distance between the rear axle and the fixed point again. 0 0 A –...

  • Page 73: Checking The Riding Sag Of The Shock Absorber

    Adjusting the spring preload of the shock absorber 9.15 Danger Danger of accidents Disassembly of pressurized parts can lead to injury. – The shock absorber is filled with high density nitrogen. Adhere to the description provided. (Your authorized KTM workshop will be glad to help.)

  • Page 74: Bleeding The Fork Legs

    MAINTENANCE WORK ON CHASSIS AND ENGINE Info Before changing the spring preload, make a note of the present setting, e.g., by measuring the length of the spring. – Remove the shock absorber. – After removing the shock absorber, clean it thoroughly. –...

  • Page 75: Cleaning The Dust Boots Of The Fork Legs

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove bleeder screws briefly.  Any excess pressure escapes from the interior of the fork. – Mount and tighten bleeder screws. Info Carry out this action on both fork legs. 100844-10 Cleaning the dust boots of the fork legs 9.17 –...

  • Page 76: Removing The Fork Protector

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Clean and oil the dust boots and inner fork tube of both fork legs. Universal oil spray ( p. 187) – Press the dust boots back into their normal position. – Remove excess oil. –...

  • Page 77: Installing The Fork Protector

    Danger of accidents Unstable vehicle handling from incorrect steering head bearing play. – Adjust the steering head bearing play without delay. (Your authorized KTM workshop will be glad to help.) Info If the bike is driven with play in the steering head bearing, the bearing and the bearing seats in the frame can become damaged with time.

  • Page 78: Adjusting Play Of Steering Head Bearing

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Move the handlebar to the straight-ahead position. Move the fork legs to and fro in the direction of travel. No play should be noticeable in the steering head bearing. » If there is noticeable play present: –...

  • Page 79: Handlebar Position

    MAINTENANCE WORK ON CHASSIS AND ENGINE Guideline Screw, top triple clamp 17 Nm (12.5 lbf ft) – Mount and tighten screw  Guideline Screw, steering stem 20 Nm Loctite ® 243™ (14.8 lbf ft) – Check the steering head bearing play. ( p.

  • Page 80: Adjusting Handlebar Position

    MAINTENANCE WORK ON CHASSIS AND ENGINE Adjusting handlebar position 9.23 – Remove the four screws . Remove the handlebar clamp. Remove the handlebar and  0 0 1 lay it to one side. 0 0 2 Info Protect the motorcycle and its attachments from damage by covering them. Do not bend the cables and lines.

  • Page 81: Checking The Chain For Dirt

    MAINTENANCE WORK ON CHASSIS AND ENGINE Checking the chain for dirt 9.24 – Check the chain for heavy soiling. » If the chain is very dirty: – Clean the chain. ( p. 79) 400678-01 Cleaning the chain 9.25 Warning Danger of accidents Oil or grease on the tires reduces their grip. –...

  • Page 82: Checking The Chain Tension

    MAINTENANCE WORK ON CHASSIS AND ENGINE Info The service life of the chain depends largely on its maintenance. – Clean the chain regularly. – Rinse off loose dirt with a soft jet of water. – Remove old grease remains with chain cleaner. Chain cleaner ( p.

  • Page 83: Adjusting The Chain Tension

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Lean the motorcycle on the side stand. – Shift gear to neutral. – Push the chain upward at a distance from the chain sliding guard and determine the  chain tension  Info The upper chain section must be taut.
  • Page 84 MAINTENANCE WORK ON CHASSIS AND ENGINE – Check the chain tension. ( p. 80) – Loosen nut  – Loosen nuts  – Adjust the chain tension by turning adjusting screws on the left and right.  Guideline Chain tension 5 mm (0.2 in) Turn the left and right adjusting screws so that the markings on the left and right...

  • Page 85: Checking The Chain, Rear Sprocket And Engine Sprocket

    MAINTENANCE WORK ON CHASSIS AND ENGINE Checking the chain, rear sprocket and engine sprocket 9.28 – Check the rear sprocket and engine sprocket for wear. » If the rear sprocket and engine sprocket are worn: – Replace the rear sprocket or engine sprocket. Info The engine sprocket, rear sprocket and chain should always be replaced together.
  • Page 86 MAINTENANCE WORK ON CHASSIS AND ENGINE – Shift into neutral; pull the lower chain section with specified weight  Guideline Weight of chain wear measurement 15 kg (33 lb.) – Measure distance of 18 chain links in the lower chain section. ...
  • Page 87 MAINTENANCE WORK ON CHASSIS AND ENGINE Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) – Check the chain guide for wear. » If the chain guide is worn: – Change the chain guide. – Check that the chain guide is firmly seated. »...

  • Page 88: Adjusting Chain Guide

    Remaining screws, chassis 10 Nm (7.4 lbf ft) 600635-10 Checking the brake discs 9.30 Warning Danger of accidents Reduced braking efficiency due to worn brake disc(s). – Change the worn brake disc(s) without delay. (Your authorized KTM workshop will be glad to help.)

  • Page 89: Adjusting The Basic Position Of The Hand Brake Lever

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Check the thickness of the front and rear brake discs in several places to ensure that it conforms to measurement  Info Wear reduces the thickness of the brake disc at the contact surface of the ...

  • Page 90: Checking The Front Brake Fluid Level

    Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.) – Move the brake fluid reservoir mounted on the handlebar to a horizontal position.
  • Page 91 Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.) Warning Environmental hazard Hazardous substances cause environmental damage.

  • Page 92: Checking The Front Brake Linings

    9.34 Warning Danger of accidents Reduced braking efficiency caused by worn brake linings. – Change worn brake linings immediately. (Your authorized KTM workshop will be glad to help.) Note Danger of accidents Reduced braking efficiency caused by damaged brake discs. – If the brake linings are not changed in time, the steel brake lining carriers grind on the brake disc. The braking effect is greatly...

  • Page 93: Changing The Front Brake Linings

    If brake fluid gets into your eyes, rinse thoroughly with water and contact a doctor immediately. Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.)
  • Page 94 Brake linings available from accessory suppliers are often not tested and approved for use on KTM vehicles. The construction and friction factor of the brake linings and therefore the brake power can differ considerably from the original KTM brake lin- ings.

  • Page 95: Removing Front Brake Linings

    Clean up overflowed or spilt brake fluid immediately with water. 100254-12 Removing front brake linings 9.36 Warning Danger of accident Brake system failure. – Maintenance work and repairs must be carried out professionally. (Your authorized KTM workshop will be glad to help.)

  • Page 96: Installing The Front Brake Linings

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Press the spring hanger of the spring forwards and withdraw the bolt   – Take off the springs . Remove brake linings   400421-11 – Remove screws and spacers . Remove the brake caliper. ...
  • Page 97 Brake linings available from accessory suppliers are often not tested and approved for use on KTM vehicles. The construction and friction factor of the brake linings and therefore the brake power can differ considerably from the original KTM brake lin- ings.

  • Page 98: Checking The Free Travel Of Foot Brake Lever

    MAINTENANCE WORK ON CHASSIS AND ENGINE Guideline Screw, front brake caliper M10x1.25 45 Nm Loctite ® 243™ (33.2 lbf ft) – Remove the fixation of the hand brake lever. Checking the free travel of foot brake lever 9.38 Warning Danger of accidents Brake system failure. –...

  • Page 99: Adjusting The Basic Position Of The Foot Brake Lever

    MAINTENANCE WORK ON CHASSIS AND ENGINE Adjusting the basic position of the foot brake lever 9.39 Warning Danger of accidents Brake system failure. – If there is no free travel on the foot brake lever, pressure builds up on the rear brake circuit. The rear brake can fail due to over- heating.

  • Page 100: Checking Rear Brake Fluid Level

    Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.) – Stand the vehicle upright.
  • Page 101 Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.) Warning Environmental hazard Hazardous substances cause environmental damage.

  • Page 102: Checking The Rear Brake Linings

    9.42 Warning Danger of accidents Reduced braking efficiency caused by worn brake linings. – Change worn brake linings immediately. (Your authorized KTM workshop will be glad to help.) Note Danger of accidents Reduced braking efficiency caused by damaged brake discs. – If the brake linings are not changed in time, the steel brake lining carriers grind on the brake disc. The braking effect is greatly...

  • Page 103: Changing Rear Brake Linings

    If brake fluid gets into your eyes, rinse thoroughly with water and contact a doctor immediately. Warning Danger of accidents Reduced braking effect caused by old brake fluid. – Change the brake fluid of the front and rear brakes according to the service schedule. (Your authorized KTM workshop will be glad to help.)
  • Page 104 Brake linings available from accessory suppliers are often not tested and approved for use on KTM vehicles. The construction and friction factor of the brake linings and therefore the brake power can differ considerably from the original KTM brake lin- ings.
  • Page 105 MAINTENANCE WORK ON CHASSIS AND ENGINE – Stand the vehicle upright. – Remove the screw cap with the membrane   – Press the brake caliper onto the brake disc by hand in order to push back the brake pis- tons.

  • Page 106: Removing Front Wheel

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Insert the brake pads, insert the bolt and mount the split pin. – Operate the foot brake lever repeatedly until the brake linings lie on the brake disc and there is a pressure point. –...

  • Page 107: Installing The Front Wheel

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Loosed screw and screw   – Screw out screw about 6 turns, press your hand on the screw to push the wheel spin-  dle out of the fork stub. Remove screw ...
  • Page 108 MAINTENANCE WORK ON CHASSIS AND ENGINE – Check the wheel bearing for damage and wear. » If the wheel bearing is damaged or worn: – Replace the wheel bearing. – Clean and grease the shaft seal rings and bearing surface of the distance bushings ...

  • Page 109: Removing Rear Wheel

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove the fixation of the hand brake lever. – Take the front from the work stand. ( p. 62) – Pull the front wheel brake and push down hard on the fork several times to align the fork legs.

  • Page 110: Installing The Rear Wheel

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Push the rear wheel forwards as far as possible and take the chain off the rear sprocket. Warning Danger of accidents Reduced braking efficiency caused by damaged brake discs. – Always lay the wheel down in such a way that the brake disc is not damaged. –...
  • Page 111 MAINTENANCE WORK ON CHASSIS AND ENGINE – Check the wheel bearing for damage and wear. » If the wheel bearing is damaged or worn: – Replace the wheel bearing. – Remove the bushing . Clean and grease the working surfaces of the bushing and shaft ...

  • Page 112: Checking The Rear Hub Rubber Dampers

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Take the rear from the work stand. ( p. 63) Checking the rear hub rubber dampers 9.48 Info The engine power is transmitted from the rear sprocket to the rear wheel via 6 rubber dampers. They eventually wear out during operation.

  • Page 113: Checking The Tire Condition

    The front and rear wheels must be fitted with tires with similar tread patterns to prevent loss of control over the vehicle. Warning Danger of accidents Uncontrollable handling characteristic due to non-approved and/or non-recommended tires/wheels. – Only tires/wheels approved by KTM and with the corresponding speed index should be used. Warning Danger of accidents Reduced road grip with new tires. –...

  • Page 114: Checking The Spoke Tension

    If a tire is more than five years old: – Change the tires. Checking the spoke tension 9.50 Warning Danger of accidents Instable handling due to incorrect spoke tension. – Ensure that the spoke tension is correct. (Your authorized KTM workshop will be glad to help.)
  • Page 115 MAINTENANCE WORK ON CHASSIS AND ENGINE Info A loose spoke causes wheel imbalance and rapidly leads to more loose spokes. If the spokes are too tight, they can break due to local overload. Check the spoke tension regularly, especially on a new motorcycle. –...

  • Page 116: Tubeless Tire System

    This results in better handling and riding comfort. The rigid rim design results in a spoke wheel that is almost entirely maintenance-free. KTM recommends that the tubeless sealing profile be changed after 5 years at the latest, regardless of the actual state of wear.

  • Page 117: Removing The Seat

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove dust cap. – Check tire air pressure when tires are cold. Tire air pressure, solo Front 2.0 bar (29 psi) Rear 2.0 bar (29 psi) Tire air pressure with passenger / fully loaded Front 2.0 bar (29 psi) 400695-01...

  • Page 118: Mounting The Seat

    MAINTENANCE WORK ON CHASSIS AND ENGINE Mounting the seat 9.54 – Hook slot of the seat onto screw , press the rear downward and at the same time   push it forward. – Push locking pin into lock housing and push the back of the seat down until the ...

  • Page 119: Installing The Battery

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Disconnect the negative (minus) cable of the battery. – Pull off the plug connector upwards.  – Remove screws  – Pull the retaining bracket of the battery forward and remove it.  –...

  • Page 120: Recharging The Battery

    – Do not discard batteries with the household trash. Dispose of a defective battery in an environmentally compatible manner. Give the battery to your KTM dealer or to a recycling center that accepts used batteries. Warning Environmental hazard Hazardous substances cause environmental damage.
  • Page 121 MAINTENANCE WORK ON CHASSIS AND ENGINE Info Even when there is no load on the battery, it still loses power steadily. The charge state and the type of charge are very important for the service life of the battery. Rapid recharging with a high charging current shortens the battery's service life. If the charging current, charging voltage and charging time are exceeded, electrolyte escapes through the safety valves.

  • Page 122: Changing The Main Fuse

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Connect the battery charger to the battery. Switch on the battery charger. Battery charger (58429074000) You can also use the battery charger to test rest potential and start potential of the bat- tery, and to test the alternator. With this device, you cannot overcharge the battery. Info Never remove lid ...
  • Page 123 MAINTENANCE WORK ON CHASSIS AND ENGINE Info The main fuse protects all power consumers on the vehicle. It is in the starter relay housing, next to the battery. – Switch off all power consumers and switch off the engine. – Remove the seat.

  • Page 124: Changing The Fuses Of Individual Power Consumers

    MAINTENANCE WORK ON CHASSIS AND ENGINE Changing the fuses of individual power consumers 9.59 Info The fuse box containing the fuses of individual power consumers is located under the seat. – Switch off all power consumers and the engine. – Remove the seat.
  • Page 125 MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove the faulty fuse. Guideline Fuse 1 - 10A - ignition, combination instrument, alarm system (optional) Fuse 2 - 10A - clock, ignition (EFI control unit) Fuse 3 - 10A - throttle valve control unit Fuse 4 - 10A - fuel pump Fuse 5 - 10A - radiator fan Fuse 6 - 10A - horn, brake light, turn signal, alarm system (optional)

  • Page 126: Adjusting The Engine Characteristic

    MAINTENANCE WORK ON CHASSIS AND ENGINE Replace the spare fuse in the fuse box so that it is available if needed. – Check that the power consumer is functioning properly. – Close the fuse box cover. – Mount the seat. ( p.

  • Page 127: Removing The Headlight Mask With The Headlight

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Turn the adjusting wheel until the desired digit is next to marking  Set the Map‑Select switch to Soft. – Set the adjusting wheel to position 1. Soft – reduced homologated peak performance for better driveability. Set the Map‑Select switch to Advanced.
  • Page 128 MAINTENANCE WORK ON CHASSIS AND ENGINE – Cover the fender with a cloth to protect it from damage. – Remove the screws on the left and right.  – Tip the headlight mask forward and pull it off upward. 100296-11 –...

  • Page 129: Installing The Headlight Mask With The Headlight

    MAINTENANCE WORK ON CHASSIS AND ENGINE Installing the headlight mask with the headlight 9.62 – Connect the connectors of headlight and flasher lights   – Check lighting function. 100294-11 – Remove the cloth from the fender, attach the headlight mask to points on the fender ...

  • Page 130: Changing The Headlight Bulb

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Position groove on counterpiece   700543-01 – Position brake-hose guide . Mount and tighten screws   Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) 100296-10 Changing the headlight bulb 9.63 Note Damage to reflector Reduced luminance.

  • Page 131: Changing The Parking Light Bulb

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Pull off connector  – Take off rubber cap of the headlight bulb.  600610-10 – Detach spring bar  – Remove headlight bulb  – Insert a new headlight bulb into the headlight housing. Headlight (H4 / socket P43t) ( p.

  • Page 132: Changing The Rear Lamp

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove rubber cap  600610-12 – Pull bulb socket out of the reflector.  – Pull parking light bulb out of the bulb socket.  – Insert a new parking light bulb in the bulb socket. Parking light (W5W / socket W2,1x9,5d) ( p.

  • Page 133: Changing The Flasher Bulb

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove screws and take off the lens.  – Press the bulb carefully into the holder, turn it about 30° counterclockwise and  remove it from the holder. Info Do not touch the reflector with your fingers and try to avoid contact with oil or grease.

  • Page 134: Checking The Headlight Setting

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove the screw from the rear of the flasher housing. – Tilt headlamp diffuser forward carefully and take it off.  – Press the flasher bulb carefully into the socket, turn it counterclockwise by about 30°, and take it out of the socket.

  • Page 135: Adjusting The Headlight Range

    MAINTENANCE WORK ON CHASSIS AND ENGINE The boundary between light and dark must be exactly on the lower mark for a vehicle with a rider. » If the boundary between light and dark does not meet specifications: – Adjust the headlight range. ( p.
  • Page 136 MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove screws . Remove filter box top   100285-10 Note Engine failure Unfiltered intake air has a negative effect on the service life of the engine. – Never ride the vehicle without an air filter since dust and dirt can get into the engine and result in increased wear.

  • Page 137: Installing The Air Filter

    MAINTENANCE WORK ON CHASSIS AND ENGINE Installing the air filter 9.70 – Clean the air filter box. – Mount air filter  Info The air filter must lie flush against the air filter box along the entire sealing sur- face ...

  • Page 138: Cooling System

    MAINTENANCE WORK ON CHASSIS AND ENGINE Cooling system 9.71 The water pump in the engine forces the coolant to flow.  The pressure in the cooling system resulting from heat is regulated by a valve in the radi- ator cap .
  • Page 139 MAINTENANCE WORK ON CHASSIS AND ENGINE Warning Danger of poisoning Coolant is poisonous and a health hazard. – Avoid contact between coolant and skin, eyes and clothing. If it gets into your eyes, rinse immediately with water and contact a doctor. Wash affected skin areas immediately with soap and water. If coolant is swallowed, contact a doctor immediately. Change clothes that have come into contact with coolants.

  • Page 140: Checking The Coolant Level

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Screw off the radiator cap  – Check antifreeze of coolant. −25… −45 °C (−13… −49 °F) » If the antifreeze of the coolant does not meet specifications: – Correct the antifreeze of the coolant. –...
  • Page 141 MAINTENANCE WORK ON CHASSIS AND ENGINE Warning Danger of poisoning Coolant is poisonous and a health hazard. – Avoid contact between coolant and skin, eyes and clothing. If it gets into your eyes, rinse immediately with water and contact a doctor. Wash affected skin areas immediately with soap and water. If coolant is swallowed, contact a doctor immediately. Change clothes that have come into contact with coolants.

  • Page 142: Draining The Coolant

    MAINTENANCE WORK ON CHASSIS AND ENGINE Alternative 2 Coolant (mixed ready to use) ( p. 181) – Mount the radiator cap. Draining the coolant 9.74 Warning Danger of scalding During motorcycle operation, the coolant gets very hot and is under pressure. –...

  • Page 143: Filling The Cooling System

    MAINTENANCE WORK ON CHASSIS AND ENGINE Filling the cooling system 9.75 Warning Danger of poisoning Coolant is poisonous and a health hazard. – Avoid contact between coolant and skin, eyes and clothing. If it gets into your eyes, rinse immediately with water and contact a doctor.

  • Page 144: Adjusting Basic Position Of Clutch Lever

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove the cap from compensating tank and add coolant to the level shown in the  figure. – Mount the cap of the compensating tank. Danger Danger of poisoning Exhaust gases are poisonous and inhaling them may result in unconsciousness and/or death.

  • Page 145: Checking/Rectifying The Fluid Level Of The Hydraulic Clutch

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Adjust the basic setting of the clutch lever to your hand size by turning adjusting screw  – When adjusting the clutch lever make sure that there is a minimum clearance to other parts of the vehicle.

  • Page 146: Checking The Play In The Throttle Cable

    MAINTENANCE WORK ON CHASSIS AND ENGINE Checking the play in the throttle cable 9.78 – Move the handlebar to the straight-ahead position. Move the throttle grip backwards and forwards to ascertain the play in the throttle cable. Throttle cable play 3…...

  • Page 147: Adjusting The Play In The Throttle Cable

    Adjusting the play in the throttle cable 9.79 – Move the handlebar to the straight-ahead position. – Use the KTM diagnostics tool to set the motor drive to the basic position. – Loosen counter nut  – Set the play in the throttle cable by turning the adjusting screw ...

  • Page 148: Changing The Engine Oil And Filter, Cleaning The Oil Screens

    MAINTENANCE WORK ON CHASSIS AND ENGINE Changing the engine oil and filter, cleaning the oil screens 9.81 – Drain the engine oil. p. 146) – Remove the oil filter. p. 147) – Clean the oil screens. p. 149) – Install the oil filter. p.

  • Page 149: Removing The Oil Filter

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Place a suitable container under the engine. – Remove the oil drain plug with the magnet and seal ring.  – Completely drain the engine oil. 100200-10 – Thoroughly clean the oil drain plug with a magnet. –...
  • Page 150 MAINTENANCE WORK ON CHASSIS AND ENGINE Warning Environmental hazard Hazardous substances cause environmental damage. – Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations. – Place a suitable container under the engine. – Remove screws .

  • Page 151: Installing The Oil Filter

    MAINTENANCE WORK ON CHASSIS AND ENGINE Installing the oil filter 9.84 – Insert oil filters   – Oil the O-rings of the oil filter cover. Mount oil filter covers   – Mount and tighten the screws. Guideline Screw, oil filter cover 6 Nm (4.4 lbf ft) 100204-10 Cleaning the oil screens...
  • Page 152 MAINTENANCE WORK ON CHASSIS AND ENGINE – Remove plug with oil screen and the O-rings.   100205-10 – Remove plug with oil screen and the O-rings.   – Completely drain the remaining engine oil. – Thoroughly clean the parts and sealing area. 100206-10 –...

  • Page 153: Filling Up With Engine Oil

    MAINTENANCE WORK ON CHASSIS AND ENGINE – Position oil screen with the O-rings.  – Mount and tighten plug with the O-ring.  Guideline Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) 100208-10 Filling up with engine oil 9.86 Info Too little engine oil or poor-quality engine oil results in premature wear to the engine.

  • Page 154: Adding Engine Oil

    MAINTENANCE WORK ON CHASSIS AND ENGINE Danger Danger of poisoning Exhaust gases are poisonous and inhaling them may result in unconsciousness and/or death. – When running the engine, always make sure there is sufficient ventilation, and do not start or run the engine in an enclosed space without an effective exhaust extraction system.
  • Page 155 MAINTENANCE WORK ON CHASSIS AND ENGINE Danger Danger of poisoning Exhaust gases are poisonous and inhaling them may result in unconsciousness and/or death. – When running the engine, always make sure there is sufficient ventilation, and do not start or run the engine in an enclosed space without an effective exhaust extraction system.

  • Page 156: Troubleshooting

    Clean the socket connector and treat it with con- oxidized tact spray. – Defect in fuel injection system Read out the fault memory using the KTM diag- nostics tool. – Engine has too little power. Air filter is very dirty Remove the air filter.
  • Page 157 Air in cooling system Fill the cooling system. p. 141) – FI warning lamp (MIL) lights/flashes Defect in fuel injection system Read out the fault memory using the KTM diag- nostics tool. – Engine dies during the journey Lack of fuel Refuel. ( p.
  • Page 158 TROUBLESHOOTING Faults Possible cause Action – Time is not (correctly) displayed Fuse 2 blown Change the fuses of individual power consumers. p. 122) – Set the clock. ( p. 35) – Battery discharged Ignition not switched off when vehicle Recharge the battery. p.

  • Page 159: Blink Code

    BLINK CODE Blink code FI of warning lamp (MIL) 02 FI warning lamp (MIL) flashes briefly 2x Error level condition Crankshaft position sensor - circuit fault Blink code FI of warning lamp (MIL) 06 FI warning lamp (MIL) flashes briefly 6x Error level condition Throttle position sensor circuit A - input signal too low Throttle position sensor circuit A - input signal too high...
  • Page 160 BLINK CODE Blink code FI of warning lamp (MIL) 13 FI warning lamp (MIL) flashes 1x long, 3x short Error level condition Intake air temperature sensor - Input signal too low Intake air temperature sensor - Input signal too high Blink code FI of warning lamp (MIL) 14 FI warning lamp (MIL) flashes 1x long, 4x short...
  • Page 161 BLINK CODE Blink code FI of warning lamp (MIL) 25 FI warning lamp (MIL) flashes 2x long, 5x short Error level condition Side stand switch - circuit fault Blink code FI of warning lamp (MIL) 26 FI warning lamp (MIL) flashes 2x long, 6x short Error level condition Motor drive hall sensor - circuit fault Blink code FI of warning lamp...
  • Page 162 BLINK CODE Blink code FI of warning lamp (MIL) 53 FI warning lamp (MIL) flashes 5x long, 3x short Error level condition Fuel evaporation valve - short circuit to ground or open circuit Fuel evaporation valve - input signal too high Blink code FI of warning lamp (MIL) 54 FI warning lamp (MIL) flashes 5x long, 4x short...
  • Page 163 BLINK CODE Blink code FI of warning lamp (MIL) 91 FI warning lamp (MIL) flashes 9x long, 1x short Error level condition CAN bus communication error Blink code FI of warning lamp (MIL) 92 FI warning lamp (MIL) flashes 9x long, 2x short Error level condition Motor drive voltage (internal) - circuit fault...

  • Page 164: Cleaning

    CLEANING Cleaning the motorcycle 12.1 Note Material damage Damage and destruction of components by high-pressure cleaning equipment. – Never clean the vehicle with high-pressure cleaning equipment or a strong water-jet. The excessive pressure can penetrate electrical components, socket connects, throttle cables, and bearings, etc., and can damage or destroy these parts. Warning Environmental hazard Hazardous substances cause environmental damage.
  • Page 165 CLEANING Warning Danger of accidents Reduced braking efficiency due to wet or dirty brakes. – Clean or dry dirty or wet brakes by riding and braking gently. – After cleaning, ride the vehicle a short distance until the engine is warm, applying the brakes occasionally. Info The heat produced causes water at inaccessible locations in the engine and the brakes to evaporate.

  • Page 166: Protective Treatment For Winter Operation

    PROTECTIVE TREATMENT FOR WINTER OPERATION Protective treatment for winter operation 13.1 Info If you use the motorcycle in winter, you must expect salt on the roads. You should therefore take precautions against aggressive road salt. If the vehicle was operated in road salt, clean it with cold water. Warm water would enhance the corrosive effects of salt. –...

  • Page 167: Storage

    Storage temperature of battery without direct sunshine. 0… 35 °C (32… 95 °F) – The storage place should be dry and not subject to large temperature differences. Info KTM recommends jacking up the motorcycle. – Jack up the rear of the motorcycle. ( p. 63) –...

  • Page 168: Putting Into Operation After Storage

    STORAGE Info Do not use non-porous materials since they prevent humidity from escaping, thus causing corrosion. Avoid running the engine for a short time only. Since the engine cannot warm up properly, the water vapor produced during combustion condenses and causes valves and exhaust system to rust. Putting into operation after storage 14.2 –...

  • Page 169: Technical Data - Engine

    TECHNICAL DATA - ENGINE Design 1-cylinder 4-stroke engine, water-cooled Displacement 654 cm³ (39.91 cu in) Stroke 80 mm (3.15 in) Bore 102 mm (4.02 in) Compression ratio 11.8:1 Control OHC, 4 valves controlled via rocker arm, chain drive Valve diameter, intake 40 mm (1.57 in) Valve diameter, exhaust 34 mm (1.34 in)

  • Page 170: Capacity - Engine Oil

    TECHNICAL DATA - ENGINE Mixture preparation Electronic fuel injection Ignition Contactless controlled fully electronic ignition with digital ignition adjustment Alternator 12 V, 224 W Spark plug NGK LKAR 8AI - 9 Spark plug electrode gap 0.9 mm (0.035 in) Cooling Water cooling, permanent circulation of coolant by water pump Starting aid Electric starter, automatic decompressor...

  • Page 171: Technical Data - Engine Tightening Torques

    TECHNICAL DATA - ENGINE TIGHTENING TORQUES ® Oil hole plug self-tapping 9 Nm (6.6 lbf ft) Loctite 243™ ® Screw, membrane fixation 2.5 Nm (1.84 lbf ft) Loctite 243™ – Hose clamp, intake flange 1.5 Nm (1.11 lbf ft) ® Oil jet, conrod lubrication 2 Nm (1.5 lbf ft) Loctite...
  • Page 172 TECHNICAL DATA - ENGINE TIGHTENING TORQUES ® Screw, locking lever 10 Nm (7.4 lbf ft) Loctite 243™ – Screw, rocker arm shaft 12 Nm (8.9 lbf ft) ® Screw, shift drum locating 10 Nm (7.4 lbf ft) Loctite 243™ ® Screw, shift lever 10 Nm (7.4 lbf ft) Loctite...
  • Page 173 TECHNICAL DATA - ENGINE TIGHTENING TORQUES ® Oil hole plug M10x1 15 Nm (11.1 lbf ft) Loctite 243™ – Plug, drain hole of water pump M10x1 15 Nm (11.1 lbf ft) – Plug, oil bore for oil radiator M10x1 15 Nm (11.1 lbf ft) –...

  • Page 174: Technical Data - Chassis

    TECHNICAL DATA - CHASSIS Frame Lattice frame made of chrome molybdenum steel tubing, powder- coated Fork WP Suspension Up Side Down 4860 ROMA Shock absorber WP Suspension 4618 with Pro‑Lever deflector Suspension travel Front 275 mm (10.83 in) Rear 265 mm (10.43 in) Brake system Front Disc brake with radially screwed four-piston brake caliper, floating...

  • Page 175: Lighting Equipment

    TECHNICAL DATA - CHASSIS Steering head angle 63° Wheelbase 1,480±15 mm (58.27±0.59 in) Seat height unloaded 910 mm (35.83 in) Ground clearance unloaded 290 mm (11.42 in) Weight without fuel approx. 139.5 kg (307.5 lb.) Maximum permissible front axle load 150 kg (331 lb.) Maximum permissible rear axle load 200 kg (441 lb.)

  • Page 176: Tires

    120/70 ZR 17 M/C 58W TL 160/60 ZR 17 M/C 69W TL Pirelli Dragon Supercorsa Pro Pirelli Dragon Supercorsa Pro Additional information is available in the Service section under: http://www.ktm.com Capacity - fuel 17.3 Total fuel tank capacity, approx. 12 l (3.2 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p.

  • Page 177: Technical Data - Fork

    TECHNICAL DATA - FORK Fork part number 14.18.7E.12 Fork WP Suspension Up Side Down 4860 ROMA Compression damping Comfort 20 clicks Standard 15 clicks Sport 10 clicks Full payload 10 clicks Rebound damping Comfort 15 clicks Standard 10 clicks Sport 5 clicks Full payload 5 clicks...

  • Page 178: Technical Data - Shock Absorber

    TECHNICAL DATA - SHOCK ABSORBER Shock absorber part number 15.18.7E.12 Shock absorber WP Suspension 4618 with Pro‑Lever deflector Compression damping, high-speed Comfort 1.5 turns Standard 1 turn Sport 0.5 turn Full payload 0.5 turn Compression damping, low-speed Comfort 20 clicks Standard 15 clicks Sport...
  • Page 179 TECHNICAL DATA - SHOCK ABSORBER Riding sag 70… 80 mm (2.76… 3.15 in) Fitted length 400 mm (15.75 in) Shock absorber fluid Shock absorber oil (SAE 2,5) (50180342S1) ( p. 183)

  • Page 180: Technical Data - Chassis Tightening Torques

    TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) – Screw, SLS valve EJOT 2 Nm (1.5 lbf ft) – Spoke nipple, front wheel M4.5 4 Nm (3 lbf ft) ® Bolt, foot brake lever stub 6 Nm (4.4 lbf ft) Loctite...
  • Page 181 TECHNICAL DATA - CHASSIS TIGHTENING TORQUES ® Screw, magnetic holder on side stand 10 Nm (7.4 lbf ft) Loctite 243™ – Screw, radiator bracket 5 Nm (3.7 lbf ft) ® Screw, rear brake disc 14 Nm (10.3 lbf ft) Loctite 243™...
  • Page 182 TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Upper fuel tank screw 20 Nm (14.8 lbf ft) ® Engine carrying screw 45 Nm (33.2 lbf ft) Loctite 243™ – Remaining nuts, chassis 50 Nm (36.9 lbf ft) – Remaining screws, chassis 45 Nm (33.2 lbf ft) ®...

  • Page 183: Substances

    – Guideline – Use only brake fluid that complies with the specified standards (see specifications on the container) and that possesses the corre- ® sponding properties. KTM recommends Castrol and Motorex products. Supplier Castrol – RESPONSE BRAKE FLUID SUPER DOT 4 ®...
  • Page 184 188) (SAE 10W/60) – KTM LC4 2007+ Guideline – Use only engine oils that comply with the specified standards (see specifications on the container) and that possess the corresponding ® properties. KTM recommends Motorex products. Synthetic engine oil Supplier ® Motorex –...
  • Page 185 – ISO VG (15) Guideline – Use only hydraulic fluid that complies with the specified standards (see specifications on the container) and that possesses the corre- ® sponding properties. KTM recommends Motorex products. Supplier ® Motorex – Hydraulic Fluid 75...
  • Page 186 SUBSTANCES Super unleaded (ROZ 95 / RON 95 / PON 91) According to – DIN EN 228 (ROZ 95 / RON 95 / PON 91)

  • Page 187: Auxiliary Substances

    AUXILIARY SUBSTANCES Chain cleaner Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Chain Clean 611 Chain lube for road use Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Chain Lube 622 Strong Cleaning and preserving materials for metal, rubber and plastic Guideline –...
  • Page 188 AUXILIARY SUBSTANCES High-luster polish for paint Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Moto Polish Long-life grease Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Fett 2000 Motorcycle cleaner Guideline – ® KTM recommends Motorex products.
  • Page 189 AUXILIARY SUBSTANCES Universal oil spray Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Joker 440 Universal...
  • Page 190 STANDARDS JASO T903 MA Different technical development directions required a new specification for 4-stroke motorcycles – the JASO T903 MA Standard. Ear- lier, engine oils from the automobile industry were used for 4-stroke motorcycles because there was no separate motorcycle specification. Whereas long service intervals are demanded for automobile engines, high performance at high engine speeds are in the foreground for motorcycle engines.
  • Page 191 INDEX rear brake, changing ......101 INDEX rear brake, checking ......100 Accessories .
  • Page 192 INDEX indicator lamps ......32 Engine oil kilometers or miles, setting ..... . 34 adding .
  • Page 193 INDEX Front wheel installing ........105 Light switch ........28 removing .
  • Page 194 INDEX Parking light bulb changing ........129 Seat Passenger footrests .
  • Page 195 INDEX rear right side ....... 22 Steering lock ........30 Stopping .
  • Page 196 *3211518en* 3211518en 11/2009 Photo: Mitterbauer KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...

This manual is also suitable for:

690 smc

Table of Contents
